436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate
436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate
436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate
436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate
436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate
436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate
436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate
436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate
Specifications
Brand Name :
TISCO BAO STEEL ZPSS LISCO
Model Number :
436L
Certification :
SGS ISO MTC
Place of Origin :
China Jiangsu
MOQ :
200KGS
Price :
1.65 USD/KG
Payment Terms :
L/C, T/T
Supply Ability :
300000KGS
Delivery Time :
10 Days
Packaging Details :
Wodden Pallet
Material :
SUS436L
Color :
2B /2D NO.1 or customized
Size :
Customized Size,as your request
Feature :
Corrosion Resistance High Temperature
Thickness :
1-3mm,3-10mm or Customized
Width :
1000-1500mm
Length :
2000-6000mm
Description

Stainless Steel 436 / 436L Sheets Specifications:

Specifications ASTM A240, ASME SA240
Dimensions ASTM, ASME and API
Standard JIS, AISI, ASTM, GB, DIN, EN, etc.
Surface 2B, 2D, BA, NO.4, NO.8, 8K, Mirror,Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching
Width 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,etc.
Finish Black,Bright Polished,Rough Turned,No.4 Finish,Matt Finish,BA Finish
Length 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc.

Grade Specifications for Stainless Steel 436 / 436L Sheets

STANDARD WERKSTOFF NR. UNS JIS
SS 436 1.4536 S43600 SUS 436
SS 436L – – SUS 436L

Chemical Properties of SS 436 / 436L Sheets

Grade Fe Cr Ni Mo Mn Nb Si Ti Ta C P S
SS 436 81.3 16 – 1 1 0.5 – – 0.5 0.12 0.040 0.030
SS 436L 80.49 17.3 0.3 1 0.3 – 0.3 0.3 – 0.01 – –

Mechanical Properties of SS 436 / 436L Sheets

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation Hardness
0.28 lbs/in3 7.74 g/cm3 2600 – 2750 ° F (1427 – 1510 °C) 77 KSI min (531 MPa min) 53 KSI min (365 MPa min) 40 % Rb 89 max
0.28 lbs/in3 7.74 g/cm3 2600 – 2750 ° F (1427 – 1510 °C) 441-517 MPa 64000-75000 psi (Metric) 276-345 MPa 40000-50000 psi (Imperial) 28-35% 74-85

Product name Prime quality ASTM A240 AISI 436 2B Finish cold rolled Stainless Steel Sheets from TISCO ZPSS
Materials Mill TISCO,ZPSS
Surface 2B
Standard ASTM A240
Grade 400 series
Technical treatment Cold Rolled
Thickness 1mm
Width 1000mm
Length 2000mm
Application Escalator, Elevator, Production tools, Kitchen appliances, freezers, cold rooms,Auto Parts,Machinery and Packaging,Equipment and Medical devices,Transport system
Package

In bundles, packed with wooden pallet and can be also according to the regulations and customer’s requests.

Type 436 is a 1% molybdenum-alloyed ferritic stainless steel with medium chromium content. It is suitable for use in many corrosive environments, like for instance in the cold end of automotive exhaust systems. Because of its titanium alloying, Type 436 can be welded in all dimensions without becoming susceptible to intergranular corrosion.

SPECIFICATIONS

Grade

Tensile Strength,

min.

Yield Strength,B

min

Elongation in

2 in.(50mm)

Cold

Bend
436 ksi MPA kis MPA min,% 180
65 450 35 240 22

Chemical Component(%) (AISI 436)
C ≤0.025
Cr 16.00-19.00
Mn ≤1.00
P ≤0.040
S ≤0.030
Si ≤1.00
Mo 0.75-1.00
N 0.025

436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate436L Food Grade Stainless Steel Sheet Metal 2D Finished Stainless Steel Plate
