Seamless SS Pipe 304 316L 2205 Cold Rolled Polished Stainless Steel Pipe
Seamless SS Pipe 304 316L 2205 Cold Rolled Polished Stainless Steel Pipe
Specifications
Certification :
AISI, ASTM, EN, DIN
MOQ :
50 kg
Price :
US $6.75-8.75 / kg
Model Number :
304 316L 2205
Shape :
Round
Technique :
Cold Rolled
Surface Treatment :
Polished
Outer Diameter :
6-300mm
Production Capacity :
500000kgs
Chromium Content :
24-26%
Nickel Content :
21-23%
Molybdenum Content :
2-2.50%
Carbon Content :
≤ 0.020%
Tensile Strength :
540-740 MPa
Proof Strength :
250 MPa
Elongation at Break :
40%
Brinell Hardness :
95
Modulus of Elasticity :
195 GPa
Description
Seamless SS Pipe 304 316L 2205 SS Polished Pipe
TP 310 / 310S Stainless Steel Sheet Metal ASTM A240 Overview
310, 310S and 310H stainless steel is an austenitic stainless steel designed for high temperature applications, capable of withstanding temperatures up to 2,100°F in continuous service. This grade contains 25% chromium and 20% nickel, providing exceptional resistance to oxidation and corrosion. 310S stainless steel is the lower carbon version, reducing susceptibility to embrittlement and sensitization. 310H stainless steel plate is the high carbon variant. These grades are widely used in moderately carburizing atmospheres found in petrochemical environments and are suitable for cryogenic applications due to their toughness and low magnetic permeability.
Available Product Forms
  • Sheet, Plate, Coil, Strip
  • Wire, Pipe, Tube, Bar
  • Profile, Round, Flat, Square, Hexagonal
TP 310 / 310S Stainless Steel Sheet Metal ASTM A240 Specifications
Product Type310 Stainless Steel Sheet, 310 Stainless Steel Plate
Other Trade NamesSS 310, SUS 310, Inox 310, DIN 1.4840, UNS S31000, AISI 310, SAE 310 Sheet
SpecificationASTM A240 / ASME SA240
TolerancesEN 10258 / DIN 59381
International StandardsASTM A480, ASTM A959, ASME IID, EN ISO 9445, EN ISO 18286, EN 10051, EN 10088-1, ISO 15510
DimensionsCold rolled: 0.5-6.4 mm, Hot rolled: 3.0-10.0 mm
Thickness Range0.1 to 100 mm
Width Range10-2500 mm
Length Options2m, 2.44m, 3m, or custom lengths
Cutting MethodsLaser Cut, Plasma Cut, Waterjet Cut, Saw Cut, Shear/Guillotine
Available FinishesSatin, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish, 1D, No.4, BA, 8K, hairline, brush, mirror
Hardness OptionsSpring Hard, Soft, Hard, Half Hard, Quarter Hard
Dimension Ranges
  • Width: 600mm - 2030mm
  • Thickness: 0.1mm - 120.0mm
  • Length: 300mm - 6000mm (Maximum 18000mm)
Surface Finish Options
No.1, 2B, BA, No.3, No.4, No.5, No.8, HL, Etching, SB, Ti-coating, color-coating, embossing
Applications
TP 310/310S stainless steel is utilized across multiple industries for its high-temperature resistance and durability:
  • Cryogenic components and furnace construction (burners, recuperators, doors, fans, piping)
  • Food processing, chemical, and pharmaceutical industries
  • Fluid bed furnaces, coal combustors, grids, wind boxes
  • Ore and steel processing (smelters, steel melting, continuous casting equipment)
  • Petroleum refining (catalytic recovery systems, flares, recuperators, tube hangers)
  • Power generation (coal gasifier internals, pulverized coal burners, tube hangers)
  • Sintering and cement plants (burners, burner shields, feeding/discharging systems)
  • Thermal processing (annealing covers, burner grids, doors, fans, muffles, retorts)
Equivalent Standards
  • DIN 1.4845, DIN X12CrNi25-21, DIN X8CrNi25-21
  • AFNOR Z12CN2520, BS 310S24, UNI X6CrNi2520
  • SS 2361, UNE F.331, SAE 310S
  • JIS SUH310, JIS SUS310S, JIS SUS310STP
  • JIS SUS310STPY, JIS SUS310STB, JIS SUS310SFB
  • EN X8CrNi25-21, EN 1.4845, UNS S31008
Technical Data Sheet
Chemical Composition
ElementContent (%)
Iron, FeBalance
Chromium, Cr24-26
Nickel, Ni21-23
Molybdenum, Mo2-2.50
Manganese, Mn≤ 2
Nitrogen, N0.10-0.16
Silicon, Si≤ 0.70
Phosphorous, P0.025
Carbon, C≤ 0.020
Sulfur, S≤ 0.010
Mechanical Properties
PropertiesMetricImperial
Tensile Strength540-740 MPa78,320-107,327 psi
Proof Strength250 MPa36,259 psi
Modulus of Elasticity (20°C)195 GPa28,282 ksi
Elongation at Break40%40%
Hardness, Brinell9595
