HF Welding Solid Fin Tubes ASTM A312 TP304H For Waste Heat Recovery Units
HF Welding Solid Fin Tubes ASTM A312 TP304H For Waste Heat Recovery Units
HF Welding Solid Fin Tubes ASTM A312 TP304H For Waste Heat Recovery Units
HF Welding Solid Fin Tubes ASTM A312 TP304H For Waste Heat Recovery Units
HF Welding Solid Fin Tubes ASTM A312 TP304H For Waste Heat Recovery Units
HF Welding Solid Fin Tubes ASTM A312 TP304H For Waste Heat Recovery Units
HF Welding Solid Fin Tubes ASTM A312 TP304H For Waste Heat Recovery Units
HF Welding Solid Fin Tubes ASTM A312 TP304H For Waste Heat Recovery Units
Specifications
Brand Name :
Yuhong
Model Number :
Serrated Finned Tubes ASTM A312 TP304H
Certification :
ABS, BV, DNV, CCS, LR
Place of Origin :
China
MOQ :
Depend the size of finned tubes
Price :
Negotiable
Payment Terms :
TT, LC
Supply Ability :
1000 tons/month
Delivery Time :
35-60 days
Packaging Details :
Ply-wooden Case With Iron Frame
Product :
Finned Tube
Finned Tube Type :
Serrated Finned Tubes
Serrated Finned Tubes Standard :
ASTM A312
Serrated Finned Tubes Material :
Stainless Steel TP304H Base Tubes and SS304H Fins
Serrated Finned Tubes Use :
For large equipment, Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators, etc
Serrated Finned Tubes Packing :
Ply-wooden Case With Iron Frame
Description

HF Welding Solid Fin Tubes ASTM A312 TP304H For Waste Heat Recovery Units

ASTM A312 is a standard specification for seamless, welded, and heavily cold worked austenitic stainless steel pipes.

Chemical Composition (%)

Grade C Mn P S Si Cr
TP304H 0.04-0.10 2.00 0.045 0.030 1.00 18.00-20.00

Composition:
18-20% Chromium (Cr) – Provides oxidation resistance.
0.04-0.10% Carbon (C) – Improves creep resistance at high temps.

Mechanical Properties

Grade Tensile Strength,min Yield Strength (0.2%Offset,min)
75ksi (515 MPa) 30ksi (205 MPa)
TP304H Elongation min. % Heat Treating Temperature min.
35% 1900°F [1040°C]

Corrosion Resistance: Excellent against oxidation, sulfur, and acidic flue gases.
Mechanical Strength: Good creep & stress rupture resistance (superior to standard 304).

HF Welding Solid Fin Tubes ASTM A312 TP304H For Waste Heat Recovery Units

Waste Heat Recovery Units (WHRUs) capture and reuse thermal energy from industrial exhaust gases, improving energy efficiency and reducing emissions. HF-welded solid fin tubes made of ASTM A312 TP304H stainless steel play a critical role in these systems due to their high-temperature strength, corrosion resistance, and efficient heat transfer capabilities.

304H stainless steel maintains strength at high temperatures (up to 900°C), ensuring long-term performance.Solid fins provide a larger heat exchange surface area than bare tubes, increasing thermal efficiency.

Applications in WHRU Systems

Heat Recovery Steam Generators (HRSGs)

Economizers

Air Preheaters

Flue Gas Condensers

HF-welded solid fin tubes (ASTM A312 TP304H) are essential for efficient, durable WHRUs in industries such as:Power generation (HRSGs, economizers) / Petrochemical (fired heaters, reformers) / Cement, steel, and waste incineration (flue gas heat recovery).

Specifications

Type Description Base tube Fin specification (mm)
O.D. (mm) Fin pitch Fin height Fin thick
Embedded G-type fin tube 16-63 2.1-5 <17 ~0.4
Extruded Single metal / Combined metal 8-51 1.6-10 <17 0.2-0.4
Low fin tube / T-type fin tube 10-38 0.6-2 <1.6 ~0.3
Bamboo tube / corrugated tube 16-51 8-30 <2.5 ~0.3
Wound L / KL / LL type fin tube 16-63 2.1-5 <17 ~0.4
String String fin tube 25-38 2.1-3.5 <20 0.2-0.5
U-type U-type fin tube 16-38 / / /
Welding HF-welding fin tube 16-219 3-25 5-30 0.8-3
H/HH type fin tube 25-63 8-30 <200 1.5-3.5
Serrated spiral fin tube 25-219 2-7 <38.1 0.9-2.0
Studed fin tube 25-219 8-30 5-35 φ5-20
