Low Carbon 316L Stainless Steel Thin Strips 0.05-0.5mm Stainless Steel Foil
Low Carbon 316L Stainless Steel Thin Strips 0.05-0.5mm Stainless Steel Foil
Low Carbon 316L Stainless Steel Thin Strips 0.05-0.5mm Stainless Steel Foil
Low Carbon 316L Stainless Steel Thin Strips 0.05-0.5mm Stainless Steel Foil
Low Carbon 316L Stainless Steel Thin Strips 0.05-0.5mm Stainless Steel Foil
Low Carbon 316L Stainless Steel Thin Strips 0.05-0.5mm Stainless Steel Foil
Low Carbon 316L Stainless Steel Thin Strips 0.05-0.5mm Stainless Steel Foil
Low Carbon 316L Stainless Steel Thin Strips 0.05-0.5mm Stainless Steel Foil
Specifications
Brand Name :
TISCO
Model Number :
316L / 1.4404
Certification :
ISO
Place of Origin :
China
MOQ :
2 Ton
Price :
2500 - 3450 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
stainless steel strip
Thickness :
0.5-3.0mm
Width :
within 1500mm
MOQ :
500 kgs
Grade :
200 series 300 series 300 series
Surface :
BA 2B NO.4 HL 8K NO.1
Standard :
ASTM EN GB JIS
Packing :
wooden frame and water proof paper
Description

Low Carbon 316L Stainless Steel Strip Thin Strips 0.05-0.5mm Stainless Steel Foil

Products Specification

Product Name 316L Stainless Steel Strips
Length As required
Width 3mm-1219mm or as required
Thickness 0.15 - 3.0mm or as required
Standard AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique Hot rolled / cold rolled
Surface Treatment 2B or according to customer requirement
Thickness tolerance ±0.01mm
Material 201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 410, 410S,420, 430, 431, 440A,904L,2205,2507
Application It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, ship components.It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen.
MOQ 1tons.We also can accept sample order.
Shipment time Within 15-20 workdays after receiving deposit or L/C
Export packing Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required
Capacity 250,000 tons/year

316L Thin Precision Stainless Steel Strip

Target Industry: Electronics & Micro-Engineering

Key Specifications:

  • Thickness Range: 0.02mm – 0.5mm (20μm – 500μm)

  • Width Tolerance: ±0.01mm (Custom slitting up to 200mm width)

  • Surface Roughness: Ra ≤ 0.1μm (Superior flatness for micro-components)

  • Temper: Extra-Soft Annealed (Hardness: HV 130-150)

  • Flatness: ≤ 0.1mm/m (Laser-leveled for critical alignment)

Enhanced Properties:

✅ Zero Cross Contamination:

  • Processed in dedicated cleanroom facilities (ISO Class 7)

  • Oils/greases replaced with VOC-free volatiles
    ✅ Micro-Edge Quality:

  • Burr-free edges (EFC ≤ 0.005mm) via precision shear cutting

  • Edge cracks eliminated through controlled annealing
    ✅ Stability Under Stress:

  • Consistent CTE (16.5 μm/m·°C) for thermal management substrates

  • Negligible magnetic permeability (<1.02 μ)

Unique Certifications:

  • Traceability: Full lot traceability with embedded laser QR coding
  • Purity: Interstitial Element Control (O ≤ 30ppm, N ≤ 200ppm)
  • Compliance: RoHS 3, REACH, and ISO 13485 (Medical Device Annex)

Applications:

  • Flexible printed circuit board (FPCB) shielding layers
  • Hermetic seals for micro-electromechanical systems (MEMS)
  • Surgical robotic actuator springs
  • Thin-film deposition substrates

Packaging:

  • Vacuum-sealed between static-dissipative PET films
  • Mounted on 300mm anti-telescoping cores
  • Humidity indicator included in nitrogen-flushed drums

Note: Custom passivation (citric acid or nitric acid) available per ASTM A967.
