ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
ASTM A213 347H Stainless Steel Heat Exchanger Tube with Cold-Drawing and Polished Finish
Specifications
MOQ :
50 kg
Price :
US $4.85-7.25 / kg
Model NO. :
347H
Shape :
Round
Technique :
Cold-Drawing
Surface Treatment :
Polished
Specification :
OD 6-630mm
Outside Diameter :
1/2"-24"
Thickness :
SCH5 SCH10 SCH40 SCH80 SCH160 XXS
Material Grade :
incone 904L, 254MO, 317L
Standard :
ASTM A312, A269
Length Tolerance :
+/- 5mm
Outer Diameter Tolerance :
+/- 0.2mm
Thickness Tolerance :
+/- 0.02mm
Density :
7.96 g/cm3
Melting Range :
2550 - 2635°F (1398 - 1446°C)
Thermal Conductivity :
16.3 W/m-°K
Description
ASTM A213 347/347H Stainless Steel Heat Exchanger Tubes for Oil Industry
High-quality 347H stainless steel seamless tubes offering excellent performance in demanding oil industry applications with competitive pricing and superior corrosion resistance.
Product Specifications
Parameter Specification
Product Name 347H Stainless Steel Seamless Tubes
Round Outside Diameter 1/2" - 24"
Thickness SCH5, SCH10, SCH40, SCH80, SCH160, XXS
Material Grade Special steel: Incone 904L, 254MO, 317L and similar alloys
Raw Material TSING SHAN
Standard ASTM A312, A269
Length Customized to customer requirements
Tolerance Outer Diameter: ±0.2mm, Thickness: ±0.02mm, Length: ±5mm
Surface Treatment Annealing, pickling, sandblasting
Marking LOGO, SIZE, STANDARD, HEAT TREATMENT, Custom requirements
Quality Assurance Dedicated inspection team, strict standards, accepts customer and third-party inspection
Applications Industrial, exhaust systems, water, petroleum, chemical, nuclear industry, electric power, shipbuilding, paper making, food processing, decoration, machinery and construction industries
Testing Squash test, extended test, water pressure test, heat treatment, NDT
Delivery Large raw material stock ensures timely order completion
Alloy 347 (S34700) is a stabilized stainless steel that offers excellent resistance to intergranular corrosion following exposure to temperatures in the chromium carbide precipitation range from 800 to 1500°F (427 to 816°C). The alloy is stabilized by the addition of columbium and tantalum, providing superior high-temperature mechanical properties and enhanced creep resistance compared to standard 304 and 304L alloys.
Material Properties
General Characteristics
Alloy 347 (UNS S34700) is a columbium-stabilized austenitic stainless steel with excellent general corrosion resistance and superior performance in strong oxidizing conditions. It maintains excellent resistance to intergranular corrosion after exposure to temperatures between 800-1500°F (427-816°C), with good oxidation resistance and creep strength up to 1500°F (816°C).
Corrosion Resistance
  • Excellent resistance to intergranular corrosion in chromium carbide precipitation range
  • Superior performance in strongly oxidizing environments up to 1500°F (816°C)
  • Suitable for nitric solutions and diluted organic acids at moderate temperatures
  • Resists polythionic acid stress corrosion cracking in hydrocarbon service
  • Not recommended for chloride solutions or sulfuric acid applications
Chemical Composition
Element 347 (%) 347H (%)
Chromium 17.00 min. - 19.00 max. 17.00 min. - 19.00 max.
Nickel 9.00 min. - 13.00 max. 9.00 min. - 13.00 max.
Carbon 0.08 max. 0.04 min. - 0.10 max.
Manganese 2.00 max. 2.00 max.
Phosphorus 0.045 max. 0.045 max.
Sulfur 0.03 max. 0.03 max.
Silicon 0.75 max. 0.75 max.
Columbium & Tantalum 10 x (C + N) min. - 1.00 max. 8 x (C + N) min. - 1.00 max.
Iron Balance
Physical Properties
Property Value
Density 0.288 lbs/in³ (7.96 g/cm³)
Specific Heat 0.12 BTU/lb-°F (500 J/kg-°K)
Modulus of Elasticity 28.0 x 10⁶ psi (193 GPa)
Thermal Conductivity (200°F/100°C) 133 BTU/hr/ft²/ft/°F (16.3 W/m-°K)
Melting Range 2550 - 2635°F (1398 - 1446°C)
Electrical Resistivity 72 Microhm-cm at 20°F
Thermal Expansion Coefficients
Temperature Range °F °C in/in °F cm/cm °C
Low Range 68-212 20-100 9.2 x 10⁻⁶ 16.0 x 10⁻⁶
Medium Range 68-1112 20-600 10.5 x 10⁻⁶ 18.9 x 10⁻⁶
High Range 68-1832 20-1000 11.4 x 10⁻⁶ 20.5 x 10⁻⁶
