AISI304 Stainless Steel Strips 1/4H 1/2H 3/4H FH Slit Cutting Stainless Steel Coils
AISI304 Stainless Steel Strips 1/4H 1/2H 3/4H FH Slit Cutting Stainless Steel Coils
AISI304 Stainless Steel Strips 1/4H 1/2H 3/4H FH Slit Cutting Stainless Steel Coils
AISI304 Stainless Steel Strips 1/4H 1/2H 3/4H FH Slit Cutting Stainless Steel Coils
AISI304 Stainless Steel Strips 1/4H 1/2H 3/4H FH Slit Cutting Stainless Steel Coils
AISI304 Stainless Steel Strips 1/4H 1/2H 3/4H FH Slit Cutting Stainless Steel Coils
AISI304 Stainless Steel Strips 1/4H 1/2H 3/4H FH Slit Cutting Stainless Steel Coils
AISI304 Stainless Steel Strips 1/4H 1/2H 3/4H FH Slit Cutting Stainless Steel Coils
Specifications
Brand Name :
TISCO
Model Number :
304 / 1.4301 / AISI304
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
2388 - 3647 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
stainless steel strip
Thickness :
0.1-3.0mm
Width :
within 1500mm
MOQ :
500 kgs
Grade :
200 series 300 series 300 series
Surface :
BA 2B NO.4 HL 8K NO.1 2D
Standard :
ASTM EN GB JIS
Packing :
wooden frame and water proof paper
Description

AISI304 Stainless Steel Strips 1/4H 1/2H 3/4H FH Slit Cutting Stainless Steel Coils

Product Name Stainless Steel Strips
Length As required
Width 3mm-1219mm or as required
Thickness 0.1 - 3.0mm or as required
Standard AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique Hot rolled / cold rolled
Surface Treatment 2B or according to customer requirement
Thickness tolerance ±0.01mm
Material 201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 410, 410S,420, 430, 431, 440A,904L
MOQ 1tons.We also can accept sample order.
Shipment time Within 15-20 workdays after receiving deposit or L/C
Export packing Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required
Capacity 2500 tons/year

304 Stainless Steel Strip and Slit Coil

304 stainless steel strip and slit to width coil, ASTMA-666, is similar to Type 302, but has a maximum carbon content of 0.08%. This material has an excellent combination of corrosion resistance and formability. 304 is also known as 18/8 chrome-nickel, austenitic, stainless strip. It is a versatile alloy that welds well without filler. It’s commonly used in stampings and drawn parts. It’s non-magnetic in the annealed state and become magnetic with work hardening. Gibbs Interwire stocks Type 304 annealed stainless strip in gauges from 0.0053″ and 304 tempered strip in gauges from .0019”.

304 Stainless Steel Strip Chemical Composition

The chemical components of grade 304 stainless steel strip is summarized in the following table:

Grade Standard C Si Mn P S Cr Ni Mo
304 ASTM A240 ≤0.07 ≤0.75 ≤2.00 ≤0.045 ≤0.030 18.00-20.00 8.00-11.00 –

304 Stainless Steel Strip Mechanical Properties

MECHANICAL PROPERTIES: (PER ASTM A240, A666)

Type Yield Strength 0.2% offset (KSI) Tensile Strength (KSI) % Elongation(2″ Gauge length)
304 Ann 30 min. 75 min. 40 min.
304 ¼ Hard 75 min. 125 min. 12 min.
304 ½ Hard 110 min. 150 min. 7 min.
304L Ann 25 min. 70 min. 40 min.
304L ¼ Hard 75 min. 125 min. 12 min.
304L ½ Hard 110 min. 150 min. 6 min.

PROCESSING:

Types 304 and 304L cannot be hardened by thermal treatment. Annealing: Heat to 1850o F to 2050 o F and cool at sufficiently high rates through 1500oF to 800oF to avoid precipitation of chromium carbides. Stress Relief Annealing: Cold worked parts should be stress relieved at 750oF for ½ to 2 hours.

FORMING:

Annealed Types 304 and 304L can be fabricated by roll forming, deep drawing, bending and most other fabrication techniques. Due to the high work hardening rate of these materials, intermediate anneals maybe required to successfully fabricate the part.

WELDING:

Types 304 and 304L are weldable by most fusion or resistance welding techniques. If filler metal is required, Type 308 is normally used. Type 304L should be used in heavier sections to reduce the occurrence of carbide precipitation in the heat affected region adjacent to the weld pool

CORROSION:

Types 304 and 304L provides corrosion resistance in a wide range of moderately oxidizing and reducing conditions, fresh water and non-marine applications

What Are 304 Stainless Steel Strip Applications

Grade 304 stainless steel foils rolls are popular for a variety of commercial and industrial applications.

  • Automotive
  • Surgical instruments
  • Architecture
  • Heat treating
  • Precision electronical parts
  • Solar and alternative energy
  • Other Precision Parts
