Specifications
Brand Name :
Lanjing
Model Number :
LANJING-1
Certification :
ICR Polska/VC/HS221231
Place of Origin :
China
MOQ :
1000sqm
Price :
1000-1500 Square Meters $45-50;1500-2000 Square Meters $42-45;2000-3000 Square Meters $40-42;
Payment Terms :
TT
Supply Ability :
30000T/year
Delivery Time :
30-45 days
Name :
Multi Storey Steel Structure Building
Cladding :
Steel color sheet
Purlin :
C/Z Section Steel
Keyword :
Steel Metal Frame Structure
Parapet Wall :
As Requested
Hs Code :
9406900090
Main Structure :
Steel Structure -H Steel, Z or C Purlin
Frame :
Weld steel structure frame
Description
Product Details
Fireproof Multi Storey Workshop Steel Structure With C And Z Section Steel Purlin
Fireproof Multi Storey Workshop Steel Structure With C And Z Section Steel Purlin
Specification
Fireproof Multi Storey Workshop Steel Structure With C And Z Section Steel Purlin

In contrast to traditional buildings, steel structures represent a modern approach to construction—these buildings are entirely composed of steel. The framework primarily consists of steel beams, columns, trusses, and other components made from section steel and steel plates. These elements are interconnected through welding, bolts, and rivets.

The lightweight and streamlined designs are widely utilized in large factories, stadiums, super high-rise buildings, and various other applications. Types of steel building structures include portal rigid steel frames, frame structures, truss structures, and grid structures.

Features and Applications of Standard Steel Building Structures:
Portal Frame Structure: This type offers straightforward load distribution, a clear pathway for force transmission, and rapid construction. It is commonly used in both industrial and civil projects, including commercial, cultural, and entertainment public facilities.
Steel Frame Structures: These structures are adaptable and can create expansive spaces. They are frequently employed in multi-story and high-rise buildings such as commercial office complexes, shopping malls, conference centers, and more.
Steel Truss Structures: Utilizing small cross-section tubes to form larger components, these structures are often found in industrial and civil projects like large-span roofs, bridges, towers, and marine oil production platforms, particularly where significant spans or heights are required.
Steel Grid Structures: This high-order statically indeterminate space structure comprises numerous rods arranged according to specific rules, resulting in minimal space stress, lightweight characteristics, high rigidity, and excellent seismic resistance. Applications include gymnasiums, exhibition halls, petrol stations, and hangars.

Material Description
Main Structure
Including Column & Beam, Made of welded H section Steel, Steel Grade Q355B/Q235B
Column & Beam Connection: High Strength Bolt
Column & Foundation Connection: Pre-embedded Anchor Bolt
Secondary Structure
Roof Purlin & Wall Purlin: C-shape or Z-shape Steel
Knee Brace: Angle Steel
Brace: Steel Rod
Tie Bar: Steel Pipe
Types of wall panels and roof panels
Applicable Regions and Scenarios
Color Steel Sheet
Areas without winter, preferred for processing workshops and warehouses
Color Steel Sheet & Fiberglass Roll Insulation
Areas with winter but with low requirements of temperature , preferred for warehouses and workshops
Insulated Sandwich Panel
Workshops and warehouses with temperature requirements
PU Insulated Sandwich Panel
Workshops, warehouses and public facilities with high requirements of temperature for the working environment
Product packaging
Fireproof Multi Storey Workshop Steel Structure With C And Z Section Steel Purlin
FAQ
1. What kind of customer service do you provide?
We offer comprehensive customer service, including basic design,supporting facilities procurement, and the option to dispatch installation guidance.

2. How about the customer reviews of your company?
We are proud to have received consistently high five-star reviews from our customers, which stand as a testament to our commitment to quality and service.

3. What is your quality inspection process like?
Our strict quality inspection process ensures that every product meets the highest standards of excellence. From raw materials to finished goods, each stage is meticulously inspected to guarantee superior quality.

4. Can you send engineers or a whole team to install my project?
We will give detailed installation drawings for free. We can send engineers as an installation director or a team upon request.

5. Do you accept container loading inspection?
You are welcomed to send an inspector, not only for the container loading, but any time during the production time.

6. Do you offer designing service for us?
Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc. we can design complex industrial buildings like office mansions, super markets, auto dealer shops, shipping malls, 5-star hotels.

7. What is the delivery time?
Delivery time depends on order quantities. In general, the delivery time to the nearest seaport in China will be 40 days after
receiving the deposit.

8. How can I get a quotation for my projects?
You can contact us by email, phone, Trade manager and so on 24*7 and you will get a reply within 8 hours.

9. What certifications has your company passed?
Our company has passed professional certifications such as IOS9000, CE, and SGS, ensuring that our products and services meet international standards.
