316 304 Stainless Steel Ice Cream Mixing Tank / Maturation Tank Jacketed Type
316 304 Stainless Steel Ice Cream Mixing Tank / Maturation Tank Jacketed Type
316 304 Stainless Steel Ice Cream Mixing Tank / Maturation Tank Jacketed Type
316 304 Stainless Steel Ice Cream Mixing Tank / Maturation Tank Jacketed Type
316 304 Stainless Steel Ice Cream Mixing Tank / Maturation Tank Jacketed Type
316 304 Stainless Steel Ice Cream Mixing Tank / Maturation Tank Jacketed Type
Specifications
Model Number :
KQ100L to KQ10000L
Certification :
ISO
MOQ :
1Set
Price :
2600USD /Set
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
200 Sets per month
Delivery Time :
20 days after get your advance payment
Packaging Details :
Standard Export Wooden Box .
Name :
316 304 Stainless Steel Maturation Tank / Aging Tank
Capacity :
100L to 30000L
Material :
Sanitary Stainless Steel 304 / 316
Cooling Method :
Cooling by Ice Water .
Application :
Ice Cream Production
Type :
Jacketed type
Speed of mixer :
36RPM ,48RPM ,72RPM,2900RPM .
Motor Brand :
ABB / Siemens / Chinese Brand
Description

316 304 Stainless Steel Maturation Tank Aging Tank For Ice Cream Mixing Tanks

1. Maturation Tank and Aging Tank Instruction :

Electirc steam heating jacketed milk pasteurizer aging Ice Cream mixing Tank

The ice cream mixing aging tank can be heated of cooled according to technological requirements,electric heating are allowed .
Made of food grade SUS304 or SUS316 stainless steel .The tank body and pipe are subjected to mirror polishing .
The stainless steel electric control cabine can completely supervise the operation of equipment, and display such data as temperature and blending rotation speed etc.

Configuration of ice cream mixing tank:


1. Quick open manhole.
2. Various types of CIF cleaners.
3. Thermometer (according to customer requirements).
4. Vertical blender (paddle type or fame type are available if customer require).
5 Jacket (miller board, hollow jacket or coil pipe jacket are available according to customer requirements

2. Technical Parameter :

Model of ice cream mixing aging tank

Volume 300L 400L 500L 600L 800L 1000L 1500L 2000L 3000L
Body diameter(mm) Φ 800 Φ 800 Φ 900 Φ 1000 Φ 1000 Φ 1000 Φ 1200 Φ 1300 Φ 1600
Body height(mm) 600 800 800 800 1000 1220 1220 1500 1500
Motor power(kw) 0.55 0.55 0.55 0.55 0.55 0.75 1.5 2.2 3
Stirring speed(rpm) 36r/min
Working pressure ≤ 0.09Mpa
Working temperature < 100° C
Accessories Thermometer, safety valve, pressure gauge
