Large Space Steel Warehouse Structure for Logistics Buildings
Large Space Steel Warehouse Structure for Logistics Buildings
Large Space Steel Warehouse Structure for Logistics Buildings
Large Space Steel Warehouse Structure for Logistics Buildings
Large Space Steel Warehouse Structure for Logistics Buildings
Large Space Steel Warehouse Structure for Logistics Buildings
Large Space Steel Warehouse Structure for Logistics Buildings
Large Space Steel Warehouse Structure for Logistics Buildings
Large Space Steel Warehouse Structure for Logistics Buildings
Large Space Steel Warehouse Structure for Logistics Buildings
Large Space Steel Warehouse Structure for Logistics Buildings
Large Space Steel Warehouse Structure for Logistics Buildings
Specifications
Brand Name :
Ruly Steel
Model Number :
Ruly0101
Certification :
SGS, BV, ISO
Place of Origin :
China
MOQ :
500 Square Meter
Price :
USD29-USD99 Per Square Meter
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
20000 Square Meter Per Month
Delivery Time :
30 Days
Packaging Details :
As request
Application :
Logistics steel warehouse, workshop
Raw steel material :
Q235B, Q355B, ASTM A36
Shot blasting level :
Sa 2.5
Service life :
50 Years
Wall and Roof :
Glass wool
Surface treatment :
Painting
Type :
Large space steel frame structure
Working scope :
Design,Fabrication, Installation
Description
High Structural Stability Steel Structure Construction for Modern Logistics and Warehousing
Product Specifications
Attribute Value
Application Logistics steel warehouse, workshop
Raw steel material Q235B, Q355B, ASTM A36
Shot blasting level Sa 2.5
Service life 50 Years
Wall and Roof Glass wool
Surface treatment Painting
Type Large space steel frame structure
Working scope Design, Fabrication, Installation
Large Space Structural Steel Warehouse for Modern Logistics Buildings

Steel frame structure logistics warehouses offer numerous advantages including light weight, high structural stability, large indoor space, excellent heat preservation, short installation period, and energy efficiency. With the rapid development of modern logistics and e-commerce, steel structure warehouses have become increasingly popular.

These specialized warehouses have distinct space and load requirements compared to conventional warehouses, designed specifically to meet the functional demands of logistics and warehousing operations.

Key Advantages
  • Superior structural stability and durability
  • Large unobstructed interior spaces
  • Excellent thermal insulation properties
  • Faster construction timeline compared to traditional buildings
  • Energy efficient design
  • Customizable to specific operational requirements
Technical Specifications
No. Item Details
1 Material Carbon structural steel
2 Production Lead Time Typically 45 days after down payment (varies by quantity)
3 Quality Certification Factory quality certificate, third-party inspection available upon request
4-7 Dimensions H beam: 4000-15000mm length
Web plate: 6-32mm thickness
Wing plate: 6-40mm thickness
200-1200mm height
8 Color Customizable to customer requirements
9 Size Minimum order quantity: 1000 m² (width × length × eave height)
10 Main Components - Base Cement and steel foundation bolts
11 Main Frame H Steel beam, Q235/Q345 steel H beam and columns (painted or galvanized), box steel, galvanized C section or steel pipe
12 Secondary Frame Galvanized C or Z purlin, steel bracing, tie bar, knee brace, flashing, etc.
13 Material Options Q235B, Q345B or other standards (ASTM, BSEN, DIN, IPE, AISI, JIS) upon request
14 Purlin C or Z purlin: Size from C120~C320, Z100~Z200
15 Column Types X-type, tree type, lattice, Cross, Box, etc.
16 Bolts Plain bolt and High-strength bolt
17 Roof & Wall PU sandwich panel, Rockwool sandwich panel or Corrugated steel sheet
18 Canopy Steel sheet, PU sandwich panel, Rockwool sandwich panel
19 Door Sliding or rolling door
20 Window Aluminium alloy window
21 Surface Treatment Two layers of rust-proof painting or Hot Dip Galvanized
22 Sheet 0.5mm or 0.6mm galvanized sheet
23 Accessories Semi-transparent skylight belts, Ventilators, down pipe, Galvanized gutter, Trim, flashing, etc.
24 Finishing Options Wide color/texture selection, Alkyd painting, two primary painting, two finish painting (gray, red, white, epoxy zinc, etc.) or Galvanized
Steel Structure Fabrication
Large Space Steel Warehouse Structure for Logistics Buildings
Our Services
  • Structural steel fabrication, painting, galvanizing, pre-assembly
  • Complete design, fabrication and installation for prefabricated steel structures
  • Detailed fabrication/shop drawings based on your architectural plans
  • Professional engineering consulting services
Large Space Steel Warehouse Structure for Logistics Buildings
Packing and Transportation

All structural components, panels, bolts and accessories are carefully packed in standard packages suitable for ocean transportation and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts to load products at our factory, ensuring all goods are protected from damage during transit.

Large Space Steel Warehouse Structure for Logistics Buildings
