Specifications
Brand Name :
RILANT
Model Number :
SZWG-2500N
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
2 sets per month
Delivery Time :
45 working days
Packaging Details :
Standard export package
Product Name :
High Precision Coil Steel Strip Cutting and Slitting Machine
Material :
Carbon Steel,Stainless Steel
Keyword :
Steel strip cutting machine
Max. Coil Width :
800-2000 mm
Voltage :
380V,50Hz,3 Phase
Rated Power :
120 KW
Dimension(L*W*H) :
1650*850*1350 mm
Applicable Industry :
Machinery,energy etc
Weight :
20 ton
Description

Steel Plate Leveling Cutting Unit Galvanized Sheet Steel Coil Slitting Machines Cold Rolled Steel Coil Slitter

Application:It is suitable for the longitudinal shearing of the metal coils and rewinding coils.
Advantages:Easy to operate, slitting quality is high, excellent material utilization, Stepless shearing speed regulation, etc.
Structure:It consist of uncoiler, feeding and positioning, slitting unit, recoiler, etc.
Applicable Materials:Tinplate, silicon steel, aluminum, copper, stainless steel and galvanized steel, etc.

Steel plate leveling cutting unit has high high-efficient constant shearing plate, bending material uncoiling, leveling and shearing of different specifications of the plate, sheet metal processing industry is essential for efficient processing lines.
The sheet behind the set can increase the finished cutting board sizing cutting system will collect the chop. Applicable to the container, machinery manufacturing, home appliances, automotive, stainless steel products, light industry and other industries.

Steel coil parameters Material HR,CRS and GI
Tensile strength δb≤450Mpa,δS≤260Mpa
Steel thickness 0.3-3mm
Steel width 500-1600
Steel coil I.D φ480-520 mm
Steel coil O.D φ1600mm(Max)
Steel coil weight 15T
Slitter parameters knife pivot diameter Ф200 mm
Knife pivot material 40Cr
Blades specification Φ200mmXφ340mmX15mm
Blade material 6CrW2Si
Slit parameter Max slit quantity 5 pcs (3mm) 25 pcs(0.3mm)
Width precision ≤±0.05mm/2M
Mini slit strips width 20mm
Other parameters Power 380V/50Hz/3Ph
Line speed 0-100m/min
Capacity 210 Kw
Whole line Dimension 25m(L)X8m(W)
Operator needed 1 mechanical engineer ,2 common workers
Line direction From right to left(Face to machine)
Machine color White grey
