ABS DNV EH40 shipbuild steel plate , construction steel plate 1500-3000mm width
ABS DNV EH40 shipbuild steel plate , construction steel plate 1500-3000mm width
ABS DNV EH40 shipbuild steel plate , construction steel plate 1500-3000mm width
ABS DNV EH40 shipbuild steel plate , construction steel plate 1500-3000mm width
ABS DNV EH40 shipbuild steel plate , construction steel plate 1500-3000mm width
ABS DNV EH40 shipbuild steel plate , construction steel plate 1500-3000mm width
ABS DNV EH40 shipbuild steel plate , construction steel plate 1500-3000mm width
ABS DNV EH40 shipbuild steel plate , construction steel plate 1500-3000mm width
Specifications
Brand Name :
BAOSTEEL WISCO JIGSTEEL
Model Number :
EH40
Certification :
SGS,BV
Place of Origin :
CHINA
MOQ :
5 TON
Price :
650 USD
Payment Terms :
T/T
Supply Ability :
5000TONS every month
Delivery Time :
7 - 15 days
Packaging Details :
Export packing or as required
Name :
ship steel plate
material :
A D E F grade
length :
6-11m
width :
1500-2500mm
thickness :
5-250mm
Type :
hot rolled
Description

Specifications

steel ship plate EH40
Thickness:5-250 mm
Width:1500-3000mm
Standard: ABS/KR/CCS/GL/BV/DNV/LR/KDK/NKK/RINA

ABS DNV EH40 shipbuild steel plate, EH40 steel plate,hot rolled steel plate

Commodity EH40 ship steel plate:
StandardAISI, ASTM, BS, DIN, GB, JIS
Model

EH40, DH40, AH40, 2HGR50, EH36, EH32, DH36, DH32, AH32,AH36,Q235A/B/D

Thickness5 to250mm
Width1500 to 2500mm
Lengthas per customer's request
ApplicationMainly used in automotive, appliance, machine, printing, construction and building materials

DNV EH40 extra high Strength Chemical Composition

Grade

The Element Max (%)

C

Si

Mn

P

S

Al

N

NV/EH40

0.18

0.10-0.50

0.9-1.6

0.035

0.035

0.015-0.08

Nb

V

Ti

Cu

B

Ni

Mo

0.02-0.05

0.05-0.10

0.02

0.35

0.20

0.40

0.08

Crack Sensitivity: Pcm = (C+Si/30+Mn/20+Cu/20+Ni/60+Cr/20+Mo/15+V/10+5B)%
Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

DNV EH40 extra high general strength property

Grade

Mechanical Property

Thickness

Yield

Tensile

Elongation

Degree

Energy 1

Energy 2

NV/EH40

mm

Min Mpa

Mpa

Min %

-40

J

J

t≤50

390

510-650

20%

27

41

50＜t≤70

390

510-650

20%

30

45

70＜t≤150

390

510-650

20%

37

55

Note: Energy 1 is transverse impact test, Energy 2 is longitudinal

Boiler steel plates | Alloy steel plates | High strength plate| Carbon steel plate | Stainless steel plate

Equivalent steel grade of NV/EH40

ABS

KR

LR

BV

CCS

NK

GL

RINA

AB/EH40

R EH40

LR/EH40

BV/EH40

CCS/EH40

K EH40

GL-EH40

RI/EH40


Advantage of us
1, fast deliver
2, good quality
3, cheap price
ABS DNV EH40 shipbuild steel plate , construction steel plate 1500-3000mm widthABS DNV EH40 shipbuild steel plate , construction steel plate 1500-3000mm width
