Specifications
Certification :
AISI
MOQ :
50 kg
Price :
US $2.35-4.85 / kg
Model NO. :
321
Shape :
Flat
Technique :
Cold Rolled
Surface Treatment :
Bright
Thickness :
10.0mm - 150.0mm
Width :
500-2000mm
Length :
1000-6000mm
Surface :
No.1 / No.4 / BA / 2B/HL/mirror/polished/brushed
Carbon Content :
0.08 max
Manganese Content :
2.00 max
Silicon Content :
0.75 max
Chromium Content :
17.0 - 19.0
Nickel Content :
9.0 - 12.0
Titanium Content :
5(C+N) - 0.70
Max Temperature :
1650°F
Description
AISI 321 Stainless Steel Plates, Sheets, Strips & Coils
UNS S32100, 1.4541, SUS 321 Grade Stainless Steel Products
Product Specifications
Material: Original Type 321 Stainless Steel Plate
Thickness: 10.0mm - 150.0mm
Services: Waterjet Cutting, Laser Cutting
Surface Finish: Hot Rolled NO.1
Brands: TISCO, BAOSTEEL
Detailed Product Specifications
Commodity321 Stainless Steel Plate
Main Grades201, 202, 304, 304L, 316, 316L, 317L, 310S, 321, 904L, 410, 430, 2205, 2507, 904L
BrandTISCO, BAOSTEEL, POSCO, JISCO, LISCO
CertificationSGS, BV, IQI, TUV, ISO, etc.
Thickness10.0-150mm or as customer's requirement
Width500-2000mm or as customer's requirement
Length1000-6000mm or as customer's requirement
SurfaceNo.1 / No.4 / BA / 2B / HL / Mirror / Polished / Brushed
StandardJIS, AISI, ASTM, GB, DIN
Delivery TimeApproximately 10 days
MOQ1 Ton
AdvantagesSuperior quality appearance, wear resistant, strong corrosion resistance, decorative effect, durable and aesthetically pleasing
About 321 Stainless Steel
Titanium-bearing stainless steels are stabilized against carbide precipitation and designed for operation within the damaging temperature range where carbide precipitation develops. In this type of steel, the carbon combines preferentially with titanium to form harmless titanium carbide, leaving the chromium in solution to maintain full corrosion resistance. Type 321 is basic type 304 modified by adding titanium in an amount at least 5 times the carbon plus nitrogen contents.
Chemical Composition of 321 Stainless Steel
ElementMinMax
C-0.08
Mn-2.00
Si-0.75
P-0.045
S-0.030
Cr17.019.0
Mo--
Ni9.012.0
N-0.10
OtherTi = 5(C+N) min, 0.70 max
Key Features of 321 Stainless Steel
  • Immune to intergranular corrosion when heated within the carbide precipitation range
  • Titanium addition eliminates chromium carbide formation at grain boundaries
  • Superior high temperature properties compared to 304 or 304L grades
  • Suitable for intermittent heating up to 1500°F, continuous service to 1650°F
  • May be susceptible to chloride stress cracking
  • Excellent weldability in field applications
  • Type 321H has higher carbon content for improved high temperature creep properties
Common Applications
  • Aircraft exhaust manifolds
  • Expansion joints and bellows
  • Furnace parts and heating element tubing
  • Heat exchangers
  • Woven or welded screens for high temperature mineral processing
  • Spiral welded tube for burner pipes and flues
Technical Background
Grades 321 and 347 are basic austenitic 18/8 steels (Grade 304) stabilized by Titanium (321) or Niobium (347) additions. These grades resist intergranular corrosion after heating within the carbide precipitation range of 425-850°C. Grade 321 is ideal for applications up to 900°C, combining high strength, scaling resistance, phase stability, and subsequent aqueous corrosion resistance.
Grade 321H is a modification with higher carbon content for improved high temperature strength. While 321 has excellent forming and welding characteristics with outstanding toughness even at cryogenic temperatures, it does not polish well and is not recommended for decorative applications.
Alternative Grade Comparison
Alternative GradeSelection Criteria
304LWhen requirement is for intergranular corrosion resistance without high temperature strength needs
3CR12For mild high temperature environments up to approximately 600°C
304HFor mild high temperature environments up to approximately 800°C
310For operating environments up to approximately 1100°C
S30815 (253MA)For operating environments up to approximately 1150°C
