Specifications
Brand Name :
BAOSTEEL TISCO
Model Number :
304L
Certification :
ISO
Place of Origin :
China
MOQ :
50 kgs
Price :
2-2.5 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Stainless Steel Plate
Grade :
304L
Thickness :
1.5-50.0mm
Tech :
cold rolled,hot rolled , forged
Width :
1000mm 1219mm 1500mm or customs as request
Surface :
2B NO.1
Standard :
ASTM GB JIS EN DIN
MOQ :
1 Ton
Description

ASTM A240 304L Stainless Steel Sheet/Plate for Chemical, Food Processing, and Architectural Applications

Stainless Steel Plate Specifications

Name 304L stainless steel Plate
Our Grade

200 Series: 201 202

300 Series: 301 304,304L,304H,309S,310S,314,316L,316Ti,316H,316LN,317L,321,329,347

400 Series: 409L,410,410S,416,420,430,431,436L.439,441,443,444,445,446

Super Stainless Steel: 904L,926,254SMO,654SMO,15-5PH,17-4PH,17-7PH.etc

Nickel Alloy: C276, C22,G35,Alloy X,Monel 400,K500,Inconel 600,601,617,625,718,Incoloy 800,800H,800HT,825.etc
Technique Hot Rolled, Cold Rolled,Forged
Standard JIS, AISI, ASTM, DIN, TUV, BV, SUS, etc
Thickness 0.1 – 80.0mm
Width range 10mm – 2000mm
Length Customized
Finish 2B, BA, No.4, 8k, Brushed,Hairline,PVD Coating,Sandblasted
Service Laser Cutting, Bending
Sample Available

ASTM A240 304L Stainless Steel Sheet & Plate – Engineered for Chemical, Food Processing, and Architectural Applications

Product Overview

ASTM A240-compliant 304L stainless steel sheet and plate is the industry-preferred low-carbon austenitic grade for applications requiring excellent corrosion resistance, superior weldability, and hygienic surface integrity—without the risk of intergranular corrosion after welding.

With a maximum carbon content of 0.03%, 304L (UNS S30403 / EN 1.4307) eliminates carbide precipitation in the heat-affected zone (HAZ), making it ideal for welded fabrications in demanding sectors such as chemical processing, food & beverage, pharmaceuticals, architecture, and cryogenic engineering.

Manufactured to strict ASTM A240/A240M, ASME SA-240, and EN 10088-2 standards, our 304L sheets and plates offer consistent quality, full traceability, and global compliance—ensuring reliability from fabrication through decades of service.

Why 304L? Key Advantages by Industry

Industry Critical Need How 304L Delivers
Chemical Processing Resistance to mild acids & solvents Stable in organic acids (acetic, citric), dilute nitric/phosphoric acid; non-reactive surfaces
Food & Beverage Hygiene, cleanability, FDA compliance Smooth, non-porous finish; meets FDA, EC 1935/2004; resists bacterial growth
Pharmaceutical Purity & contamination control Low leaching; compatible with CIP/SIP cleaning; non-toxic
Architecture Aesthetics + durability Attractive finishes (brushed, mirror); resists urban/rural atmospheric corrosion
Cryogenics Toughness at low temps Retains ductility down to –196°C (–320°F)

Unlike standard 304, 304L requires no post-weld annealing, reducing cost and complexity in large-scale welded structures.

Technical Specifications

Chemical Composition (Typical – wt%, per ASTM A240)

Element Content (%)
Chromium (Cr) 18.0–20.0
Nickel (Ni) 8.0–12.0
Carbon (C) ≤0.030
Manganese (Mn) ≤2.00
Silicon (Si) ≤0.75
Phosphorus (P) ≤0.045
Sulfur (S) ≤0.030
Iron (Fe) Balance

UNS S30403 | EN 1.4307 | AISI 304L

Mechanical Properties (Annealed Condition)

Property Typical Value
Tensile Strength 485–620 MPa
Yield Strength (0.2% offset) ≥170 MPa
Elongation ≥40%
Hardness ≤201 HB
Density (20°C) 8.0 g/cm³
Thermal Conductivity ~16.2 W/m·K

Corrosion Resistance Profile

✅ Excellent in:

  • Atmospheric environments (urban, rural)
  • Freshwater and potable water systems
  • Organic acids (vinegar, citric, lactic)
  • Alkaline solutions
  • Mild chemical environments (dilute sulfuric/nitric <10%)

⚠️ Not recommended for:

  • Seawater or high-chloride (>200 ppm) environments
  • Hydrochloric or strong reducing acids
  • Marine splash zones (consider 316L instead)

Available Product Forms & Sizes

Parameter Details
Material Grade 304L / UNS S30403 / 1.4307
Standards ASTM A240, ASME SA-240, EN 10088-2
Form Cold-rolled sheet (<4.5 mm)
Hot-rolled plate (≥4.5 mm)
Thickness Range 0.5 mm – 100 mm
(Common stock: 1.0, 1.5, 2.0, 3.0, 4.0, 6, 8, 10, 12, 16, 20, 25, 30 mm)
Standard Dimensions • 1000 × 2000 mm
• 1219 × 2438 mm (4' × 8')
• 1500 × 3000 mm
• 1500 × 6000 mm
• Custom sizes available
Surface Finishes • 2B (standard for sheet)
• No.1 (plate, descaled)
• BA (bright annealed)
• No.4 (brushed)
• Hairline, Mirror, Embossed (custom)
Certifications EN 10204 3.1/3.2 MTR, PMI, ISO 9001, RoHS, REACH

All materials are batch-traceable with mill heat numbers and stored in dry, covered facilities.

Industry-Specific Applications
