Specifications
Brand Name :
Laiwu Steel
Model Number :
20CrMnTiH DIN1.7147 20MnCr5
Certification :
SGS ISO MTC
Place of Origin :
China
MOQ :
10Tons
Price :
735 USD/Ton
Supply Ability :
500 Tons per Month
Delivery Time :
7 days
Packaging Details :
Export Packing
OD :
8-450MM
Length :
1-12m
Surface :
Black and Bright
Type :
Hot Rolled
Description

20CrMnTiH Steel Round Rod ASTM SAE5120 DIN1.7147 Forged Steel Bar Quenching and Temperature

20CrMnTi| GB/T 3077 20CrMnTi Alloy Steel Plate

Specification in 20CrMnTi

Thickness: 8MM to 250 MM,

Width: 1500mm to 4050mm,

Length: 3000mm to 15000mm

Gangsteel is specialized in supplying Alloy steel plate in 20CrMnTi. For more information of 20CrMnTi steel plates, please check them in following:

20CrMnTi Chemical Composition
Grade The Element Max (%)
C Si Mn P S
20CrMnTi 0.17~0.23 0.17~0.37 0.80~1.10 0.035 0.035

Grade 20CrMnTi Mechanical Property
Thickness Yield Tensile HB
20CrMnTi mm Min Mpa Mpa HB
6-50 850 1080
50-200 850 1080

For more information about GB/T 3077 Alloy steel plate, please clicking Mill Technical Information

If GB/T 3077 20CrMnTi covers the following issues of hot rolled and forging alloy steel: the dimension, shape, weight, tolerance, engineering specification, test method, inspection rules, packaging, marking, and quality certificates.

The standard applies to alloy structural steel bar 250mm maximum diameter or thickness. After consultation between the two sides of supply and demand, bar stock of diameter greater than 250 mm can also be provided

The chemical compositions of steel grades specified in the standard also apply to steel ingot, billet and its productions.

20CrMnTi Alloy Steel Bar

1. Features Specifications: 20CrMnTi Alloy Steel Bar

2. Commodity:20CrMnTi Alloy Steel Bar

3. Hot rolling craftwork and fine mechanical performance

4. Chemical components meet standards, delivery in black skin
5. Standards: GB/T3077 20CrMnTi

6. Size: dia 18 - 460 mm

7. Length:6M above

8. Packing:Bundles

Chemical Composition:

C Si Mn Cr S P Ni Cu Ti
0.17~0.23 0.17~0.37 0.80~1.10 1.00~1.30 ≤0.035 ≤0.035 ≤0.030 ≤0.030 0.04~0.10

Our company can supply various kinds of steel bars.Welcome to send us inquires!
