Specifications
MOQ :
30 kg
Price :
US $2.06-3.75 / kg
Shape :
U Channel
Technique :
Hot Rolled
Surface Treatment :
Pickling
Angle Bar Size :
30*30*3 - 200*200*10mm * 6m length
Channel Bar Size :
50*30*3 - 200*100*10mm * 6m length
Grade :
201 304 310S 316L 321 2205
Standard :
ASTM GB DIN
Angle Bar Thickness :
3mm - 10mm
Channel Bar Thickness :
3mm - 12mm
Angle Bar Weight :
0.894kg/m - 15.0kg/m
Channel Bar Weight :
1.79kg/m - 35.8kg/m
Length :
6m
Material :
Stainless Steel
Angle Bar Dimensions :
20×20mm - 100×100mm
Channel Bar Dimensions :
40×20mm - 200×100mm
Description
Stainless Steel Angle Bars & Channel Bars
High-quality wholesale 304 and 316 stainless steel angle bars and channel bars available in various grades and sizes for industrial applications.
Product Specifications
  • Product Name: Stainless Steel Angle Bar / Stainless Steel Channel Bar
  • Grades Available: 201, 304, 310S, 316L, 321, 2205, etc.
  • Standards: ASTM, GB, DIN
  • Angle Bar Size Range: 30×30×3mm to 200×200×10mm × 6m length
  • Channel Bar Size Range: 50×30×3mm to 200×100×10mm × 6m length
  • Services: Custom cutting available
  • Packing: Waterproof paper wrapping or wooden pallets
  • Brand: TSINGSHAN
Stainless Steel Angle Bar Specifications
Size A×B (mm) 3mm 4mm 5mm 6mm 7mm 8mm 9mm 10mm
20×200.8941.131.38
25×251.131.451.772.06
30×301.371.772.172.53
35×351.612.092.573.01
40×401.852.412.973.49
45×452.122.763.404.00
50×502.363.073.794.465.135.766.427.06
60×604.585.426.247.03
63×635.035.956.847.718.609.48
70×705.426.427.398.349.3110.3
75×755.826.897.958.9710.011.1
80×807.378.509.6110.711.8
90×908.339.6511.9012.213.4
100×1009.2810.812.2013.615.0
*Weight shown in kg per meter
Stainless Steel Channel Bar Specifications
Size H×B (mm) 3mm 4mm 5mm 6mm 7mm 8mm 9mm 10mm 12mm
40×201.79
50×252.27
60×302.743.564.375.12
70×353.234.215.176.08
80×403.714.845.967.03
90×454.255.556.838.05
100×504.736.187.628.9810.311.713.041.2
120×609.2010.912.614.2
130×6510.111.913.815.517.319.1
140×7012.914.916.818.820.7
150×7513.916.018.120.222.226.3
160×8014.817.119.321.623.828.1
180×9016.719.422.024.527.032.0
200×10018.621.624.527.430.235.8
*Weight shown in kg per meter
About Our Company
Our company is a comprehensive stainless steel enterprise specializing in material wholesale, processing, storage, and distribution. Located in Wuxi, the stainless steel trading center, we have a total investment of 10 million yuan with annual sales exceeding 300 million yuan.
We maintain long-term, stable cooperative relationships with renowned steel mills including Taiyuan, East, Zhang Pu, Hongxing, Zhejiang Qingshan, and others. We also distribute imported stainless steel plates from Sweden, North America, South Africa, Japan, Korea, and other regions.
Material Range
Our product portfolio includes 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205-904L and other materials covering high-temperature resistant stainless steel series, duplex stainless steel series, and super stainless steel series.
Processing Capabilities
  • Plasma cutting machines
  • Coil material opening equipment
  • Laser cutting machines
  • 8K mirror finishing
  • Grinding and wire drawing
  • Film and titanium plating equipment
Specialized Services
We specialize in thick plate zero cutting, cutting rounds, squares, and shaped components. Our capabilities extend to casting parts, forging parts, with product thickness up to 150MM. All special materials and specifications can be customized according to customer requirements.
Our materials are widely used in machinery, chemical, petroleum, boiler, heat exchanger, food machinery, beverage machinery, medical equipment, and other industries.
304 316 Stainless Steel Angle Bar Hot Rolled 30*30-100*100mm Stainless Steel Channel Bar 304 316 Stainless Steel Angle Bar Hot Rolled 30*30-100*100mm Stainless Steel Channel Bar 304 316 Stainless Steel Angle Bar Hot Rolled 30*30-100*100mm Stainless Steel Channel Bar
Product Gallery
304 316 Stainless Steel Angle Bar Hot Rolled 30*30-100*100mm Stainless Steel Channel Bar 304 316 Stainless Steel Angle Bar Hot Rolled 30*30-100*100mm Stainless Steel Channel Bar 304 316 Stainless Steel Angle Bar Hot Rolled 30*30-100*100mm Stainless Steel Channel Bar 304 316 Stainless Steel Angle Bar Hot Rolled 30*30-100*100mm Stainless Steel Channel Bar 304 316 Stainless Steel Angle Bar Hot Rolled 30*30-100*100mm Stainless Steel Channel Bar
Applications
304 316 Stainless Steel Angle Bar Hot Rolled 30*30-100*100mm Stainless Steel Channel Bar
Stainless steel angle bars and channel bars are primarily used for frame structures including:
  • High-voltage power transmission towers
  • Frame structures on both sides of main beams in steel bridge construction
  • Columns and booms of tower cranes on construction sites
  • Columns and beams in workshop structures
  • Air-conditioning and solar-powered shelf supports under windows
Widely applied in building structures and engineering construction such as house beams, ship beams, industrial furnaces, and various industrial applications across multiple sectors.
