Gr11 Gr12 Chromoly Flat Bar Welding Punching Titanium Alloy Rod Ti15333
Gr11 Gr12 Chromoly Flat Bar Welding Punching Titanium Alloy Rod Ti15333
Specifications
Brand Name :
TISCO
Model Number :
201 304 316 317 321 310 309 410 420
Certification :
SGS ISO ROHS
Place of Origin :
Mainland China
MOQ :
100KG
Price :
0.5-1.0 USD PER KG
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
800TONS PER MONTH
Delivery Time :
5-10Days after confirming order
Packaging Details :
Standard Waterproof Package
Product Name :
Titanium Bar
Material :
gr1, gr2, gr3,gr4, gr5,gr7, gr9, gr10
Certificate :
ISO9001:2008
Processing service :
Bending cutting welding punching
Trading term :
CIF CFR FOB EXW
Ti :
99.9%
Application :
Industrial,Medical,industrial and medical,electroplating equipment,Mechanical equipment
MOQ :
100KGS
Shipping :
By Sea, Air
Payment term: :
TT LC
Description

Titanium Gr1, Gr2, Gr4, Gr7, Gr9, Gr11, Gr12 Price Of 1kg Titanium Bar

100% titanium sponge to produce titanium ingot and 3 times melting to ensure the uniformity of chemical composition,quanlity received customer approval.

Test We Done and Test Report :

1) Nondestructive Test 2) UT Testing Detector 3) Tensile Tester
4) Digital Ultrasonic Detector 5) Infrared Tester 6) HV Hardness Tester

Product name

Titanium Gr1, Gr2, Gr4, Gr7, Gr9, Gr11, Gr12 Price Of 1kg Titanium Bar
Standard
ASTM B348,ASTM F67 ASTM F136,AMS 4928
Material
gr1,gr2,gr5(Ti-6Al-4V),gr7,gr9,gr12,gr23,Ti15333
Color
Matal gray; Color can be customized according to material
Feature
Titanium has low weight, excellent high strength, excellent corrosion resistance.
Technique
Radial Forging /Rolling
Application
Industrial,Metallurgy, Medical,Chemical,Petroleum,Aerospace,Deep Engineering
Tolerance
H6~H13, h10~h13
Diameter
Φ6-450mm
Length
≤6000mm
Test
Ultrasonic testing
Surface
Polished surface/peeling surface/machined surface/grinding surface
Packaging
Export Polywood Case and As customer's requirement
Processing Flow
Titanium sponge→3 times VAR melting→Forging→Grind surface→Radial
forging→Straightening→Annealing→Straightening→Machining→Polishing→Inspecting→Packaging→Delivering
Marking as the request
Yes

Product Description

Gr11 Gr12 Chromoly Flat Bar Welding Punching Titanium Alloy Rod Ti15333

Gr11 Gr12 Chromoly Flat Bar Welding Punching Titanium Alloy Rod Ti15333

Chemical Composition

Grade chemical composition, weight percent (%)
C H O N Fe Al V Pd Ni Mo Ti
(≤) (≤) (≤) (≤) (≤) - - - - - bal
GR1 0.08 0.015 0.18 0.03 0.2 - - - - - bal
GR2 0.08 0.015 0.25 0.03 0.3 - - - - - bal
GR4 0.08 0.015 0.25 0.03 0.3 - - - - - bal
GR5 0.08 0.015 0.2 0.05 0.4 5.5~6.75 3.5~4.5 - - - bal
GR7 0.08 0.015 0.25 0.03 0.3 - - 0.12~0.25 0.12~0.25 - bal
GR9 0.08 0.015 0.15 0.03 0.25 2.5~3.5 2.5~3.5 - - - bal
GR11 0.08 0.15 0.18 0.03 0.2 - - 0.12~0.25 - - bal
GR12 0.08 0.15 0.25 0.03 0.3 - - - 0.6~0.9 0.2~0.4 bal
GR23 0.08 0.125 0.13 0.03 0.25 5.5~6.5 3.5~4.5 - - - bal

Physical Properties

Grade Physical properties
Tensile strength Yield strength Elongation in 4D Reduction of Area
Min Min (0.2%, offset) Min (%) Min (%)
ksi MPa ksi MPa
Gr1 35 240 20 138 24 30
Gr2 50 345 40 275 20 30
Gr4 80 550 70 483 15 25
Gr5 130 895 120 828 10 25
Gr7 50 345 40 275 20 30
Gr9 90 620 70 483 15 25
Gr12 70 483 50 345 18 25
Gr23 120 828 110 759 10 15


Packaging & Shipping



Gr11 Gr12 Chromoly Flat Bar Welding Punching Titanium Alloy Rod Ti15333

Certification


Gr11 Gr12 Chromoly Flat Bar Welding Punching Titanium Alloy Rod Ti15333

FAQ


Q1: ARE YOU FACTORY OR TRADER?

A1: Our company is a cold rolling manufacturer of magnetic stainless steel coil since 2009. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.


Q2: WHICH MATERIAL/PRODUCTS YOU CAN PROVIDE?

A2: Stainless Steel Coils / Strips, Stainless Steel Sheets / Plates, Stainless Steel Circles / Discs, Decorative Stainless Steel Sheets.


Q3: HOW TO GET A SAMPLE?

A3: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.


Q4: HOW TO VISIT YOUR FACTORY?

A4: Most of the main cities have flights to Wuxi; you can take flight to Wuxi Shuofang International Airport.

If you come from Shanghai, it will take 2 hours by flight (every day 5 flights).
If you come from Hongkong, it will take 1 hour by flight (every day 1 flight around noon time).
