6003 1.5mm Aluminum Alloy Tubes Brushed Round For Aerospace
6003 1.5mm Aluminum Alloy Tubes Brushed Round For Aerospace
6003 1.5mm Aluminum Alloy Tubes Brushed Round For Aerospace
6003 1.5mm Aluminum Alloy Tubes Brushed Round For Aerospace
Specifications
Brand Name :
TONGMAO
Model Number :
steel pipe
Certification :
ISO9001 MTC
Place of Origin :
China
MOQ :
3tons
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000tons/year
Delivery Time :
7-15days
Packaging Details :
Standard Packing
Model NO. :
6101, 6003, 6061, 6063, 6020, 6201, 6262, 6082
Temper 1 :
O - H112 T3 - T8 T351 - T851
Surface Treatment :
Anodized Brushed Mill Finished Polished Powde
Shape :
Round
Tolerance :
+-0.01mm
Specification :
Customized
Description

Aluminum Tube Alloy 6101 6003 T1 1.5mm Round Pipe Used for communication, aerospace industry engineer and mechanic

1) Products:Round pipe,square pipe,flat pipe,special designed pipe
2) Standard :STM B209-04,B210M-05,B234M-04,B241-02,B221M-05a, AISI, SUS, EN573-3-2003, JISH4000-2006,H4080-2006,H4040-2006, DIN, GB/T3190-2008,3880.1-2006,6893-2000,3191-1998,4437.1-2000, ASME,ISO3522-1984ISO ASTM GB1A80,1070A,1100,2A01,2014A,1017A,5050,5154A,5083,6161,7A01,7A52,7075,
3)Grade:
1000series:1435,1050,1060,1070,1080,1100,etc
2000series:2011,2014,2017,2024,etc
3000series:3002,3003,3104,3204,3030,etc
5000series:5005,5025,5052,5040,5056,5083,etc
6000series:6101,6003,6061,6063,6020,6201,6262,6082,etc
7000series:7003,7005,7050,7075,etc
4) WT:0.3mm above
5) OD: up to 600mm
6) Length: per customer's request
7) Process: heat extrusion, welding, seamless

Alloy Si Mg Fe Cu Mn Zn Cr Ti
1050 0.25 0.05 <0.40 <0.05 <0.05 <0.05 - <0.03
3003 0.6 - 0.7 0.05 -0.20 1.0-1.5 0.10 - -
5052 0.25 2.2-2.8 0.4 0.1 0.1 0.10 0.15-0.35 -
5083 0.4 4.0-4.9 0.4 0.1 0.4-1.0 0.25 0.05-0.25 0.15
6005 0.6-0.9 0.4-0.6 <0.35 <0.1 <0.1 <0.1 <0.1 <0.1
6061 0.4-0.8 0.8-1.2 <0.70 0.15-0.4 <0.15 <0.25 0.04-0.35 <0.05
6063 0.2-0.6 0.45-0.9 <0.35 <0.1 <0.1 <0.1 <0.1 <0.1
6082 0.7-1.3 0.6-1.2 <0.50 <0.1 0.4-1.0 <0.2 <0.25 <0.10
OD OD Tolerance ID Tolerance Roundness Straightness Circular run-out
Φ16-20 ±0.02 ±0.02 0.01↓ 0.015↓ 0.05↓
Φ20-30 ±0.02 ±0.02 0.01↓ 0.015↓ 0.05↓
Φ30-50 ±0.05 ±0.05 0.02↓ 0.020↓ 0.08↓
Φ50-80 ±0.15 ±0.10 0.05↓ 0.025↓ 0.10↓


Product Parameters

Physical properties and mechanical properties
Tensile strength
524Mpa
0.2% yield strength
455Mpa
Elongation
11%
Modulus of elasticity E/Gpa
71
1. High strength heat treatable alloy.
2. Good mechanical properties.
3. Good usability.
4. Easy to process and good wear resistance.
5. Good corrosion resistance and oxidation resistance.

Applications of Seamless Aluminium Tube/Pipe
Aluminium seamless tube is used for virtually any type of application, from high pressure and mechanical to architectural and framing, typically used for pressure vessels, hydraulic cylinders, compressed gas cylinders, driveshafts, lighting applications, and bus conductors.
1.Critical pressure ratings
2.Demanding forming applications
3.Critical strength requirement
4.Uniform anodizing appearance

6003 1.5mm Aluminum Alloy Tubes Brushed Round For Aerospace
