ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
Specifications
MOQ :
1 Ton
Price :
US $630-1,120 / Ton
Model Number :
A-500
Section Shape :
Square
Side Length Range :
30*30mm-400*600mm
Wall Thickness :
0.5mm-25mm
Length :
5m-12.5m
Material Grades :
Q195-Q235, Q345, 20#, AlloySteelST37-2, ST52-3, S235, S355
Standards :
JISG 3466, DIN EN 10210, DIN EN10219, ASTM A500, GB/T 3094-2000, GB/T 6728-2002
Surface Treatment :
Black
Packing :
In bundles with strong steel strips
Surface Protection :
Oiled or black painted
Production Capacity :
500000kgs
Square Pipe Sizes :
30*30 to 400*400mm
Rectangle Pipe Sizes :
60*20 to 600*400mm
Thickness Range :
2-25mm
End Options :
Bevelled or square cut
Description
Steel Square Tube ASTM A-500 100 X 50 X T3.0mm Square Pipe
High-quality carbon steel square and rectangular pipes manufactured to international standards for various industrial applications.
Product Specifications
  • Square Pipe Dimensions: OD F10×10 to 600×600mm, Wall Thickness: 0.5mm-25mm
  • Rectangle Pipe Dimensions: OD J10×15 to 600×550mm, Wall Thickness: 0.5mm-25mm
  • Standard Length: 5m-12.5m (custom lengths available)
  • Material Grades: Q195-Q235, Q345, 20#, Alloy Steel ST37-2, ST52-3, S235, S355
  • Standards Compliance: GB/T6728-2002, GB/T6725-2002, GBT3094-2000, JG 178-2005, ASTM A500, JIS G3466, EN10210
Key Features
  • Available in square and rectangular profiles
  • Multiple material grades for different strength requirements
  • Comprehensive international standards compliance
  • Surface treatment: oiled or black painted for rust prevention
  • Professional packaging in bundles with steel straps
  • Ends available beveled or square cut with optional capping
  • OEM manufacturing available
  • Certifications: CE, CCS, FPC
Applications
Construction structures, machinery manufacturing, container fabrication, hall structures, offshore oil fields, sea trestles, motorcar chassis, airport structures, shipbuilding, automobile axle pipes, and various industrial applications.
Standard Size Specifications
Normal Size Square Tubes
Diameter (mm) Thickness (mm) Diameter (mm) Thickness (mm) Diameter (mm) Thickness (mm)
30×302-4120×1202-14250×2508-25
40×402-4125×1252-14255×2558-25
50×502-5130×1302-14258×2588-25
60×602-5135×1358-14260×2608-25
70×702-5140×1408-20280×2808-25
75×752-5150×1508-22300×3009-25
80×802-8160×1608-22350×3509-25
90×902-9180×1808-22360×3609-25
100×1002-14200×2008-25400×4009-25
110×1102-14220×2208-25
115×1152-14240×2408-25
Normal Size Rectangular Tubes
Diameter (mm) Thickness (mm) Diameter (mm) Thickness (mm) Diameter (mm) Thickness (mm)
60×202-380×402-6110×605-8
60×302-390×402-6110×705-10
60×402-690×502-6120×605-8
70×202-3100×202-4120×805-10
70×302-3100×302-4120×1005-14
70×402-6100×402-4125×905-10
70×502-6100×502-6125×1005-14
75×452-6100×804-9130×1205-14
140×805-6,8-14
Large Size Tubes
Diameter (mm) Thickness (mm) Diameter (mm) Thickness (mm) Diameter (mm) Thickness (mm)
180×1005-14300×2007-25400×2507-20
200×1006-18300×2507-25400×3007-25
200×1505-6,8-25320×2007-25420×3507-25
250×1005-14350×1007-18450×1507-18
250×2006-25350×2007-25450×2507-22
250×2256-25350×2507-25500×3007-25
300×1007-18350×3007-25600×2007-18
300×1507-18400×2007-18600×4008-25
Product Gallery
ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery ASTM A-500 Steel Square Tube 100 X 50 X T3.0mm with Black Surface Treatment for Construction and Machinery
