Specifications
MOQ :
30 kg
Price :
US $1.48-2.52 / kg
Model Number :
201 304 316L 310S 2205
Shape :
Angle
Technique :
Hot Rolled
Surface Treatment :
Bright
Specification :
30*30-100*100
Grade :
201 304 310S 316L 321 2205
Standard :
ASTM GB DIN
Angle Bar Size :
30*30*3 - 200*200*10mm * 6m length
Channel Bar Size :
50*30*3 - 200*100*10mm * 6m length
Thickness Range :
3mm - 12mm
Weight per Meter :
0.894kg - 35.8kg
Length :
6m
Packing :
Waterproof paper or wooden pallets
Material :
Stainless Steel
Processing Service :
Cutting
Description
Hot Rolled Stainless Steel Angle & Channel Bars
Premium quality hot rolled 201 and 304 stainless steel angle bars and equal angle stainless steel bars from trusted supplier.
Product Specifications
  • Product Name: Stainless Steel Angle Bar / Stainless Steel Channel Bar
  • Grades: 201, 304, 310S, 316L, 321, 2205, etc.
  • Standards: ASTM, GB, DIN
  • Angle Bar Size: 30×30×3 - 200×200×10mm × 6m length
  • Channel Bar Size: 50×30×3 - 200×100×10mm × 6m length
  • Service: Cutting
  • Packing: Waterproof paper surround or wooden pallets
  • Brand: TSINGSHAN
Stainless Steel Angle Bar - Standard Sizes & Weights
Size A×B (mm) 3mm 4mm 5mm 6mm 7mm 8mm 9mm 10mm
20×200.8941.131.38
25×251.131.451.772.06
30×301.371.772.172.53
35×351.612.092.573.01
40×401.852.412.973.49
45×452.122.763.404.00
50×502.363.073.794.465.135.766.427.06
60×604.585.426.247.03
63×635.035.956.847.718.609.48
70×705.426.427.398.349.3110.3
75×755.826.897.958.9710.011.1
80×807.378.509.6110.711.8
90×908.339.6511.9012.213.4
100×1009.2810.812.2013.615.0
Stainless Steel Channel Bar - Standard Sizes & Weights
Size H×B (mm) 3mm 4mm 5mm 6mm 7mm 8mm 9mm 10mm 12mm
40×201.79
50×252.27
60×302.743.564.375.12
70×353.234.215.176.08
80×403.714.845.967.03
90×454.255.556.838.05
100×504.736.187.628.9810.311.713.041.2
120×609.2010.912.614.2
130×6510.111.913.815.517.319.1
140×7012.914.916.818.820.7
150×7513.916.018.120.222.226.3
160×8014.817.119.321.623.828.1
180×9016.719.422.024.527.032.0
200×10018.621.624.527.430.235.8
About Our Company
We are a comprehensive stainless steel enterprise specializing in material wholesale, processing, storage, and distribution. Located in Wuxi - the stainless steel trading center, with a total investment of 10 million yuan and annual sales exceeding 300 million yuan.
We maintain long-term, stable cooperative relationships with renowned steel mills including Taiyuan, East, Zhang Pu, Hongxing, Zhejiang Qingshan, and distribute stainless steel plates imported from Sweden, North America, South Africa, Japan, South Korea, and other regions.
Material Range & Processing Capabilities
Material Grades: 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205-904L, high temperature resistant stainless steel series, duplex stainless steel series, super stainless steel series.
Processing Equipment: Plasma cutting machines, coil material opening equipment, laser cutting machines, 8K mirror finishing, grinding wire drawing, film and titanium plating equipment.
Specialized Services: Thick plate cutting (up to 150mm), cutting rounds, squares, shaped parts, casting parts, forging parts. Customized specifications available according to customer requirements.
Product Applications
Stainless steel angle bars and channel bars are primarily used for frame structures including:
  • High-voltage power transmission towers
  • Frame structures for steel bridges
  • Tower crane columns and booms on construction sites
  • Workshop columns and beams
  • Air-conditioning and solar-powered shelf supports
  • Building structures and engineering construction
  • Ship beams and industrial furnaces
Our stainless steel angle bars and channel bars are widely applicable across various industrial sectors including machinery, chemical, petroleum, boiler, heat exchanger, food machinery, beverage machinery, and medical equipment industries.
