Dry / Wet High Chrome Grinding Balls High Precision +-1mm / +-2mm Tolerance
Dry / Wet High Chrome Grinding Balls High Precision +-1mm / +-2mm Tolerance
Specifications
Brand Name :
DRAGON BALLS
Model Number :
45# 60Mn B2 B3 Low Cr High Cr Medium Cr
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 ton
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :
3000 tons / Month
Delivery Time :
3-7 work days/ 25 tons
Packaging Details :
Container bags ,steel drums
Technology :
Forging,hot rolling,casting
Usage :
Mining,Cement plant,Power Station
Advantage :
High Wear Resistant,High output and low price
Material :
Steel Iron ,Round Steel
Tolerance :
+-1mm,+-2mm
Hardness :
According to the material and customer requirements
Package :
Container bags ,Steel drums
Service :
After sale service
Description

High Cr Casting Steel Balls Cement Grinding Balls Dry Grinding Wet Grinding balls

1. Ball Mill Balls Forged ball, Hot Rolling ball,Grinding rods specifications:

① Chemical Composition

Material Chemical Composition
C Si Mn Cr P S Ni Cu
C45

0.42-0.5

0.17-0.37

0.5-0.8

≤0.25

≤0.035

≤0.035

≤0.25

≤0.25
60Mn

0.55-0.65

0.17-0.37

0.7-1.0

≤0.25

<0.04

<0.04

≤0.3

≤0.25
B2

0.72-0.85

0.17-0.37

0.7-1.0

0.4-0.6

≤0.025

≤0.025

≤0.02

≤0.02
B3

0.58-0.66

1.3-1.9

0.65-0.8

0.7-0.9

≤0.025

≤0.025

≤0.02

≤0.02

② Hardness

Size

C45

60Mn

B2

B3
20mm 55-58 58-62 60-64 62-65
30mm 55-58 58-62 60-64 62-65
40mm 55-58 58-62 60-64 62-65
50mm 55-58 58-62 60-64 62-65
60mm 55-58 58-62 60-64 62-65
70mm 53-56 58-62 60-64 61-63
80mm 53-56 58-62 59-63 60-65
90mm 50-55 58-62 57-61 60-65
100mm 48-52 57-61 56-60 60-65
110mm 48-52 57-61 55-60 58-64
120mm 48-52 57-61 55-60 56-63
130mm 48-52 57-61 55-60 56-63
140mm 48-42 57-61 55-60 56-63
150mm 48-52 57-61 55-60 56-63

③ Weight

Size(mm) 20 30 40 50 60 70 80 90 100 110 120 130 140 150
Weight(kg) 0.033 0.111 0.261 0.512 0.883 1.402 2.092 2.98 1.087 5.44 7.062 9.008 11.25 13.83

④ Dragon balls specifications

Diameter

(mm)

Diameter Tolerance

(mm)

 Approx Weight of per ball(kg) Average numbers per ton
20 ＋1,－0.5 0.033 30303
30 ＋2,－1 0.11 9090
40 ＋2,－1 0.261 3831
50 ＋2,－1 0.512 1961
60 ＋2,－1 0.883 1132
70 ＋3,－1.5 1.402 713
80 ＋3,－1.5 2.092 478
90 ＋3,－1.5 2.98 335
100 ＋3,－1.5 1.087 244
110 ＋3,－1.5 5.44 183
120 ＋3,－1.5 7.062 141

⑤ Grinding rods size

Diameter 30mm-90mm
Length 3.2 m-4.5 m

2. Ball Mill Balls Cast balls, cylpebs Specifications:

① Chemical Composition

Material C Si Mn Cr P S
Low Cr 2.2-3.4 ≤1.2 0.5-1.5 1.0-1.5 ≤0.06 ≤0.06
Medium Cr 2.0-3.2 <1.0 0.5-2.5 ≥5 ≤0.06 ≤0.06
High Cr 2.0-3.2 <1.0 0.5-2.5 ≥10 ≤0.06 ≤0.06

② Hardness

Type Low Cr Medium Cr High Cr
20mm-150mm 45-50 48-55 58-63

③ Dragon Balls Weight

Size(mm) 20 30 40 50 60 70 80 90 100 110 120 130 140 150
Weight(kg) 0.033 0.111 0.261 0.512 0.883 1.402 2.092 2.98 1.087 5.44 7.062 9.008 11.25 13.83

④ Dragon balls specifications

Diameter

(mm)

Diameter Tolerance

(mm)

 Approx Weight of per ball(kg) Average numbers per ton
20 ＋1,－0.5 0.033 30303
30 ＋2,－1 0.11 9090
40 ＋2,－1 0.261 3831
50 ＋2,－1 0.512 1961
60 ＋2,－1 0.883 1132
70 ＋3,－1.5 1.402 713
80 ＋3,－1.5 2.092 478
90 ＋3,－1.5 2.98 335
100 ＋3,－1.5 1.087 244
110 ＋3,－1.5 5.44 183
120 ＋3,－1.5 7.062 141

⑤ Grinding cylpebs Size(mm)

6×6

8×8

10×10

15×15

12×18

20×35

22×30

25×25

25×30

25×35

30×35

30×40

35×40

35×45

⑥ Production Process

Cast Balls and cylpebs are melted in electric furnace and poured into moulds after scientific proportioning. High chromium balls and cylpebs are also processed by oil quenching.

⑦ The Abrasion of the cast balls when grinding the cement

Material Abrasion Breakage Size(mm)
Low Chrome Cast Ball 85-105g Cast Balls /Ton Cement <2% 10-150mm
Medium Chrome Cast Ball 50-80g Cast Balls /Ton Cement <1.5% 10-150mm
High Chrome Cast Ball 35-60g Cast Balls/Ton Cement <1% 10-120mm
High Chrome Cylpebs 35-60g Cylpebs/Ton Cement <1.5% 12×18-35×40
Low Chrome Cylpebs 65-95g Cylpebs/Ton Cement <1% 12×18-35×40
Micro Cylpebs 6×6 8×8 10×10 12×12 15×15

3. Cement Grinding Balls Classification:

Dry / Wet High Chrome Grinding Balls High Precision +-1mm / +-2mm Tolerance

4. The difference of the forged ball and cast ball

① Different production line

② Different raw material

③ Different chemical element

④ Different core hardness and core hardness

5. How to choose the material

① According to the different customer need and usage.

② According to the ball mill size, dry grinding or wet grinding. We can recommend you the most suitable products.

6. Ball Mill Balls Quality Control

① Factory Test

Grinding cylpebs test is an very important step. Real-time detection will be carried out in the production process. Cylpebs produced in each shift will be sampled in large quantities and tested for size, hardness, chemical composition, drop test, core pulling and impact value to ensure the quality of cylpebs

② The third party test

According to the customer different demand, cylpebs can be tested by any third party.

7. Packing

Cylpebs are usually packed in container bags and steel drums, it can also be customized according to different customer needs.
