Specifications
Brand Name :
Yuhong
Model Number :
ASME SB163 N04400
Certification :
ABS, BV, DNV, CCS, LR
Place of Origin :
China
MOQ :
100KGS
Price :
Negotiable
Payment Terms :
TT, LC
Delivery Time :
7days
Packaging Details :
Ply-wooden case with iron frame
Base Tube Test :
HT/ET
Fin Thickness :
0.4mm
Standard :
ASME SB163
Tube Diameter :
25mm
Product :
Fin Tubes
Type :
Embedded G Type
Fin Pitch :
2.3mm
Fin Material :
Aluminum
Description

ASME SB163 N04400, Nickel Alloy Steel Seamless Tube, G Type Fin Tube with Aluminium Fin Strip


Product Overview

ASME SA163 specifies nickel alloy seamless tubes intended for high-temperature and corrosion-resistant services, especially in heat exchangers and condensers. When combined with extruded or embedded aluminium fin strips, the tube offers enhanced heat transfer performance for air-cooled and process cooling applications.


Chemical Composition of Base Tube (UNS N04400 / Monel 400)

Element Content (%)
Nickel (Ni) ≥ 63.0
Copper (Cu) 28.0 – 34.0
Iron (Fe) ≤ 2.5
Manganese (Mn) ≤ 2.0
Silicon (Si) ≤ 0.5
Carbon (C) ≤ 0.3
Sulfur (S) ≤ 0.024


Mechanical Properties of UNS N04400 Tube

Property Typical Value
Tensile Strength ≥ 485 MPa (70 ksi)
Yield Strength ≥ 170 MPa (25 ksi)
Elongation ≥ 35%
Hardness ≤ 100 HRB


Advantages

  • Excellent resistance to seawater and acidic environments (due to N04400).

  • Lightweight fin material (Aluminum) for efficient heat transfer.

  • Strong mechanical bond prevents fin loosening under thermal cycling.

  • Suitable for high-salinity and offshore environments.

  • Good thermal conductivity and durability.


Applications

  • Air Cooled Heat Exchangers in petrochemical plants

  • Offshore oil & gas cooling systems

  • Condensers in desalination plants

  • Heat exchangers in marine environments

  • Sulfuric and hydrofluoric acid process equipment

  • Power plants using brackish or seawater cooling
