Specifications
Brand Name :
Delta
Model Number :
CD4MCU
Certification :
ISO 9001
Place of Origin :
China
MOQ :
500 kgs
Price :
4000 - 5500 USD/Ton
Payment Terms :
T/T, Western Union
Supply Ability :
50 Ton per Month
Delivery Time :
5 - 10 days
Packaging Details :
wooden box or water resistant paper surround
Products Name :
CD4MCU Stainless Steel bar
Diameter :
10 - 350mm
Length :
6m or cutting any length as request
Surface :
Pickling or Bright
Service :
Cutting
Standard :
ASTM DIN GB EN
Other products :
round bar, square bar, flat bar.etc
Technique :
hot rolled
Description

CD4MCU Stainless Steel Round Bars Superior Durability & Wear Resistance

Products Specification

Products Name Stainless Steel Round Bar
Grade CD4MCU
Products Diameter Range φ10mm - φ350mm
Length 6.1m/pcs or cutting any length as request
Surface Pickling finishing, bright finishing
Other Grade

304,304L,309S,310S,310H,316L,316Ti,316H,317L,321,329,347,410,420,

430F,431,440A/B/C,2205,2507,904l,254SMO,253MA,CD4MCU,XM-19,17-4PH,15-5PH,17-7PH,C276,600,601,625,718,800,800H,825,926.etc
Standard ASTM JIS,GB,DIN EN
Service Cutting
Other Shape Square , Flat, Hexagonal, Round.etc
Loading Port Shanghai Port
MOQ 500 kgs

CD4MCu is an Fe-Cr-Ni-Cu-Mo alloy with a duplex structure of ferrite and austenite. Moderately high strength and hardness are combined with good ductility and impact properties, resulting in an alloy with superior resistance to abrasion or erosion-corrosion.
CD4MCu provides significantly better stress/corrosive cracking resistance, and less pitting than standard stainless steel. It has a higher strength and thus is more durable.
CD4MCu combines outstanding corrosion resistance with nearly twice the strength of many stainless types. It can be age-hardened to increase its Brinell Hardness Number (BHN). This alloy has proven useful in sulphuric acid environments and seawater applications. It resists abrasive wear and galling, can be readily machined, and is weldable without preheating. This duplex alloy is also known as MTEK 29M.

CD4MCu Duplex Stainless Steel General Information

  • Cast Alloy Designation:CD4MCu
  • Similar designation:DUPLEX 1A
  • Alloy Family:High Alloy / Stainless Steel
  • UNS:J93370
  • ASTM Standard(s):A890
  • Wrought:255
  • Weldability:Good
  • Castability:Good
  • Machinability rating:Good

CD4MCu Duplex Stainless Steel Chemical Composition

Element Content (%)
Chromium, Cr 24.5-26.5
Manganese, Mn 1-3
Nickel, Ni 4.75-6
Silicon, Si 1 max
Nitrogen, N 0.20-0.25
Copper, Cu 2.75-3.25
Molybdenum, Mo 1.75-2.25
Phosphorous, P 0.040 max
Carbon, C 0.040 max
Sulfur, S 0.030 max
Iron, Fe Balance

CD4MCu Duplex Stainless Steel Mechanical Properties

Properties Metric Imperial
Tensile strength (min) 690 MPa 100 ksi
Yield strength (min) 485 MPa 70 ksi
Elongation (min) 16% 16%
Hardness, Brinell (max) 290 290

CD4MCu Duplex Stainless Steel Applications

Superior corrosion and abrasion ability make CD4MCu ideal for varied applications in these industries:
  • Centrifuge and dewatering equipment
  • Couplings
  • Heat exchangers,
  • Ffshore piping systems
  • Paper rolls
  • Pulp digesters
  • Pump and valve components
  • Pressure vessels
  • Sleeves
  • Flanges

CD4MCu Duplex Stainless Steel Benefits

  • Corrosion and pitting resistance
  • Better for abrasive applications
  • Higher strength than standard stainless steel
  • Improved ductility and weldability
  • Better resistance to embrittlement

Available Sizes And Specifications

CD4MCu stainless steel pipe sizes and specifications
Grade CD4MCu
Specification EN, DIN, JIS, ASTM, BS, ASME, AISI, ISO
Standard ASTM A276/ASME SA276, ASTM A479/ASME SA479 & ASTM A164/ASME SA164 .
Stainless steel round Bar Diameter: 2mm - 600mm
Stainless steel bright Bar Diameter: 2mm - 600mm
Stainless steel hex Bar Dimension: 6mm - 80mm
Stainless steel square bar Dimension: 3.0 - 180mm
Stainless steel flat bar Thickness: 0.5mm - 200mm, Width: 1.5mm - 250 mm
Stainless steel angle bar as requirements
Length Normally 6m, or produce as requirements
Surface Black, Bright. Peeled and Polished, Solution annealed.
Delivery condition cold drawn, hot rolled, forged, grinding, centerless grinding
Tolerance H8, H9, H10, H11, H12, H13,K9, K10, K11, K12 or as per clients’ requirements
