The Purpose Of Forged Flanges

Forged flanges combine two separate machinery parts together. They can be an extension to a structure in order to make the object stronger. Industrial flanges have numerous uses including connecting sheets, pumps, pipes and structures that specifically require an intermediate point of connection.

Types Of Forged Flanges

Stainless steel flanges come in many different types. Each type meets its own requirement. Long weld neck flanges are attached to a pipes neck. The way this flange is welded ensures the thickness is the same as the dimensions of the pipe that it was connected to. These flanges are most commonly used for applications that use high pressure.

Advantages

A connection that has been FCI forged will eliminate certain aspects of shop fabrication. A reinforced pad application eliminates the need for cutting, drilling, layout, forming and the tapping of the weep hole.

Better Quality Control

The inspections relating to shop fabrication, components and material trace ability is greatly reduced. This lets the Quality Control Inspectors use their time in areas that are of a more critical concern. Barrel distortion is also reduced significantly.

Reduced Production Costs

The FCI has reduced the production of fabrication costs. This applies to material requisitioning, purchasing, expediting, quality control, inspections, documentation, testing, the fabrication schedule and material requisitioning. All of this lowers the cost of production and saves money.

Any questions can be easily addressed by having a consultation. You questions will be correctly and promptly answered.

Chemical Properties:

Mechanical Properties:

Physical Properties:

Flanges we also provide:

ANSI/ASME FORGED FLANGES

MSS-SP-44 FLANGES/ANSI B 16.47 SERIES A

API TYPE 6A - RTJ Face Flanges.

API-605 FLANGES/ANSI B 16.47 SERIES B

A.G.A. ORIFICE UNIONS - Furnished with or without Hardware.

ASME BOILER CODE FLANGES

CL. 125 LIGHTWEIGHT FLANGES - For low pressure applications.

PLATE FLANGES - From 1/4" thru 8" Thick, Including AWWA C-207,and all other
special designs.

ANSI LONG WELDNECKS & SPECIAL BODY CONNECTORS

SPECTACLE BLINDS

Special Ring Flanges

Materials:

CARBON STEEL - ASTM/ASME SA-105, A-350 LF-2, LF-3, A694, SA-516-70, A36

CHROME ALLOYS - A-182-F-1, F-5, F-6, F-7, F-9, F-11, F-12, F-22, F-51

STAINLESS STEEL - A-182 - F-304, 304L, 316, 316L, 309, 310, 317L, 321, 347,
Alloy 20

ALUMINUM - 1100, 2014, 3003, 5083, 5086, 6061, 7075

HASTALLOY - B-2, C-276, G, X

INCONEL - 600, 601, 625, 718

INCOLLOY - 800, 825

MONEL - 400

COPPER - C11000

NAVAL BRASS - (Bronze)

TITANIUM
