Specifications
MOQ :
100 PCS
Payment Terms :
T/T in advance
Place of Origin :
Chengdu , China
Brand Name :
Shunyao Supply Chain
Packaging Details :
Bundles
Delivery Time :
5-15 days
Supply Ability :
Excellent
Price :
$15-50
Warranty :
5 Years
Thickness Of Panel :
50mm, 75mm, 100mm, 150mm, 200mm, 250mm
Connection :
Bolts
Design Load :
Wind, Snow, Seismic
Raw Steel Material :
Q235B, Q355B
Maintenance Costs :
Reduced
Corrosion Resistance :
High
Labor Costs :
Lower
Using Life :
50 Years
Description
Main Product Name: Steel Structural Building Support

Other Names: Building Steel Support, Prefabricated Steel Support, Steel Structural Load-bearing Bracket; Keywords: Steel Support, Building Load-bearing Structure, Prefabricated House Support, Steel Mezzanine Bracket, Construction Temporary Support.

Processing Technology

CNC flame cutting (dimensional accuracy ±0.5mm), submerged arc automatic welding (weld strength qualification rate 100%), shot blasting derusting (derusting grade up to Sa2.5), hot-dip galvanizing/painting anti-corrosion, ultrasonic flaw detection (ensuring no weld defects);

Load-bearing Parameters

Single vertical bearing capacity 50kN - 1000kN, customizable according to material and cross-sectional dimension (e.g., φ48*3.5mm steel pipe support has a bearing capacity of about 50kN, 300*300mm H-beam support can reach 1000kN);

Anti-corrosion Standards

Hot-dip galvanized layer thickness ≥85μm, salt spray test ≥1000h; painting anti-corrosion adopts epoxy primer + polyurethane topcoat, dry film thickness ≥120μm, salt spray test ≥800h;

Material Steel Application Residential, commercial, and public buildings
Feature High Strength, Easily
Assembled, Reusable		 Warranty 2 Years
Design Style  Traditional After-sale Service Online Technical Support,
Onsite Installation
Project Solution
Capability		 3D model design, graphic
design		 Place of Origin Chengdu, China
Brand Name Shunyao supply chain steel frame Function  Diversified Agricultural Needs
