High Quality 254 Smo Uns S31254 Large Diameter Stainless Steel Pipe
High Quality 254 Smo Uns S31254 Large Diameter Stainless Steel Pipe
High Quality 254 Smo Uns S31254 Large Diameter Stainless Steel Pipe
High Quality 254 Smo Uns S31254 Large Diameter Stainless Steel Pipe
High Quality 254 Smo Uns S31254 Large Diameter Stainless Steel Pipe
High Quality 254 Smo Uns S31254 Large Diameter Stainless Steel Pipe
High Quality 254 Smo Uns S31254 Large Diameter Stainless Steel Pipe
High Quality 254 Smo Uns S31254 Large Diameter Stainless Steel Pipe
Specifications
Brand Name :
DELTA
Model Number :
254SMO
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
4650-5760 USD/Ton
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Stainless Steel Pipe
Grade :
254SMO
Standard :
ASTM GB EN
Length :
6m or custom cutting any length as request
Diameter :
DN10 - DN400
Wall thickness :
SCH10 - XXS or unstandard size
Type :
seamless pipe
Service :
cutting, polishing
application :
Industrial
Packing :
wooden box or PP bag
Description

High Quality 254 Smo Uns S31254 Large Diameter Stainless Steel Pipe

Product Name 254SMO Stainless Steel Pipe Ss Pipe
Fabrication Standard ASTM A213/269/312/789
Material Grade TP304 TP316 TP310S SS32750 TP321 TP347L 2507 S32205 254SMo
Out Diameter 1/8" - 24"
Wall Thickness 1.25mm - 80mm
Length <= 18 Mtr
Surface anealling and pickles surface, polishing
Package by piece, in bundles, with external pvc wrapped, wood crated
Minimum Order Quantiy 1 Metric Tons
Our Advantage 1.regular sizes in stock over 2000 tons for immediate delivery
2.small quantity with factory rate
3.quality certificate as per EN10204 3.1b issued by manufacturer
4.expert technical and export/import document consultant and support
5.on-time response by email, skype, website and online messages

High Quality 254 Smo Uns S31254 Large Diameter Stainless Steel Pipe

High Quality 254 Smo Uns S31254 Large Diameter Stainless Steel Pipe We are manufacture of steel products. We have many types of steel products, such as steel plate, steel pipe, steel coil, angle steel, u channel steel, steel rod, flat bar ,steel pipe fittings and so on. About materials, it is divided into carbon, stainless,

Product Details

There are several names for UNS S31254, including 6 moly, 254SMO and NAS 185N. Belonging to the austenitic class of stainless steel, the 6 moly (s31254) is a highly corrosion resistant material. The chemistry of this particular austenitic stainless steel includes high contents of nickel, Chromium, as well as molybdenum. The alloy chemistry was designed in such a manner that the 6% moly stainless steel would demonstrate excellent corrosion resistance, irrespective of their exposure to severe corrosion environments, for instance, elevated temperature seawater.

The most important characteristic of the 254SMO (UNS S31254) is the fact that it provides excellent resistance Pitting Corrosion. This is a fact that can be attested by its high PREN value. The PREN value of 6 moly ss uns n08926 is higher than 42.5.

254 SMO Stainless Steel

  • Material Grade: 254 SMo Super Austenitic Stainless Steel
  • American Grade: UNS S31254
  • DIN/EN Grade: 1.4547
  • Chinese Grade: 00Cr20Ni18Mo6CuN
  • Forging Grade: F44

SMO 254,6MO Stainless Steel Pipe specifications

Trade Name

  • 254 SMO Pipe

  • 6MO Pipe
Grades EN 1.4547 / UNS S31254 (F44).
American Specification

  • ASTM A213 UNS S31254

  • ASME SA 213 UNS S31254
Size range 1/8” to 48”, 6MO Seamless Pipes up to 24”.
Outer Diameter (OD) 0.3mm - 10mm.
Wall Thickness 0.4mm up to 30.00 mm
Pipe Schedules Schedules 5, 10S, 10, 30, 40S, 40, 80, 80S, XS, 160, XXH.
Hardness Soft, Hard, Quarter Hard, Half Hard, Spring Hard etc.
Surface Finishing Bright, Polish & Black
Manufacturer of Fully annealed seamless or welded and drawn alloy (254, 925, 926, AL6XN) hydraulic tubing as per ASTM A269 or ASTM A213

254SMO Tubing sizes

WALL THICKNESS SIZES ( O.D.)
.010 1/16" , 1/8" , 3/16"
.020 1/16" , 1/8" , 3/16" , 1/4" , 5/16" , 3/8"
.012 1/8"
.016 1/8" , 3/16"
.028 1/8" , 3/16" , 1/4" , 5/16" , 3/8" , 1/2" , 3/4" , 1" , 1 1/2" , 2"
.035 1/8" , 3/16" , 1/4" , 5/16" , 3/8" , 7/16" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4"
.049 3/16" , 1/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/8" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4"
.065 1/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 3/4" , 2" , 2 1/2" , 3"
.083 1/4" , 3/8" , 1/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 7/8" , 2" , 2 1/2" ,3"
.095 1/2" , 5/8" , 1" , 1 1/4" , 1 1/2" , 2"
.109 1/2" , 3/4" , 1" , 1 1/4" , 1 1/2" , 2"
.120 1/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 2" , 2 1/4" , 2 1/2" , 3"
.125 3/4" , 1" , 1 1/4" , 1 1/2" , 2" , 3" , 3 1/4"
.134 1"
.250 3"
.375 3 1/2"

Business Terms

  • Packing
  • Common Standard Export-sea Packing : Each bundle is fixed at least three times strips , wrapped with durable PVC material .
  • Special Packing : Covered with film and packed in wooden box .
  • MOQ: 1 Ton
  • Payment Term: 30% advanced T/T payment, the balance before shipment or against copy of B/L
  • Shipment Term : The goods should be loaded with 20ft container or LCL
  • Quality Assurance: Mill Test Certificate is provided, Third Party Inspection is acceptable , Free Sample is available for Testing and welcome to our factory for personal inspection .
