Specifications
Brand Name :
BAOSTEEL BENSTEEL HBIS
Model Number :
Galvalume Steel Coil
Certification :
SGS,BV,ISO
Place of Origin :
China
MOQ :
5 tons
Price :
600 - 810 USD/Ton
Payment Terms :
L/C, T/T,Western Union
Supply Ability :
3000 TON per month
Delivery Time :
5 days
Packaging Details :
Standard export packing or as per customer’s request.
Products :
Galvanized steel Coil
Zinc Coating :
AZ60-275 g/m2
Coil ID :
508mm / 610mm
Type :
Coil / Strips
Technique :
Hot dipped galvanized
Surface :
regular spangle / zero spangle
Width :
1000mm 1250mm 1500mm
Service :
slit cutting
Coil Weight :
5 - 10 Tons
Loading Port :
Shanghai, China
Description

JISCO Galvalume SteeL Coil AZ100 AZ120 AZ150 AZ180 Galvanized Steel Rolled 0.4 - 2.5mm

Galvalume steel is carbon steel coated with an aluminum-zinc alloy using a continuous hot-dip process, combining the corrosion protection and high-temperature resistance of aluminum with the formability and galvanic protection of zinc.

Applications for Galvalume Steel Products

Galvalume steel’s unique protective characteristics and economical price point make it ideal for:

  • Residential and Commercial Exterior Building Products
  • Roofing
  • Siding
  • Cabinetry

Galvalume Steel Sheet

  • Material Thickness: .015"-.135"
  • Max Coil: 45,000 lbs
  • ID: 20”-24”
  • Entry Width: 15.00”-74.00”
  • Exit Width: 5.00”-74.00”
  • Length: 6.00”-144”
  • Width/Length Tol: +/-.010"
  • Exit width: 4.00"-74.00”
  • Max coil weight: 50,000 lbs

Galvalume Steel Coil

  • Material Thickness: .010"-.500"
  • Min/Max Slit width: .375”-84”
  • Min/Max ID: 20”-30”
  • Max OD: 84”
  • Slit Width Tolerance: +/-.005"

galvalume steel sheet and coil service capabilities include slitting, shearing, blanking, degreasing and brushing,

galvalume steel sheet and coil product information and availability.

Structural Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
30,33,36,40 0.25 0.9 0.035 0.04 0.2 0.2 0.15 0.06 0.008 0.008 0.025
36T2,45-80 0.25 1.35 0.035 0.04 0.2 0.2 0.15 0.06 0.008 0.008 0.025
45T2 .02- 0.08 .30- 1.0 .03- .07 0.025 .02- .08 0.6 0.2 0.2 0.15 0.06 0.008 0.008 0.025 .01- .03

HSLA Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
45C1 0.22 1.35 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
45C2 0.15 1.35 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
50C1 0.23 1.35 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
50C2 & 55C2 0.15 1.35 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
55C1 0.25 1.35 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
60C1 & 65C1 0.26 1.5 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
60C2 & 65C2 0.15 1.5 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
70C1 0.26 1.65 0.04 0.04 0.2 0.2 0.15 0.16 0.005 0.005 0.005
70C2 0.15 1.65 0.04 0.04 0.2 0.2 0.15 0.16 0.005 0.005 0.005

Common Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
CSA 0.1 0.6 0.03 0.035 0.2 0.2 0.15 0.06 0.008 0.008 0.025
CSB 0.02-.15 0.6 0.03 0.035 0.2 0.2 0.15 0.06 0.008 0.008 0.025
CSC 0.08 0.6 0.1 0.035 0.2 0.2 0.15 0.06 0.008 0.008 0.025
BH 0.012 1.5 0.12 0.03 0.2 0.2 0.15 0.06 0.008 0.008 0.025
FSA 0.1 0.5 0.02 0.035 0.2 0.2 0.15 0.06 0.008 0.008 0.025
FSB 0.02-.15 0.5 0.02 0.03 0.2 0.2 0.15 0.06 0.008 0.008 0.025
DDS 0.06 0.5 0.02 0.025 .01 0.2 0.2 0.15 0.06 0.008 0.008 0.025
EDDS 0.02 0.4 0.02 0.02 .01* 0.2 0.2 0.15 0.06 0.1 0.1 0.15
