A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel
Specifications
Brand Name :
BY
Model Number :
BYAS00053
Certification :
ABS, GL, DNV, NK,
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000 ton per Month
Delivery Time :
5-8 work days
Packaging Details :
PLY-WOODEN CASE OR PALLET
Product Name :
Carbon Steel Pipe
OD :
1/2"-48”
Type :
Seamless or welded
Thickness :
SCH 5-SCH XXS
Standard :
A333 Gr6
Prodcut :
steel pipe tube
Description

A333 Gr6 Seamless Carbon Steel Tube For Low Temperature Pressure Vessel OD1/2'-16'

Product Standard: GB/T18984-2003,ASTM A333,ASME SA333


Main steel grades: 16MnDG,10MnDG,09DG,09Mn2VDG,06Ni3MoDG,ASTM

A333Gr1,A333Gr3,A333Gr4,A333Gr6,A333Gr7,A333G8,A333Gr9,A333Gr10,A333Gr11

Application: for low temperature pressure vessel pipes of -45 °C ~ -195 °C and low temperature heat exchanger pipes.

Chemical Requirements & Mechanical Properties:

Standard GB/T18984-2003
Chemical Components (%)
Grades C Si Mn P S Cr Ni Cu Mo V Al
16MnDG 0.12-0.20 0.20-0.55 1.20-1.60 ≤0.025 ≤0.025 -- -- -- -- -- --
10MnDG ≤0.13 0.17-0.37 ≤1.35 ≤0.025 ≤0.025 -- -- -- -- ≤0.07 --
09DG ≤0.12 0.17-0.37 ≤0.95 ≤0.025 ≤0.025 -- -- -- -- ≤0.07 --
09Mn2VDG ≤0.12 0.17-0.37 ≤1.85 ≤0.025 ≤0.025 -- -- -- -- ≤0.12 --
06Ni3MoDG ≤0.08 0.17-0.37 ≤0.85 ≤0.025 ≤0.025 -- 2.5-3.7 -- 0.15-0.30 ≤0.05 --
ASTM A333 A333Gr1 ≤0.30 -- 0.40-1.06 ≤0.025 ≤0.025 -- -- -- -- --
A333Gr3 ≤0.19 0.18-0.37 0.31-0.64 ≤0.025 ≤0.025 -- 3.18-3.82 -- -- -- --
A333Gr4 ≤0.12 0.18-0.37 0.50-1.05 ≤0.025 ≤0.025 0.44-1.01 0.47-0.98 0.40-0.75 -- -- 0.04-0.30
A333Gr6 ≤0.30 ≥0.10 0.29-1.06 ≤0.025 ≤0.025 -- -- -- -- -- --
A333Gr7 ≤0.19 0.13-0.32 ≤0.90 ≤0.025 ≤0.025 -- 2.03-2.57 -- -- -- --
A333Gr8 ≤0.13 0.13-0.32 ≤0.90 ≤0.025 ≤0.025 -- 8.40-9.60 -- -- -- --
A333Gr9 ≤0.20 -- 0.40-1.06 ≤0.025 ≤0.025 -- 1.60-2.24 0.75-1.25 -- -- --
A333Gr10 ≤0.20 0.10-0.35 1.15-1.50 ≤0.030 ≤0.015 ≤0.15 ≤0.25 ≤0.015 ≤0.50 ≤0.12 ≤0.06
A333Gr11 ≤0.10 ≤0.035 ≤0.60 ≤0.025 ≤0.025 ≤0.50 35.0-37.0 -- ≤0.50 -- --

Standard Grades TS(Mpa) YS(Mpa) Elongation(%)
vertical horizontal

GB/T1898

-2003

 16MnDG 490-665 ≥325 ≥30 --
10MnDG ≥400 ≥240 ≥35 --
09DG ≥385 ≥210 ≥35 --
09Mn2VDG ≥450 ≥300 ≥30 --
06Ni3MoDG ≥455 ≥250 ≥30 --
ASTM A333 A333Gr1 ≥380 ≥205 ≥35 ≥25
A333Gr3 ≥450 ≥240 ≥30 ≥20
A333Gr4 ≥415 ≥240 ≥30 ≥16.5
A333Gr6 ≥415 ≥240 ≥30 ≥16.5
A333Gr7 ≥450 ≥240 ≥30 ≥22
A333Gr8 ≥690 ≥515 ≥22 --
A333Gr9 ≥435 ≥315 ≥28 --
A333Gr10 ≥550 ≥450 ≥22 --
A333Gr11 ≥450 ≥240 ≥18 --


Mark: As required.

Inspection and Test:

chemical composition test, mechanical properties test(tensile, yield, elongation), process properties test(flatting, flaring, bending, hardness, impact, etc.), appearance and size test, non-destructive inspection test, hydrostastic test.

Delivery status: Annealed, normalized, normalized+Tempered, etc.

Surface treatment: oil impregnation, paint, passivation, phosphating, shot blasting etc.

Packing: Exporting package/wooden box /as requirement.

A333 Gr6 Carbon Seamless Steel Pipe For Low Temperature Pressure Vessel

Place of Origin

 China Brand Name BOYUE
Standard ANSI, ISO, ASME, DIN, ASTM Type

Seamless
ModelNumber Carbon Steel Pipe Thickness SCH 5-SCH XXS
Packing Depending on customer Payment 30%TT+70% Balance


Supply Ability:40000Pieces / per Month
Packaging & Delivery
Packaging Details:Generally plywooden case or following customer's requirement.
Port:Shanghai/Tianjin

Commerce Clause

Minimum Order Quantity: 1pcs
Price: Depending on quantity
Payment Terms: T/T or Western Union or LC
Supply Ability: 40000 ton per month
Delivery Time: 10-100 days depending on quantity
Packaging Details: Depending on customer



Why Choose Us

1. One-Stop Service,One Single Source.
2. No MOQ.
3. Best quality,competitive price
4. Fast Reply.
5. On-Time Delivery
6. Professional sales and technical team .

FAQ

Q1: Are you a factory or a trade company?
A1: We are a professional manufacturer for designing and producing of Large-size products.(View Mor)
Q2: Do you make customized products or finished parts?
A2: All parts are custom made only, and in stock, we can produce based on your drawings.
Q3: Will my drawing be e after you get it?
A3: Yes, we will not release your design to third party unless with your permission.
Q4: What is the MOQ?
A4: Small order is acceptable, but the more, the cheaper.
Q5: How about the samples?
A5: We are happy to make prototype part or sample for clients to ensure quality standard, but it’s charged according to your drawing.
