Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing
Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing
Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing
Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing
Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing
Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing
Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing
Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing
Specifications
Brand Name :
Joyruns
Model Number :
DIN17175 Alloy steel Tube
Certification :
ISO9000
Place of Origin :
CHANGZHOU, CHINA
MOQ :
5TONs
Price :
Negotiable
Payment Terms :
TT OT 100% LC AT SIGHT
Supply Ability :
1000Ton/month
Delivery Time :
30DAYS
Packaging Details :
Exporting package/wooden box package
Standard :
DIN17175
Grade :
4130.1020.4140,ST35,ST45,ST52,15CrMo,15CrMoG
Type :
Seamless cold drawing
OD. Range :
6mm – 114.3mm
Wall thickness :
1mm-15mm
Length :
Max length 12M
Description

DIN17175 13CrMo44 Cold drawing high-pressure seamless steel pipe

13CrMo44 Cold Drawn Welded Pipe is used in a variety of industries. In fact, the 13CrMo44 Cold Drawn Seamless Pipes is highly effective, particularly in sectors such as the oil, gas and chemical industry. Often in these industries, liquids and gases are often stored at high temperatures. Because the DIN 17175 13CrMo44 Welded Pipes are able to withstand higher temperatures, the alloy is considered to be an ideal metal for these industries.

Din 17175 13crmo44 pipe is a low alloy steel grade. Chemically, the alloy of DIN 17175 13CrMo44 Chrome Moly Steel Seamless Tube contains both chromium and molybdenum as elements that impart strength to the alloy. A reason why our clients prefer using this low alloyed EN 10216-2 13CrMo44 Seamless Pipe is that the metal has good mechanical properties, which are similar to alloy grade 12CrMo. The material for Stal 13CrMo44 Seamless Steel Tubes is generally delivered in a quenched and tempered condition.

13CrMo44 Steel Pipe /Tube Chemical Composition :

Grade

Material

C

Si

Mn

P

S

Cr

Mo

13CrMo44

1.7335

0.10-0.18

0.10-0.35

0.40-0.70

0.035

0.035

0.70-1.10

0.45-0.65

DIN 17175 13CrMo44 Seamless Steel Pipes/ Tubes Mechanical properties:

Grade

Material

Tensile strength N/mm2

Yield strength thickness,mm

Elongation (L=5do)

Notch impact energy

≤16

>16≤40

>40≤60

N/mm2 min

13CrMo44

1.7335

440-590

290

290

280

22

20

34

Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing

Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing Seamless High Pressure Steel Pipe DIN17175 13CrMo44 Cold Drawing
