Weaving 1.42mm Thin Steel Cable In Spool Thin Metal Wire
Weaving 1.42mm Thin Steel Cable In Spool Thin Metal Wire
Weaving 1.42mm Thin Steel Cable In Spool Thin Metal Wire
Weaving 1.42mm Thin Steel Cable In Spool Thin Metal Wire
Weaving 1.42mm Thin Steel Cable In Spool Thin Metal Wire
Weaving 1.42mm Thin Steel Cable In Spool Thin Metal Wire
Weaving 1.42mm Thin Steel Cable In Spool Thin Metal Wire
Weaving 1.42mm Thin Steel Cable In Spool Thin Metal Wire
Specifications
Brand Name :
LONGKUO METAL WIRE MESH
Place of Origin :
CHINA
MOQ :
1 Coil / Spool or Negotiable
Price :
$2 ~ 4 / kg
Payment Terms :
T/T, Western Union
Supply Ability :
5000tons/year
Delivery Time :
About 7 work days depends on the supply
Packaging Details :
Wooden box or plastic spool or steel spool or coil
Product name :
Stainless Steel Cold Cable
Material :
Stainless Steel 201,304,304L,316,316L and so on.
Diameter :
1.42mm
Surface :
Bright Finish, Galvanized, Spray plastic
Type :
In Spool
Packing :
Wooden box or plastic spool or steel spool or coil
Alloy or not :
Is Alloy
Color :
Primary color/ Customized
Quality :
High
Sample :
Small Sample Free
Usage :
Weaving
We are factory :
Low MOQ, Lowest price and the best service
Description

Weaving Type in Spool Diameter 1.42mm Stainless Steel Cold Cable

Product Information

Stainless Steel Cold Cable is made of stainless steel as raw material for various kinds of silk products of different specifications and models. The cross section is generally round or flat. The common stainless steel wires with good corrosion resistance and high cost performance are 201, 304 and 316 stainless steel wires.

Specifications

Name Code

Characteristics

 Specification Material

Stainless steel soft wire / Hydrogen wire

 S, soft

Bright surface, soft, no magnetism, fatigue resistance, large extension force and other characteristics

0.09 — 0.45mm

201, 304, 304L, 316, 316L, 310, 310S, 321, etc.

Stainless steel light cable

 LD, lightly drawn

After heat treatment, the steel wire shall be pulled with small reduction surface. The surface is bright, soft, fatigue resistant, and has certain elongation.

0.5 — 1.5mm

201, 304, 304L, 316, 316L, etc.

Stainless steel cold cable

 WCD, cold drawn

The surface is smooth, toughness is good and wear resistant

 0.03 — 6.0mm

201, 304, 304L, 316, 316L, etc.

Stainless steel spring wire

 -

High hardness, strong elasticity, good wear resistance and compression resistance

 0.15 — 5.0mm

302, 304H, 304L, 316, 316L, 310, 310S, 321, etc.

Material composition table

AISI

Material

 Chemical composition (%)
C Si Mn P S Ni Cr Mo Cu Ti
201 ≤0.15 ≤0.75 5.5~7.5 ≤0.06 ≤0.03 3.5~5.5 16~18 - - -
304 <0.08 <1.0 <2.0 <0.035 <0.03 8~10 17~19 - - -
304L <0.03 <1.0 <2.0 <0.04 <0.03 9~13 18~20 - - -
304HC <0.06 <1.0 1.2-1.8 <0.035 <0.03 8~11 17~19 - 2.0-3.0 -
316 <0.08 <1.0 <2.0 <0.04 <0.03 10~14 16~18 2.0~3.0 - -
316L <0.03 <1.0 <2.0 <0.04 <0.03 12~15 16~18 2.0~3.0 - -
310S <0.08 <1.5 <2.0 <0.04 <0.03 19~22 24~26 - - -
321 <0.08 <1.0 <2.0 <0.045 <0.03 9~13 17~19 - - >0.035
301 <0.15 <1.0 <2.0 <0.04 <0.03 >7 16~18 - - -
302 <0.15 <1.0 <2.0 <0.04 <0.03 >8 17~19 - - -

Product specification parameter table

Wire diameter(mm) Tolerance(mm)

Maximum diameter

deviation(mm)
0.020-0.049 +0.002 -0.001 0.001
0.050-0.074 ±0.002 0.002
0.075-0.089 ±0.002 0.002
0.090-0.109 +0.003 -0.002 0.002
0.110-0.169 ±0.003 0.003
0.170-0.184 ±0.004 0.004
0.185-0.199 ±0.004 0.004
0.-0.299 ±0.005 0.005
0.300-0.310 ±0.006 0.006
0.320-0.499 ±0.006 0.006
0.500-0.599 ±0.006 0.006
0.600-0.799 ±0.008 0.008
0.800-0.999 ±0.008 0.008
1.00-1.20 ±0.009 0.009
1.20-1.40 ±0.009 0.009
1.40-1.60 ±0.010 0.010
1.60-1.80 ±0.010 0.010
1.80-2.00 ±0.010 0.010
2.00-2.50 ±0.012 0.012
2.50-3.00 ±0.015 0.015
3.00-4.00 ±0.020 0.020
4.00-5.00 ±0.020 0.020
