Pleated Stainless Steel Filter Element Liquid Stainless Steel Mesh Filter Cartridge
Pleated Stainless Steel Filter Element Liquid Stainless Steel Mesh Filter Cartridge
Pleated Stainless Steel Filter Element Liquid Stainless Steel Mesh Filter Cartridge
Pleated Stainless Steel Filter Element Liquid Stainless Steel Mesh Filter Cartridge
Pleated Stainless Steel Filter Element Liquid Stainless Steel Mesh Filter Cartridge
Pleated Stainless Steel Filter Element Liquid Stainless Steel Mesh Filter Cartridge
Pleated Stainless Steel Filter Element Liquid Stainless Steel Mesh Filter Cartridge
Pleated Stainless Steel Filter Element Liquid Stainless Steel Mesh Filter Cartridge
Specifications
Brand Name :
XinLi
Model Number :
Pleated Filter
Certification :
ISO9001
Place of Origin :
HeNan
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5000+Pcs+Per Month
Delivery Time :
20-25 Work days
Packaging Details :
Plastic Bubble Film + Wooden Box, As The Clients Requirement
Diameter :
40,50,60,100Inch and customized size
Working Pressure :
30Mpa
Connection Method :
222，226 and customized size
Receiving Capacity :
16.9-41mg/cm2
Material :
304,316,316L
Length :
10,20,30,40Inch and customized size
Micron :
1-300um
Working Temperature :
300℃
Description

316L High Temperature Resistance Pleated Stainless Steel Micron Melt Filter Element For Liquid Filter

Product Introduction:

Our pleated filter cartridges are made of stainless steel fiber mat and stainless steel weaving wire mesh. Stainless steel sintered fiber web is a multi-pore filter media. The filter elements gives you the advantage of high porosity, large filter area and high dirt holding capacity, and can also be clean and reused by chemical cleaning or ultrasonic cleaning methods.

Filter Elements Adaptors:

1. Standard Adaptors (222,220,226)
2. Fast Interface Connector
3. Threaded Connector
4. Flange
5. Tire Rod
6. Other Special Adaptors

Product Features:

1. High dirt-holding capacity (longer lifetime)
2. High temperature resistance
3. High differential pressure, with stand capacity
4. Strong corrosion resistant
5. Back flushing
6. Excellent mechanical strength
7. No media migration
8. Customized Sizes available

Application:

Polymer ,water treatment, oil, pharmaceutical ,food and beverage, chemical, synthetic filtration ,and medium filtration such as high temperature.

Material Stainless steel 304 or 316L
Micron Rate 1-300um
OD Standard 60mm / 65mm or customized
Connectors Standard 220/222/226, Thread, Flange, Fast interface
Length Standard 10”, 20”, 30”, 40” or customized
Application Water, Oil, Polymer, Chemical, Food, High temperature gas filtration, and so on

Technical Prameters:

Product

Type

 Material

Micron

(um)

Outer

Diameter

(mm)

 Length Connector O-Ring/Gasket

Filter

Media
Pleated SS304

1,2,5,10,15,20,

25,30,40,50,Etc

 30 5’’ 1’’ BSP Threaded Silicore Stainless Steel Wire Mesh
SS316L 60 10’’ NIL-Cut Ends Buna-N Mesh + Sintered Fiber Felt
Other 65 20’’ DOE Viton
80 30’’ 222/Seal Teflon
85 40’’ 226/Seal

Ethylene

Propylene

The above options are freely combined, For Example:

Pleated 316l;Micron:5;Out Dia:60;Length:20’’;Connector:222;Gasket:Silicore;Fiter Media:Stainless steel wire mesh

Notice:It also can be customized according to your requirerment
