Specifications
MOQ :
1 Ton
Price :
US $680-1,150 / Ton
Outer Diameter :
6-630mm
Surface Treatment :
Black
Material :
Carbon Steel and Alloy Steel
Production Capacity :
50000kgs
Cold Drawn Tolerance :
+/-0.1mm
Cold Rolled Tolerance :
+/-0.05mm
Tensile Strength :
≥415-570 Mpa
Yield Strength :
≥245-485 Mpa
Carbon Content :
≤0.28
Manganese Content :
≤1.20-1.40
Chromium Content :
≤0.50
Molybdenum Content :
≤0.15
Phosphorus Content :
≤0.030
Sulfur Content :
≤0.030
Nickel Content :
≤0.50
Description
Seamless Pipe API 5L/ASTM A106/ASTM A53 Carbon Steel Pipe
Product Overview
High-precision seamless steel pipes manufactured through cold rolled and cold drawn processes for demanding industrial applications.
Product Name Seamless steel pipe
Material Carbon Steel and Alloy Steel
Surface Oiled, Polished, Brightness, Metallic color
Standards ASTM A106 A53 A192 A179 A210 A519, DIN17175 1629 2391, EN10216-1 10216-2 10305-1
Grades St35, St45, St52, E215, E235, E355, sch10, sch20, A106, A179, A192, A210, T11, T22, T12, AISI4130, SAE1010, SAE1020
Manufacturing Process Cold rolled and Cold drawn
Size Range OD: 8mm-100mm, WT: 1-8mm
Length Customized
Tolerance Cold drawn pipe: +/-0.1mm, Cold rolled pipe: +/-0.05mm
Applications Gas spring, Shock absorber, Cylinder and other high precision areas
Seamless Pipe Applications
Seamless steel pipes are manufactured through hot rolled and cold drawn technologies, with hot rolled pipes offering superior strength. These pipes are essential for various industrial applications including:
  • Steam pipeline systems
  • Gas pipeline networks
  • Liquefied gas pipeline infrastructure
  • Natural gas pipelines
  • Petroleum product transportation
  • Various other gas and liquid conveyance systems
Technical Specifications
Standard Steel Grade Chemical Components Mechanical Properties
API Spec 5L PSL1 B C≤0.28, Mn≤1.20, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 Tensile: ≥415 MPa, Yield: ≥245 MPa
X42 C≤0.28, Mn≤1.30, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 Tensile: ≥415 MPa, Yield: ≥290 MPa
X46 C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 Tensile: ≥435 MPa, Yield: ≥320 MPa
X52 C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 Tensile: ≥460 MPa, Yield: ≥360 MPa
X56 C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 Tensile: ≥490 MPa, Yield: ≥390 MPa
X60 C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 Tensile: ≥520 MPa, Yield: ≥415 MPa
X65 C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 Tensile: ≥535 MPa, Yield: ≥450 MPa
X70 C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 Tensile: ≥570 MPa, Yield: ≥485 MPa
