ASTM A240 316 Stainless Steel Plate 6-16mm Thickness
ASTM A240 316 Stainless Steel Plate 6-16mm Thickness
ASTM A240 316 Stainless Steel Plate 6-16mm Thickness
ASTM A240 316 Stainless Steel Plate 6-16mm Thickness
ASTM A240 316 Stainless Steel Plate 6-16mm Thickness
ASTM A240 316 Stainless Steel Plate 6-16mm Thickness
ASTM A240 316 Stainless Steel Plate 6-16mm Thickness
ASTM A240 316 Stainless Steel Plate 6-16mm Thickness
Specifications
Brand Name :
TISCO BAOSTEEL
Model Number :
304 304L 316L 310S 321 2205 2507 904L 254SMO.etc
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
5000 - 7200 USD/Ton
Payment Terms :
T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Stainless Steel Plate
Grade :
304 304L 316L 310S 321 2205 2507 904L 254SMO.etc
Thickness :
0.6 - 30.0mm
Width :
1219mm 1500mm 1800mm 2000mm
Surface :
NO.1 2B
Brand :
BAOSTEEL TISCO
Standard :
ASTM A240/240M
Loading Port :
Shanghai Port
Description

SA240 316 Stainless Steel Plate Sheet 6.0mm 8.0mm 10.0mm 12.0mm 14.0mm 16.0mm Thickness


Products Specification

Products Name 316 Stainless Steel Plate
Main Grades Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 317L, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,654SMO,253MA,2205,2507.etc
Thickness 0.6 - 30.0mm
Width 1250mm,1500mm ,1800mm,2000mm, or custom other size as request
Length 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT
Service Laser Cutting
Form Plate / sheet
Cutting Shape Round , Square, or any special shape as request
Test Certificate Yes.
Finish NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA.
Brand TISCO, LISCO,BAOSTEEL , POSCO, JISCO

316 stainless - steel plate is an austenitic stainless - steel alloy renowned for its excellent corrosion resistance, especially in chloride - containing environments
Here is a detailed introduction:

Parameters

Parameter Value
Carbon (C) content ≤0.08% (for 316); ≤0.03% (for 316L)
Silicon (Si) content ≤1.00%
Manganese (Mn) content ≤2.00%
Phosphorus (P) content ≤0.045%
Sulfur (S) content ≤0.030%
Chromium (Cr) content 16.00 - 18.00%
Nickel (Ni) content 10.00 - 14.00% (for 316); 12.00 - 15.00% (for 316L)
Molybdenum (Mo) content 2.0 - 3.0%
Yield strength (YS) ≥205 Mpa (for 316); ≥175 Mpa (for 316L)
Tensile strength (TS) ≥520 Mpa (for 316); ≥480 Mpa (for 316L)
Elongation (EI) ≥40%
Hardness (Hv) ≤200

Specification316 stainless - steel plates are available in a variety of sizes. The thickness typically ranges from 0.3 mm to 100 mm, the width can be up to 2000 mm, and the length can reach up to 6000 mm.

StandardIt complies with international standards such as ASTM A240 and JIS G4304, ensuring quality and consistency in production.

Similar Grades

Country/Region Grade
USA UNS S31600 (316), UNS S31603 (316L)
Japan SUS316, SUS316L
European Union 4401 (316), 4404 (316L)
China 06Cr17Ni12Mo2 (316), 022Cr17Ni12Mo2 (316L)

Packaging

316 stainless - steel plates are usually packaged in bundles or wrapped with protective materials to prevent scratches and corrosion during transportation and storage. Some may also be packed in wooden cases for better protection, especially for high - value or large - sized plates.

Application

  • Marine industry: Due to its good resistance to seawater corrosion, it is used for shipbuilding, marine platforms, and other marine equipment.

  • Chemical and petrochemical processing: Applied in pressure vessels, storage tanks, heat exchangers, and pipeline systems to withstand corrosive media.
  • Food and beverage processing: Because of its corrosion resistance and hygienic properties, it is suitable for food processing equipment.
  • Medical equipment: Used to manufacture surgical instruments and implants due to its antibacterial properties and corrosion resistance.
  • Pharmaceutical industry: Applied in drug processing equipment to ensure that drugs are not contaminated.
  • Paper and textile industry: Used in processing equipment to resist corrosive media.
