Cold Drawn ASTM A179 Seamless Steel Tube High Temperature Resistant Boiler Tube OD 6-630mm
Cold Drawn ASTM A179 Seamless Steel Tube High Temperature Resistant Boiler Tube OD 6-630mm
Specifications
MOQ :
1 Ton
Price :
US $630-1,130 / Ton
Outer diameter :
6-630mm
Wall thickness :
0.5-15mm
Length :
max 25m
Section shape :
Round
Surface treatment :
Black
Material grade :
A179, St35, St45, St52, E215, E235, E355
Delivery condition :
BK, BKW, BKS, GBK, NBK
Tensile strength :
340-630 Mpa
Yield strength :
215-450 Mpa
Elongation :
4-30%
Chemical composition C :
0.10-0.22%
Chemical composition Si :
0.05-0.55%
Chemical composition Mn :
0.40-1.60%
Chemical composition P :
0.025% max
Chemical composition S :
0.025% max
Description
Boiler Steel Seamless Tube ASTM A179 SA210C
ASTM A179 Steel Boiler Tubes - Seamless Steel Pipe SA210C Seamless Boiler Steel Pipe. Cold Drawn Seamless Steel Pipe Precision Carbon Steel Tube DIN2391 EN10305 ST37 ST52.
Product Specifications
  • Standards: ASTM / DIN / EN / GOST / SAE / JIS etc
  • Material Grade: Carbon Steel / Alloy Steel or according to requirements
  • Size: OD: 19.05 mm, WT: 2.11 mm, Length: max 25m
  • Type: Cold Drawn or ERW
  • Ends: Plain ends or bevel ends
  • Delivery Conditions: BK, BKS, BKW, NBK, GBK (As drawn, quenched and tempered, normalized, annealed, stress-relieved)
  • Coating: Black painting, anti-rust oiled or varnish, customized as required
Factory Testing & Quality Assurance
  • Hydrostatic or Nondestructive Electric Test
  • Heat Treatment according to standard
  • Surface Condition according to standard
  • Grain Size according to standard
  • Sampling: flattening, flaring, grain size, marking
  • Additional services: bevel end, plastic cap, varnish coating, oiled or black painted rust prevention
Main Specification Details
Name Cold drawn or ERW straight steel tubes and pipes for heat exchanger
Standard Meet or exceed ASTM, ASME, API, ANSI and DIN standards including ASTM A106/A179/A192/A210/A213/A519, DIN2391/DIN17175/EN10305, GB8162/GB8163/GB3639
Material A179, St35, St45, St52, E215, E235, E355, 10, 20, A106, A179, A192, A210, T11, T22, T12 etc
Size Outer diameter: 6-114.0mm, Wall thickness: 0.5-15mm, Length: max 2400mm (generally 6000mm)
Application Cold drawn or cold rolled precision seamless steel tubes for hydraulic pressure and pneumatic services, auto use, machinery use, oil cylinder tube, motorcycle shock reducer use, auto shock reducer inner cylinder, seamless steel pipes for low and medium pressure boiler, high pressure boiler, ship-building, liquid service, petroleum cracking, chemical fertilizer equipment, drawing-oil-equipment and structure purposes
Key Characteristics
  • No oxidation layer on outer and inner walls
  • No leakage under high pressure
  • No crack under flating and flattening
  • No distortion after cold bending
  • High precision and high cleanness
  • Excellent brightness cold drawn and hot finished
  • Superior performance for high pressure and temperature uses
  • Black finish and hot dip galvanized options
  • Excellent corrosion resistance
Delivery Conditions
Designation Symbol Description
Cold finished (hard) BK Tubes do not undergo heat treatment following final cold forming, providing high resistance to deformation
Cold finished (soft) BKW Final heat treatment followed by cold drawing with limited deformation, allowing certain cold forming
Cold finished and stress-relieved BKS Heat treatment applied after last cold forming process, enabling forming and machining
Annealed GBK Last cold forming process followed by annealing in controlled atmosphere
Normalized NBK Last cold forming process followed by annealing above upper transformation point in controlled atmosphere
International Standards Compatibility
Chinese Standard Steel Grade American Standard Steel Grade
GB5310 20G,15MoG,12CrMoG,12Cr2MoG,15CrMoG,12Cr1MoVG ASTM A106 GR. A,B,C
GB9948 10,20,12CrMo,15CMo ASTM A53 GR.A,B
GB3087 10,20 ASTM A192, A179, A210, A333, A334, A209 A-1,C / GR.1,GR3,GR6 / T1, Ta, Tb
Applications
  • Evaporator, heat exchangers, condensers, heat transfer equipment and similar pipes
  • Mechanical treatment field, petrochemical industry, transport and construction
  • Ordinary structural purposes and mechanic structural purposes in construction field, fulcrum bearing
  • Transportation of fluids in projects and big equipment (water, oil, gas)
  • Low and medium pressure boiler fluid transportation (steam tube, big smoke tube, small smoke tube, generating tube)
Competitive Advantage
Asia's leading steel pipe & tube manufacturer with production capacity exceeding 250,000 tons/year. Over 60% of products shipped to more than 35 countries worldwide. We manufacture quality pipes & tubes with reasonable and competitive pricing while maintaining excellent quality standards for global customers.
