CD4MCU Alloy Stainless Steel Bars Ideal for Chemical Marine
CD4MCU Alloy Stainless Steel Bars Ideal for Chemical Marine
CD4MCU Alloy Stainless Steel Bars Ideal for Chemical Marine
CD4MCU Alloy Stainless Steel Bars Ideal for Chemical Marine
CD4MCU Alloy Stainless Steel Bars Ideal for Chemical Marine
CD4MCU Alloy Stainless Steel Bars Ideal for Chemical Marine
CD4MCU Alloy Stainless Steel Bars Ideal for Chemical Marine
CD4MCU Alloy Stainless Steel Bars Ideal for Chemical Marine
Specifications
Brand Name :
Delta
Model Number :
CD4MCU
Certification :
ISO 9001
Place of Origin :
China
MOQ :
500 kgs
Price :
4000 - 5500 USD/Ton
Payment Terms :
T/T, Western Union
Supply Ability :
50 Ton per Month
Delivery Time :
5 - 10 days
Packaging Details :
wooden box or water resistant paper surround
Products Name :
CD4MCU Stainless Steel bar
Diameter :
10 - 350mm
Length :
6m or cutting any length as request
Surface :
Pickling or Bright
Service :
Cutting
Standard :
ASTM DIN GB EN
Other products :
round bar, square bar, flat bar.etc
Technique :
hot rolled
Description

CD4MCU Alloy Stainless Steel Bars Ideal for Chemical & Marine Applications

Products Specification

Products Name Stainless Steel Round Bar
Grade CD4MCU
Products Diameter Range φ10mm - φ350mm
Length 6.1m/pcs or cutting any length as request
Surface Pickling finishing, bright finishing
Other Grade

304,304L,309S,310S,310H,316L,316Ti,316H,317L,321,329,347,410,420,

430F,431,440A/B/C,2205,2507,904l,254SMO,253MA,CD4MCU,XM-19,17-4PH,15-5PH,17-7PH,C276,600,601,625,718,800,800H,825,926.etc
Standard ASTM JIS,GB,DIN EN
Service Cutting
Other Shape Square , Flat, Hexagonal, Round.etc
Loading Port Shanghai Port
MOQ 500 kgs

MATERIAL DATA SHEET - Grade CD4MCu
MATERIAL CATEGORY - Duplex stainless steel - 25Cr-5Ni-2Mo-3Cu
MATERIAL SPECIFICATIONS - ASTM A959 (2004), A276, A312, A632, A176, A580, A564
CHEMICAL COMPOSITION (WEIGHT %)
  • C (％): ≤ 0.04
  • Si (％): ≤ 1.00
  • Mn (％): ≤ 1.00
  • P (％)≤: 0.040
  • S (％)≤: 0.040
  • Ni (％): 4.75 ~ 6.00
  • Cr (％): 24.5 ~ 26.5
  • Mo (％): 1.75 ~ 2.25
  • Cu (%): 2.75 ~ 3.25
MECHANICAL PROPERTIES FINAL HEAT TREATMENT
  • Condition: solution, annealed
  • Tensile strength, σb/MPa: ≥ 689
  • Yield strength, σ0.2/MPa: ≥483
  • Elongation, δ (％): 16.0
  • Reduction of area, ф (％): -
  • Hardness | HRB: 94RB ~ 27RC

Stainless Steel Rod, Bar, Wire, Cold drawn, ground and polished

Standard length of bars: 2 - 3 meter.

Austenitic Stainless Steel for implants, with high corrosion resistance.

According to ISO 5832/1, F-138 Vacuum melt grade (VAR)

For surgical instruments, fracture fixation devices, screws for implants and many more similar applications.

PRODUCT DESCRIPTION
The alloy is usually produced by AOD / VOD /VIM followed by electroslag refining (ESR) / VAR if necessary for special purpose.
Bars and, where applicable, forgings are subjected to ultrasonic examination based on the different levels according to the buyers' requirements.
Bars are usually supplied black/bright in the annealed condition.
Final heat treatment - solution treatment / QT
TYPICAL APPLICATIONS

  • Chemical equipment
  • Mechanical parts used in the condition of corrosion resistance
  • Bolt and nut
  • Pressure vessel
PRODUCT PROFILE & FORMS
  • Round bar / Wire rod (Diameter): 5.5mm to 550mm
  • Square bar / Flat bar: 3mm to 1000mm
  • Plate / Sheet steel / Steel strip: 0.1mm to 1000mm
  • Width: 8mm to 1000mm
  • Length: random length or based on the customer's special requirement.
  • Forged steel shape: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.

CD4MCU Alloy Stainless Steel Bars Ideal for Chemical MarineCD4MCU Alloy Stainless Steel Bars Ideal for Chemical MarineCD4MCU Alloy Stainless Steel Bars Ideal for Chemical MarineCD4MCU Alloy Stainless Steel Bars Ideal for Chemical Marine
