Astm A131 Grade A Ship Steel Plate , AH36 Shipbuilding Steel Plate 6.0*2000*6000mm
Astm A131 Grade A Ship Steel Plate , AH36 Shipbuilding Steel Plate 6.0*2000*6000mm
Astm A131 Grade A Ship Steel Plate , AH36 Shipbuilding Steel Plate 6.0*2000*6000mm
Astm A131 Grade A Ship Steel Plate , AH36 Shipbuilding Steel Plate 6.0*2000*6000mm
Astm A131 Grade A Ship Steel Plate , AH36 Shipbuilding Steel Plate 6.0*2000*6000mm
Astm A131 Grade A Ship Steel Plate , AH36 Shipbuilding Steel Plate 6.0*2000*6000mm
Astm A131 Grade A Ship Steel Plate , AH36 Shipbuilding Steel Plate 6.0*2000*6000mm
Astm A131 Grade A Ship Steel Plate , AH36 Shipbuilding Steel Plate 6.0*2000*6000mm
Specifications
Brand Name :
WISCO
Model Number :
AH36
Certification :
ISO
Place of Origin :
China
MOQ :
1 ton
Price :
680 USD/Ton
Payment Terms :
L/C, T/T
Supply Ability :
500 tons per month
Delivery Time :
7 days
Packaging Details :
Export Packing
Standard :
AISI, ASTM, BS, DIN, GB, JIS
Type :
Steel Plate
Application :
Ship Plate
Special Use :
High-strength Steel Plate
Technique :
Hot Rolled
Description

Astm A131 Grade A Ship Steel Plate , AH36 Shipbuilding Steel Plate 6.0*2000*6000mm

ASTM A131 AH36 steel plate, AH36 steel is a kind of steel for shipbuilding and platform. Shipbuilding steel plate AH36 is the high tensile strength steel.

ABS steels come 4 grades in ordinary-strength steel for shipbuilding and grade A is the lowest one of them. The ABS A grade steel plates have yield strength of 34,100 psi (235 MPa), and ultimate tensile strength of 58,000 - 75,500 psi (400-520 MPa). All the ABS/A shipbuilding Steel offered by Baoxin Steel Group can be certificated by American Bureau of Shipping(ABS).

1.Thickness:6~100mm

2.Width:1000~4800mm

3.Length:1000~18000mm

Chemical Properity

Grade

C

max

Si

max

 Mn

P

max

S

max

Als

min

Ti

max

Cu

max

 Cr
max		 Ni
max		 Mo
max		 Nb V
AH36 0.18 0.50 0.90-1.60 0.035 0.035 0.015 0.02 0.35 0.20 0.40 0.08 0.02-0.05 0.05-0.10

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.38% (thickness ≤ 50mm),≤0.40%( when the thickness >50-100). Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.

Mechanical Properity
Grade Rm
(MPa)		 Re(MPa) min A% min Akv/J min
AH36 490-630 355 21 E.T °C Thickness (mm)
0 ≤ 50 >50-70 >70-100
L C L C L C
34 24 41 27 50 34

Note: In the list , Rm: .tensile strength,Re: Yield strength,A%: elongation, E.T: experimental temperature,L: lengthways, C: crosswise.
