API 5L A106 GR.B ERW / LSAW / SSAW Sch 40 Carbon Steel Seamless Steel Pipe
API 5L A106 GR.B ERW / LSAW / SSAW Sch 40 Carbon Steel Seamless Steel Pipe
API 5L A106 GR.B ERW / LSAW / SSAW Sch 40 Carbon Steel Seamless Steel Pipe
API 5L A106 GR.B ERW / LSAW / SSAW Sch 40 Carbon Steel Seamless Steel Pipe
Specifications
Brand Name :
Mittel
Model Number :
API 5L GR.B
Certification :
SGS ISO API 5L
Place of Origin :
China
MOQ :
5 Tons
Price :
850 USD/Ton
Payment Terms :
L/C, T/T
Supply Ability :
20 Tons
Delivery Time :
7 days
Packaging Details :
Export Packing
OD :
8-325MM
Thickness :
1-30mm
Length :
1000-12000mm
Surface :
Black and Oil
Type :
Weled And Seamless
Use :
Oil and exchanger
Description

API 5L A106 GR.B ERW / LSAW / SSAW / Seamless Sch 40 Carbon Steel Pipe and Tubes

Product name: Seamless Beveled End Pipe

Scope of the seamless steel pipe we produce:

Manufacturer Pipe Steel Pipe Shandong Huitong Steel Pipe Manufacturing Co.,Ltd.
Brand Name qiluhuitong
Business Type Manufacture & Sales
Product Description Caron & Low Alloy Seamless Steel Pipe
Advantaged Product Specification
English Chinese

Outside Diameter

(Inch)

Wall

thickness

(Inch)

Outside

Diameter

(mm)

Wall

thickness

(mm)
From 1/2 to 5 From SCH40 to XXS From 25 to 356 From4 to 80
Length From 2m to 12.5m in accordance with customers' requirements

Material

&

Standard

Description

 Chisese American German
10# ASTM A53-A St37 DIN1626
ASTM A106-A St37-2 DIN17175
ASTM A179-C St35.8 DIN17175
ASTM A192 St35.8 DIN17175
20# ASTM A53-B St42-2 DIN1626
ASTM A106-B St45-8 DIN17175
ASTM A178-C St45-4 DIN1629
45# ASTM A1045 CK45
16Mn ASTM A210-C St52 DIN1629
37Mn5 J55
27SiMn
CrMo ASTM 4135,4150 CrMo4 DIN17212
40Cr ASTM 5140 41Cr4

Carbon Steel Seamless Pipes Details:

Material Grades

High Temperature Seamless Pipe ASTM A106 Gr. B/C, API 5L Gr. B, ASTM A53 Gr. B
Heat Exchanger Seamless Tube ASTM A179
Low Temperature Seamless Pipe ASTM A333 Gr. 3/6
Low Temperature Seamless Tube ASTM A334 Gr. 6
High Yield Seamless Pipe API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2
High Yield Seamless Pipe ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485
Atmospheric & Low Temp EFW Pipes ASTM A671 Gr. CC60/CC65/CC70
High Pressure & Moderate Temp EFW Pipes ASTM A672 Gr. B60/B65/B70/C55/C60/C65/C70
High Yield ERW/SAW Pipe API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2
High Yield ERW/SAW Pipe ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485

Additional Testing : NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc.
Dimensions : All Pipe is manufactured and inspected/tested to the relevant standards including ASTM, ASME, API.

High Temperature Seamless Pipe ASTM A106 Gr. B/C, API 5L Gr. B, ASTM A53 Gr. B
Heat Exchanger Seamless Tube ASTM A179
Low Temperature Seamless Pipe ASTM A333 Gr. 3/6
Low Temperature Seamless Tube ASTM A334 Gr. 6
High Yield Seamless Pipe API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2
High Yield Seamless Pipe ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485
Atmospheric & Low Temp EFW Pipes ASTM A671 Gr. CC60/CC65/CC70
High Pressure & Moderate Temp EFW Pipes ASTM A672 Gr. B60/B65/B70/C55/C60/C65/C70
High Yield ERW/SAW Pipe API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2
High Yield ERW/SAW Pipe ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485

Additional Testing : NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc.
Dimensions : All Pipe is manufactured and inspected/tested to the relevant standards including ASTM, ASME, API.

carbon steel pipe astm specifications Chemical Composition

Grade C≤ Mn P≤ S≤ Si≥ Cr≤ Cu≤ Mo≤ Ni≤ V≤
A 0.25 0.27-0.93 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08
B 0.30 0.29-1.06 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08
C 0.35 0.29-1.06 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08

carbon steel pipe astm specifications Mechanical Properties

Grade Rm Mpa Tensile Strength Mpa Yield Point Elongation Delivery Condition
A ≥330 ≥205 20 Annealed
B ≥415 ≥240 20 Annealed
C ≥485 ≥275 20

Annealed

Packing of Carbon Seamless steel pipe

-- Big OD:in bulk

-- Small OD:bundled by steel strips

-- Nomal OD:bundled by 4 to 8 heavy steel strips with plastic tarpaulin clin cover all the

bundles including two slings of the bundle with two steel tags


Shipping of Carbon Seamless steel pipe

Container Loading Capacity
Type Length Width Height Volume Max Weight
20FT GP 5.8m 2.13m 2.18m 24-26 CBM 25 MT
40FT GP 11.8m 2.13m 2.18m 54 CBM 25 MT
40FT HP 11.8m 2.13m 2.72m 68 CBM 26 MT
According to the quantity or volume,you can choose!
FCL(full container load); LCL(less than container load); or Bulk-cargo.
