316L DIN1.4404 Stainless Steel Plate ASTM A240 Grade
316L DIN1.4404 Stainless Steel Plate ASTM A240 Grade
316L DIN1.4404 Stainless Steel Plate ASTM A240 Grade
316L DIN1.4404 Stainless Steel Plate ASTM A240 Grade
316L DIN1.4404 Stainless Steel Plate ASTM A240 Grade
316L DIN1.4404 Stainless Steel Plate ASTM A240 Grade
Specifications
Brand Name :
Mittel
Model Number :
316L
Certification :
SGS ISO MTC
Place of Origin :
China
MOQ :
100KGS
Price :
3.65USD/KG
Payment Terms :
L/C, T/T
Supply Ability :
80000KGS
Delivery Time :
7 Working Days
Packaging Details :
Wooden Pallet BOX
Material :
Metal,stainless steel,316
Metal type :
Stainless Steel
Shape :
flat Plate
Thickness :
1.5-30 mm or Customized
Surface :
According to customer demand
Width :
1000-2000mm
Description

316L Stainless Steel Plate DIN1.4404 Stainless Steel Plate ASTM a240 Grade 316L Stainless Steel Metal Plate

Type 316L is a variant of Type 316 and differs by having a lower Carbon content as well as slightly lower yield and tensile strengths. Type 316L offers improved weldability and also reduces the possibility of lower corrosion resistance around welded areas.

1. Products Details

Commodity 300 Series 316 Stainless Steel Plate
Grade 301,302,304,304L,316,316L,310S,309S,321,301,310
Brand TISCO ,BAOSTEEL,POSCO,JISCO,LISCO
Certification SGS,BV,IQI,TUV,ISO,etc
Thickness 0.3mm-3.0mm
Width 1000,1219,1250,1500mm, or as your requirements
Length 2000,2438,2500,3000,6000mm, or as your requirements
Surface No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film.
Standard ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc
Delivery 5-7 days after confirming the order
MOQ 1 Ton

2. Chemical Properties:

C Mn Si P S Cr Mo Ni N
316
(S31600)		 0.08
max		 2.0
max		 0.75
max		 0.045
max		 0.03
max		 min: 16.0
max: 18.0		 min: 2.0
max: 3.0		 min: 10.0
max: 14.0		 0.10
max
316L
(S31603)		 0.03
max		 2.0
max		 0.75
max		 0.045
max		 0.03
max		 min: 16.0
max: 18.0		 min: 2.0
max: 3.0		 min: 10.0
max: 14.0		 0.10
max

Mechanical Properties:

Grade Tensile Strength
ksi (min)		 Yield Strength
0.2% ksi (min)		 Elongation % Hardness (Brinell) MAX Hardness
(Rockwell B) MAX
316
(S31600)		 75 30 40 217 95
316L
(S31603)		 70 25 40 217 95

3. 316L 316 316Ti PROCESSING OF Laser Cutting

And compared to traditional oxygen acetylene, such as plasma cutting technology, laser cutting speed, narrow kerf width, small heat affected zone, vertical degree good, trimming smooth kerf edge, at the same time can be variety of laser cutting materials, including carbon steel, stainless steel, alloy steel, wood, plastic, rubber, cloth, quartz, ceramic, glass, composite materials, etc.With the rapid development of market economy and the progress of science and technology, laser cutting technology has been widely used in automobile, machinery, electricity, hardware and electrical appliances and other fields.

316L DIN1.4404 Stainless Steel Plate ASTM A240 Grade316L DIN1.4404 Stainless Steel Plate ASTM A240 Grade316L DIN1.4404 Stainless Steel Plate ASTM A240 Grade
