Specifications
Brand Name :
Mittel
Model Number :
DC04
Certification :
SGS ISO MTC
Place of Origin :
China
MOQ :
500KGS
Price :
0.75 USD/KG
Payment Terms :
L/C, T/T
Supply Ability :
5000Tons
Delivery Time :
14 Days
Packaging Details :
Export Packing
Thickness :
0.3-3.0mm
Width :
10-650mm
Surface :
Bright
Condition :
Cold Rolled
Grade :
DC04
Description

With excellent drawing and welding performance and relatively high dimensional accuracy, the clod rolled low carbon and ultra-low carbon steel plates provided byMittel have been widely applied to manufacture of various automotive parts. With some ductibility, DC04(St14, St15) low carbon and ultra-low carbon automotive steel plates are suitable to simple forming, bending or welding.

DC04(St14, St15) low carbon and ultra-low carbon automotive steel mechanical and process performance:


Steel grade
 Yield strength
MPa		 Tensile strength Mpa
≥		 After Breakage Percent Elongation (L0=80mm, b=20mm)%≥ rb, c
≥		 nb, c
≥
Nominal Thickness mm
<;0.70 0.70~<;1.0 1.0~<;1.6 ≥1.6
DC04(St14, St15) 120~210 270 36 38 39 40 1.5 0.18

a taking RP0.2 in case of indistinct yield, otherwise ReL.
c r=(r90+2r45+r0)/4; n= (n90 +2n45+n0)/4.

DC04(St14, St15) low carbon and ultra-low carbon automotive steel plates sizes:
Nominal thickness: 0.30mm~0.35mm, nominal width: 700mm~1850mm.

DC04(St14, St15) low carbon and ultra-low carbon automotive steel tensile strain mark:

It is guaranteed that no tensile strain mark occurs on steel plates and strips at their application within 6 months after they are produced and in case of room temperature storage.

DC04(St14, St15) low carbon and ultra-low carbon automotive steel surface quality:


Grade
 Code No. Features
Relatively high-grade finishing surface FB(O3) It is allowed for the existence of a few surface defects which will not affect forming and coating & plating adhesiveness such as minor scratch, impression, pit, roll mark and oxidation tint.
High-grade finishing surface FC(O4) One side of relatively good quality is free from any remarkable defect visible and the other side must reach FB requirements at least.
Ultra high-grade finishing surface FD(O5) One side of relatively good quality is free from any defect, namely appearance quality after painting or electrogalvanizing is no affected, and the other side must reach FB requirements at least.
