Specifications
MOQ :
1 Ton
Price :
US $750-1,150 / Ton
Model NO. :
DC01 1.0330
Edge :
Slit edge
Specification :
1220*2440, 1500*3000, 1500*6000, 2000*6000mm
Grade :
DC01
Number :
1.0330
Classification :
Non-alloy quality steel
Standard :
EN 10130: 2006, EN 10139: 1997, EN 10152: 2009, EN 10271: 1999
Carbon content :
max 0.12%
Manganese content :
max 0.6%
Phosphorus content :
max 0.045%
Sulfur content :
max 0.045%
Tensile strength :
270-410 MPa
Yield strength :
280 MPa
Elongation (Lo=80mm) :
28%
Elongation (Lo=5.65√So) :
32%
Description
DC01 1.0330 EN 10152:2009 Electrolytically Zinc Coated Cold Rolled Steel Coil
Product Specifications
Grade: DC01
Number: 1.0330
Classification: Non-alloy quality steel
Standards: EN 10130:2006 - Cold rolled low carbon steel flat products for cold forming
EN 10139:1997 - Cold rolled uncoated mild steel narrow strip for cold forming
EN 10152:2009 - Electrolytically zinc coated cold rolled steel flat products for cold forming
EN 10271:1999 - Electrolytically zinc-nickel (ZN) coated steel flat products
Chemical Composition % (EN 10130-2006)
Unless otherwise agreed, this grade may be supplied as alloy steel (for example with boron or titanium)
Element Maximum %
C (Carbon) 0.12
Mn (Manganese) 0.6
P (Phosphorus) 0.045
S (Sulfur) 0.045
Mechanical Properties
Property Value
Rm - Tensile Strength (MPa) 270-410
ReH - Minimum Yield Strength (MPa) 280
A - Min. Elongation Lo = 80 mm (%) 28
A - Min. Elongation Lo = 5,65 √ So (%) (+A) 32
Vickers Hardness (HV) (+A) 105
Equivalent Grades
Warning! Only for reference
EU EN USA Germany DIN,Wnr Japan JIS France AFNOR England BS
DC01 SAE1008
SAE1010		 FeP01
St12		 SPCC C
F12
FeP01		 CR4
FeP01
European Old EN Italy UNI Spain UNE China GB Sweden SS Other Standards
FeP01 FeP01 AP00 08
08F		 1142 Various international equivalents available
