Specifications
Brand Name :
TISCO BAOSTEEL
Model Number :
316Ti
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
1700- 2000 USD/Ton
Payment Terms :
T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Stainless Steel Plate
Grade :
316Ti
Thickness :
3.0 - 80.0mm
Width :
1500mm 1800mm 2000mm
Surface :
NO.1
Brand :
BAOSTEEL TISCO
Standard :
ASTM A240/240M
Loading Port :
Shanghai Port
Description

316Ti Stainless Steel Plate ASME SA240 Hot Rolled SS Plate S31635 Heat Resistant Steel

Products Specification

Products Name 316Ti Stainless Steel Plate
Main Grades Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,253MA,2205,2507.etc
Thickness 3.0 - 80.0mm
Width 1250mm,1500mm ,1800mm,2000mm, or custom other size as request
Length 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT
Type of Material Laser Cutting
Form Plate / coil
Test Certificate Yes.
Finish NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA.
Brand TISCO, LISCO,BAOSTEEL , POSCO, JISCO

Hot - Rolled 316Ti Stainless Steel Sheet Product Information​
The hot - rolled 316Ti stainless steel sheet is a high - performance material that combines the excellent properties of 316Ti stainless steel with the unique advantages brought by the hot - rolling process. Through high - temperature processing, it features enhanced mechanical properties, improved microstructure, and better formability in large - scale applications. This makes it a preferred choice for a wide range of industrial and construction projects that demand strength, durability, and corrosion resistance.​
1. Key Parameters​
1.1 Chemical Composition​
​
Element​




Content (%)​




Carbon (C)​




≤0.08​




Chromium (Cr)​




16.0 - 18.0​




Nickel (Ni)​




10.0 - 14.0​




Molybdenum (Mo)​




2.0 - 3.0​




Titanium (Ti)​




≥5*C%​




Manganese (Mn)​




≤2.0​




Silicon (Si)​




≤1.0​




Phosphorus (P)​




≤0.045​




Sulfur (S)​




≤0.03​




​
1.2 Mechanical Properties​
  • Tensile Strength: ≥515 MPa​
  • Yield Strength (0.2% offset): ≥205 MPa​
  • Elongation at Break: ≥40%​
  • Hardness (HB): ≤187​
  • Density: 7.98 g/cm³​
The hot - rolling process further refines the grain structure, enhancing the overall mechanical performance and ensuring consistent quality across the sheet.​
2. Similar Grades​
  • ASTM/ASME: S31635​
  • EN/DIN: 1.4571​
  • JIS: SUS316Ti​
These similar grades share comparable chemical compositions and performance characteristics, but slight differences in manufacturing standards and specific application focuses may exist.​
3. Standards​
Our hot - rolled 316Ti stainless steel sheets comply with multiple international and national standards:​
  • ASTM A240/A240M: Specifies requirements for chromium and chromium - nickel stainless - steel plate, sheet, and strip for pressure vessels and for general applications.​
  • EN 10028 - 7: Deals with flat products made of stainless steels for pressure purposes.​
  • GB/T 4237: Chinese standard for hot - rolled stainless steel plates, sheets, and strips.​
  • JIS G4305: Japanese standard for hot - rolled stainless steel plates, sheets, and strips.​
Compliance with these standards ensures the product's reliability, quality, and suitability for various applications worldwide.​
4. In - Stock Specifications​
  • Thickness: 3 - 50 mm​
  • Width: 1000 - 2000 mm​
  • Length: 2000 - 12000 mm​
We maintain a large inventory of hot - rolled 316Ti stainless steel sheets in standard sizes, ready for immediate delivery. Custom sizes can also be produced according to customer requirements, with short lead times.​
5. Packaging Methods​
  • Inner Packaging: Each sheet is protected with a layer of anti - rust paper or plastic film to prevent scratches and rust during transportation and storage.​
  • Outer Packaging: The sheets are bundled together with steel straps and placed on wooden pallets or in steel racks to ensure stability. For large orders, they can be packed in containers to minimize the risk of damage during long - distance transportation.​
6. Applications​
  • Chemical Industry: Ideal for manufacturing chemical reactors, pipelines, storage tanks, and heat exchangers due to its excellent resistance to a wide range of chemicals.​
  • Petroleum and Gas Industry: Used in oil refineries, offshore platforms, and pipelines, where it can withstand harsh environments and corrosive media.​
  • Power Generation: Applied in power plants for components such as boiler parts, condensers, and exhaust systems, thanks to its high - temperature resistance and durability.​
  • Construction and Architecture: Suitable for large - scale building structures, bridges, and architectural facades, providing both strength and aesthetic appeal. The hot - rolled surface texture can also add a unique visual effect to architectural designs.​
  • Mechanical Manufacturing: Used to produce various mechanical parts, such as gears, shafts, and frames, that require high strength, corrosion resistance, and good formability.
