Specifications
MOQ :
500 kg
Price :
US $7.1-7.9 / kg
Model NO. :
CuZn36
Shape :
Round
Diameter :
4 - 200mm
Other Shape :
Hexagonal, Flat
Density :
8.5g/cm3
Hardness :
1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard,soft
Length :
500-6000mm
Chemical Composition :
Cu: 63.00-68.50%, Fe max: 0.07%, Pb max: 0.09%, Zn: Rest
Tensile Strength :
48 [331] ksi [MPa]
Yield Strength :
116 [110] ksi [MPa]
Elongation :
65%
Shear Strength :
34 [234] ksi [MPa]
Thermal Conductivity :
120 W/m-K
Poisson's Ratio :
0.31
Elastic Modulus :
110 GPa
Description
C27000 Brass Round Bar Specifications
Product Overview
CuZn36 / 2.0336 / C27000 Brass Round Bar available in 2-6 meter lengths, manufactured to ASTM and EN standards.
Product Types: Brass Bar, Brass Rod, Brass Shaft, Brass Stick
Standards: ASTM, AISI, EN, BS, JIS, GB/T, BSI, AS/NZS, ISO
Available Materials: H96, H90, H85, H80, H70, H68, H65, H63, H62, H60, C21000, C22000, C23000, C24000, C26000, C26800, C27000, C27200, C28000, C35000
Surface Finish: Mill, polished, bright, oiled, or as required
Density: 8.5 g/cm³
Diameter Range: 1-200mm
Hardness Options: 1/16 hard, 1/8 hard, 3/8 hard, 1/4 hard, 1/2 hard, full hard, soft
Shapes: Square, Rectangular, Round
Length: 500-6000mm, or as required
Packaging & Shipping
Packaging: Standard sea-worthy package, fixed by belt then loaded into fumigated wooden box
Container Sizes:
- 20GP: 2.352m (width) × 2.385m (height) × 5.90m (inside length)
- 40GP: 2.352m (width) × 2.385m (height) × 11.8m (inside length)
- 40HQ: 2.352m (width) × 2.69m (width) × 5.90m (inside length)
Export Regions: Global coverage including Americas, Europe, Asia, Middle East, Australia
Ports of Shipment: Tianjin Xingang, Qingdao, Shanghai, Ningbo, Guangzhou
Material Properties
Chemical Composition (%) - C27000 Brass
Material Cu Fe, max Pb, max Zn
C27000 63.00-68.50 0.07 0.09 Rest
Mechanical Properties
Tensile Strength, ksi [MPa], min Yield Strength, ksi [MPa], min Elongation (%), min Shear Strength, ksi [MPa]
48 [331] 116 [110] 65 34 [234]
Physical Properties
Density Thermal Expansion Thermal Conductivity Poisson's Ratio Elastic Modulus
8.1 g/cm³ 0 µm/m-K 120 W/m-K 0.31 110 GPa
Equivalent Grades
ASTM BS EN JIS DIN ISO IS
C27000 CZ107 CW507L H3250(92) C2700 BE 2.0335 CuZn36 IS 2704 CuZn35
Key Features
  • High flexibility and excellent cold workability
  • Good hot formability and high durability
  • Superior corrosion resistance
  • Unusual wear resistance
  • High property levels and yield strength
  • High hardness values
Applications
  • Aviation, aerospace, and shipbuilding industries
  • Electrical and industrial equipment
  • Oil and gas pipelines
  • Chemical processing plants
  • Power generation facilities
  • Pulp and paper industry
  • Energy industry applications
  • Dairy and food processing equipment
