1.8 M Diamond Mesh 10 14 0.5mm 1mm Bulletproof Mesh
1.8 M Diamond Mesh 10 14 0.5mm 1mm Bulletproof Mesh
1.8 M Diamond Mesh 10 14 0.5mm 1mm Bulletproof Mesh
1.8 M Diamond Mesh 10 14 0.5mm 1mm Bulletproof Mesh
1.8 M Diamond Mesh 10 14 0.5mm 1mm Bulletproof Mesh
1.8 M Diamond Mesh 10 14 0.5mm 1mm Bulletproof Mesh
Specifications
Brand Name :
LONGKUO METAL WIRE MESH
Place of Origin :
CHINA
MOQ :
1rolls
Price :
$6 ~ 99/roll
Payment Terms :
T/T, Western Union
Supply Ability :
100,000m2/year
Delivery Time :
About 7 work days depends on the supply
Packaging Details :
Plastic bag, Moistureproof paper and Wooden pallet
Product name :
Bulletproof Mesh
Material :
SS 201/304/316/304L/316L
Color :
Body/black/white/Colorful/Customizable
Hole shape :
Square Hole
Type :
Weave Wire Mesh
Sample :
According to size
Advantage :
Superior wire,standard mesh
Packing :
Paper tube inside + waterproof paper/plastic bag + wodden box/pallet
Wire diameter :
0.5-1mm
Mesh count :
10-14 mesh
Description

Mesh Count 10 - 14 Mesh Wire Diameter Range 0.5mm - 1mm Beautiful Bulletproof Mesh

Bulletproof Mesh Basis Information

Our factory is a chemical factory integrating production, sales, wholesale and retail. All products are provided with one-stop service. From wire drawing, mesh weaving, deep processing and inspection, we operate independently. All materials, sizes and specifications can be customized according to customer requirements. It is one of the largest manufacturers of stainless steel wire mesh in China. We have a large stock of many popular standard items.

Bulletproof Mesh Product Information

Stainless Steel Diamond mesh is also known as stainless steel anti-theft window screen, steel mesh, diamond mesh, bullet proof mesh and diamond protective mesh. It is a kind of stainless steel mesh. First, it is woven into the original mesh (roll shape) by heavy-duty wire mesh loom with high-strength metal wire. Then, it is cleaned, flattened and cut into flat diamond mesh. Finally, it is made by surface spray treatment. Diamond mesh refers to diamond mesh The net is stacked in a wooden box and separated by plastic film in the middle to prevent adhesion and plastic dropping.

Bulletproof Mesh Specifications

Materials: 304/304L stainless steel, 316/316L stainless steel, 201 stainless steel

Color: black, gray, white, yellow, silver, metal primary color and other colors

Specification and size:

11 mesh * 0.8mm, 12 mesh * 0.7mm, 14 mesh * 0.6mm, 14 mesh 0.55mm, 14 mesh 0.5mm. Mesh size: 1500mm * 3000mm; 1300mm * 2600mm; 1200mm * 2000mm; 1200mm * 2400mm; 1000 * 2400mm; 900mm * 2000mm; 900mm * 2400mm; 750mm * 2000mm; 750mm * 2400mm.

Bulletproof Mesh Technology

1. Raw materials for stainless steel wire drawing

2. Stainless steel drawing line production

3. Water tank wire drawing machine -- wire drawing and annealing

4. Stainless steel wire 0.50mm-1mm

5. Stainless steel mesh weaving

6. Stainless Steel Diamond mesh

7. Net washing

8. Net cutting

9. Plastic spraying

10. Packing and delivery

Bulletproof Mesh Parameter table

MESH WIRE DIAMETER(mm)
10 1mm / 0.9mm
11 0.9mm / 0.8mm
12 0.8mm / 0.7mm
13 0.6mm
14 0.50mm / 0.55mm / 0.60mm
