Specifications
Brand Name :
TISCO POSCO BAOSTEEL
Model Number :
2205 / 1.4462 / UNS S32205 / UNS S31803
Certification :
ISO
Place of Origin :
China
MOQ :
1 Ton
Price :
2500-3500 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products Name :
Stainless Steel Plate
Grade :
2205 / 1.4462 / UNS S32205 / UNS S31803
Thickness :
0.6-30.0mm
Standard :
ASTM EN GB
Width :
1000mm 1219mm 1500mm
Surface :
2B NO.1
Brand :
TISCO BAOSTEEL
MOQ :
1 Ton
Description

Duplex 2205 Stainless Steel Sheet Plate Coils EN 10204-3.1 Standard Size 4ft*8ft 5ft*10ft 5ft*20ft

Products Specification

Item Alloy 2205 duplex stainless steel plate
Standard ASTM A240,GB/T3280-2007,JIS4304-2005,ASTM A167,EN10088-2-2005,etc
Surface

2B,2D,BA,NO.1,NO.4,NO.8,8K,mirror ,brushcheckered ,embossed,hair line,

sand blast,etching,etc
Thickness 0.1~200mm
Width 1000mm,1219mm,1500mm,1800mm,2000mm,etc
Length 2000mm,2440mm,3000mm,5800mm,6000mm,etc
Package Standard export package,suit for all kinds of transport,or as required.
Price term Ex-Work,FOB,CNF,CFR,CIF,FCA,DDP,DDU,etc
Payment term TT,L/C,Western Union

Standard Size of our 2205 Duplex Stainless Steel Plate in Stock

Cold Rolled 2205 duplex stainless steel sheet
0.4*1219*2438mm 0.5*1219*2438mm 0.6*1219*2438mm 0.8*1219*2438mm 1.0*1219*2438mm
1.2*1219*2438mm 1.5*1219*2438mm 2.0*1219*2438mm 2.5*1219*2438mm 3.0*1219*2438mm
Hot Rolled 2205 duplex stainless steel plate
3.0*1500*6000mm 4.0*1500*6000mm 5.0*1500*6000mm 6.0*1500*6000mm 8.0*1500*6000mm
10.0*1500*6000mm 12.0*1500*6000mm 14.0*1500*6000mm 16.0*1500*6000mm 20.0*1500*6000mm
6.0*2000*6000mm 8.0*2000*6000mm 10.0*2000*6000mm 12.0*2000*6000mm 14.0*2000*6000mm
16.0*2000*6000mm

Chemical Composition (%) Of 2205 Duplex Stainless Steel Sheet

Chemical Composition (%)
Grade C, max Mn, max P, max S, max Si, max Cr Ni Mo N
S31803 0.03 2.00 0.030 0.020 1.00 21.00-23.00 4.50-6.50 2.50-3.50 0.08-0.20
S32205 0.03 2.00 0.030 0.020 1.00 22.00-23.00 4.50-6.50 3.00-3.50 0.14-0.20

Mechanical Properties Of 2205 Duplex Stainless Steel Sheet

Mechanical Properties
Tensile Strength, ksi [MPa], min Yield Strength, ksi [MPa], min Elongation (%), min Hardness, max
90 [620] 65 [450] 25 217 HB

Physical Properties Of 2205 Duplex Stainless Steel Sheet

Physical Properties
Density Melting Point Modulus of Elasticity Poisson's Ratio Coefficient of Thermal Expansion Thermal Conductivity Electrical Conductivity
7.80 g/cm³ 1300-1390℃ 200 GPa 0.27 13 μm/m·K 15 W/m·K 2.2% IACS

Heat Treatment Of 2205 Duplex Stainless Steel Sheet

- Annealing temperatures range from 1868 to 2012 °F (1020 to 1100 °C).

- Cannot be hardened by heat treatment, but duplex 2205 can be work hardened.

Features Of 2205 Duplex Stainless Steel Sheet

Compared with other stainless steel materials, SS2205 represents higher strength and better corrosion resistance. This is because the amount of ferrite and austenite in duplex stainless steel can be controlled by adjusting the chemical composition and the process of heat treatment. Therefore, duplex stainless steel can achieve the best mechanical properties and corrosion resistance.

- High strength

- Excellent impact toughness

- Excellent stress corrosion resistance

- Excellent corrosion fatigue strength

- Good weldability

- Good mechanical machinability

- Good plasticity

Applications Of 2205 Duplex Stainless Steel Sheet

Widely used in chemical industry, offshore engineering, oil and gas industry, etc, UNS S32205 sheet is mainly used for various equipment and pipeline systems in these industries. In addition, duplex stainless steel can be used to make chemical equipment, power generation equipment and pharmaceutical equipment.

Another advantage of UNS S32205 sheet is that it is much cheaper than other stainless steel materials with high strength and toughness. It's been that way because the production cost of duplex stainless steel is relatively low. As a result, this kind of steel has been extensively utilized in many fields which require materials with higher strength, higher corrosion resistance and lower cost.

- Petroleum platform

- Bridge construction

- Heat exchangers

- Pumps and valves

- Pressure vessels

- Food processing equipment

- Wastewater treatment systems

Equivalent Grades Of 2205 Duplex Stainles Steel Sheet
ASTM UNS WERKSTOFF NR. EN GB
SS2205 S32205/S31803 1.4462 X2CrNiMoN 22-5-3 022Cr23Ni5Mo3N
