ASTM B575 ASME SB575 UNS N06022 Alloy Steel Hastelloy C22 Plate Alloy 22 Plate
ASTM B575 ASME SB575 UNS N06022 Alloy Steel Hastelloy C22 Plate Alloy 22 Plate
ASTM B575 ASME SB575 UNS N06022 Alloy Steel Hastelloy C22 Plate Alloy 22 Plate
ASTM B575 ASME SB575 UNS N06022 Alloy Steel Hastelloy C22 Plate Alloy 22 Plate
ASTM B575 ASME SB575 UNS N06022 Alloy Steel Hastelloy C22 Plate Alloy 22 Plate
ASTM B575 ASME SB575 UNS N06022 Alloy Steel Hastelloy C22 Plate Alloy 22 Plate
Specifications
Brand Name :
VDM
Model Number :
Hastelloy C22
Certification :
SGS ISO MTC
Place of Origin :
China
MOQ :
100KGS
Price :
35 USD/KG
Payment Terms :
L/C, T/T
Supply Ability :
80000KGS
Delivery Time :
7 Working Days
Packaging Details :
Wooden Pallet BOX
Grade :
Nickel Base Alloy,Hastelloy C22
Type :
Nickel Plate
Ni (min) :
Balance
Standard :
ASTM,DIN,EN,AISI
Material :
Hastelloy C22
Thickness :
1mm~30mm
Package :
wooden boxes package
Description

Hastelloy C22 Plate Hastelloy C22 Plate Alloy C22 Sheet UNS N06022 Alloy Steel Plate

Specification Of Hastelloy C22 Sheet

ASTM Specification ASTM A240 / ASME SA240
Standard MSRR, AMS, BS, ASTM A240 / ASME SA240
Length & Sizes 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1250mm x 2500mm, 1500mm x 3000mm to 6000mm, 2000mm x 4000mm to 6000mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 2m, 2.44m, 3m, 36" X 120" or 48" X 144", 4' x 8', Cut to size available
Thickness 0.1mm to 100 mm Thk
Width 10-2500mm
Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Temper Annealed
Condition Polished on both sides
Finish Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Stock in form of Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate
Value Added Service Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc.
Dealers & Distributor of SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material
Test Report
  • Raw Materials Certificate
  • EN 10204/3.1B
  • 100% Radiography Test Report
  • High special strength, high melt point
  • Third Party Inspection Report, etc
  • Excellent corrosive resistance, good thermal resistance
  • Customer support after-sales service
  • Strict Control from Raw Material to Finished

Metric Dimensions

Surface finish Thickness (mm) Width (mm)
2B – Cold rolled, heat treated, pickled, skin passed 0.25–8.0 max. 2032
2D – Cold rolled, heat treated, pickled 0.4–6.35 max. 1524
2E – Cold rolled, heat treated, mechanically descaled 0.4–8.0 max. 2032
2R – Cold rolled, bright annealed 0.25–3.5 max. 1524
2H – Work hardened 0.4–6.35 max. 1524
Polished, brushed 0.5–4.0 max. 1524

Imperial Dimensions

Surface finish Gauge (in) Width (in)
2B – Cold rolled, heat treated, pickled, skin passed 10–24 max. 72*
2D – Cold rolled, heat treated, pickled 12–24 max. 60
BA Mexinox only 18–28 max. 48
Polished (not brushed) 11–24 max. 60
Temper rolled Mexinox only 13–29 max. 48
Chemical Composition Of ASME SB575 Hastelloy C22 Coil
Hastelloy C22 Ni C Mo Mn Si Fe P S Co Cr
Balance 0.010 max 12.5 – 14.5 0.50 max 0.08 max 2 – 6 0.02 max 0.02 max 2.5 max 20 – 22.5
Mechanical Properties Of UNS N06022 Shim Sheets
Density Melting Point Yield Strength (0.2%Offset) Tensile Strength Elongation
8.69 g/cm3 1399 °C (2550 °F) Psi – 45000 , MPa – 310 Psi – 1,00,000 , MPa – 690 45 %
STANDARD UNS WERKSTOFF NR. AFNOR EN JIS BS GOST
Hastelloy C22 N06022 2.4602 – NiCr21Mo14W NW 6022 – –

ASTM B575 ASME SB575 UNS N06022 Alloy Steel Hastelloy C22 Plate Alloy 22 PlateASTM B575 ASME SB575 UNS N06022 Alloy Steel Hastelloy C22 Plate Alloy 22 PlateASTM B575 ASME SB575 UNS N06022 Alloy Steel Hastelloy C22 Plate Alloy 22 Plate
