Low Fin Tubes ASTM B111 C71500 Copper Nickel CuNi30Mn1Fe Tubes For Air Cooler
Low Fin Tubes ASTM B111 C71500 Copper Nickel CuNi30Mn1Fe Tubes For Air Cooler
Low Fin Tubes ASTM B111 C71500 Copper Nickel CuNi30Mn1Fe Tubes For Air Cooler
Low Fin Tubes ASTM B111 C71500 Copper Nickel CuNi30Mn1Fe Tubes For Air Cooler
Low Fin Tubes ASTM B111 C71500 Copper Nickel CuNi30Mn1Fe Tubes For Air Cooler
Low Fin Tubes ASTM B111 C71500 Copper Nickel CuNi30Mn1Fe Tubes For Air Cooler
Low Fin Tubes ASTM B111 C71500 Copper Nickel CuNi30Mn1Fe Tubes For Air Cooler
Low Fin Tubes ASTM B111 C71500 Copper Nickel CuNi30Mn1Fe Tubes For Air Cooler
Specifications
Brand Name :
Yuhong
Model Number :
ASTM B111 C71500
Certification :
ABS, BV, DNV, CCS, LR
Place of Origin :
China
MOQ :
1ton
Price :
Negotiable
Payment Terms :
TT, LC
Supply Ability :
1000 tons/month
Delivery Time :
35-60 days
Packaging Details :
Ply-wooden Case With Iron Frame
Product :
Fin Tubes or Finned Tube
Fin Tube Type :
Low Fin Tubes / Integral Fin Tubes
Air Cooler Low Fin Tube Standard :
ASTM B111
Air Cooler Low Fin Tube Material :
C71500 Tube CuNi 70 / 30
Low Fin Tube Use :
For large equipment, Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators / Air Coolers, etc
Low Fin Tube Packing :
Ply-wooden Case With Iron Frame
Description

Low Fin Tubes ASTM B111 C71500 Copper Nickel ( CuNi30Mn1Fe) Tubes For Air Cooler

Copper nickel alloy seamless tubes widelu be used in air coolers, surface condensers, evaporators, and heat exchangers,etc. ASTM B111 C71500 copper-nickel 70/30 alloy tube has the following core performance advantages:

  • Exceptional corrosion resistance in seawater, brackish water, and marine atmospheres
  • Superior erosion resistance under high-velocity flow conditions
  • Excellent resistance to stress corrosion cracking (SCC)
  • Biofouling resistance and long-term durability in submerged applications

Chemical Composition (%) 70-30 Copper-Nickel (CuNi30Mn1Fe)

Grade Cu Ni, incl Co Pb Fe Zn Mn
C71500 remainder 29.0-33.0 0.05 0.4-1.0 1.00 1.00

Mechanical Properties 70-30 Copper-Nickel (CuNi30Mn1Fe)

Grade Standard Tensile Strength,min Yield Strength (0.2%Offset,min)
C71500 O61 52ksi 18ksi
HR50 72ksi 50ksi

Low Fin Tubes ASTM B111 C71500 Copper Nickel CuNi30Mn1Fe Tubes For Air Cooler

Definition

Low fin tubes/integral fin tubes are increasingly being used in various fluid heat exchangers, such as in coolers, condensers, and chillers. Typically constructed from materials such as carbon steel, stainless steel, alloy or copper, providing durability and resistance to corrosion.

Low fin tubes have the following core performance advantages:

  • Available in corrosion-resistant alloys (e.g., C70600 Cu-Ni, SS 316, Duplex Steel) for harsh environments.
  • 2.5–4× larger surface area than bare tubes, significantly improving heat exchange capacity,enhanced heat transfer efficiency.
  • The low-profile fins minimize flow resistance, leading to lower energy consumption in pumping systems.
  • Higher heat transfer per unit length reduces the overall size/cost of air cooler bundles, which ideal for retrofit projects where space constraints exist.
  • With a versatile application, suitable for a wide range of industries, including oil and gas, chemical processing, and power generation.

Application ( Not limited to the following )

*Oil Refineries: Resists sulfur-containing atmospheres (alloy options).

*Power Plants: Handles steam condensation efficiently

*Marine Applications: in heat exchangers for marine applications

*Air Conditioning and Refrigeration:in condensers and evaporators of air conditioning and refrigeration systems

*HVAC Systems:Lowers energy use in chillers.

*LNG Processing Units

Specifications

Type Description Base tube Fin specification (mm)
O.D. (mm) Fin pitch Fin height Fin thick
Embedded G-type fin tube 16-63 2.1-5 <17 ~0.4
Extruded Single metal / Combined metal 8-51 1.6-10 <17 0.2-0.4
Low fin tube / T-type fin tube 10-38 0.6-2 <1.6 ~0.3
Bamboo tube / corrugated tube 16-51 8-30 <2.5 ~0.3
Wound L / KL / LL type fin tube 16-63 2.1-5 <17 ~0.4
String String fin tube 25-38 2.1-3.5 <20 0.2-0.5
U-type U-type fin tube 16-38 / / /
Welding HF-welding fin tube 16-219 3-25 5-30 0.8-3
H/HH type fin tube 25-63 8-30 <200 1.5-3.5
Serrated spiral fin tube 25-219 2-7 <38.1 0.9-2.0
Studed fin tube 25-219 8-30 5-35 φ5-20

Low Fin Tubes ASTM B111 C71500 Copper Nickel CuNi30Mn1Fe Tubes For Air Cooler
