EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless
EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless
EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless
EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless
EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless
EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless
EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless
EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless
Specifications
Brand Name :
DELTA
Model Number :
EN 1.4432
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
3250 -4500 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
wooden pallets + waterproof paper
Products :
stainless steel plate
Grade :
EN 1.4432
Standard size :
1000*2000mm 1219*2438mm 1500*6000mm
Thickness :
0.4- 40.0mm
Brand :
TISCO BAOSTEEL POSCO LISCO
Loading Port :
Shanghai Port
MOQ :
500 kgs
Packing :
wooden pallets + waterproof paper
Description

EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless Steel

More Informations of our Products

Item Stainless Steel Plates / Stainless Steel Sheets
Grades 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, etc.
Thickness 0.4mm-40mm
Stock Thickness 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10mm,12 - 40mm
Width 1000mm 1219mm 1500mm or cutting any size as request
Standard size 1000*2000mm 1219*2438mm 1500*6000mm 2000*6000mm
Finish 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc.
Package Standard export package

Chemical Composition of EN 1.4432 Stainless Steel

C Si Mn Ni P S Cr Mo N
max 0.03 max 1 max 2 10.5 - 13 max 0.045 max 0.015 16.5 - 18.5 2.5 - 3 max 0.11

MECHANICAL PROPERTIES OF GRADE1.4432

Proof strength
Rp0.2(MPa)		 Tensile strength
Rm(MPa)		 Impact energy
KV(J)		 Elongation at fracture
A(%)		 Reduction in cross section on fracture
Z(%)		 As-Heat-Treated Condition Brinell hardness(HBW)
176(≥) 215(≥) 11 32 43 Solution and Aging,Annealing,Ausaging,Q+T,etc 311

Equal Grade of 1.4432 Stainless Steel

EU
EN		 USA
-		 Japan
JIS		 France
AFNOR		 England
BS		 Sweden
SS		 Russia
GOST
X2CrNiMo17-12-3 316L SUS316L Z3CND17-13-03 316S13 2353 03KH17N14M3

1.4432 RANGE OF PRODUCTS
Product type Products Dimension Processes Deliver Status
Plates/Sheets Plates/Sheets 0.08-200mm(T)*W*L Forging,hot rolling and cold rolling Annealed,Solution and Aging,Q+T,ACID-WASHED,Shot Blasting
Steel Bar Round Bar,Flat Bar,Square Bar Φ8-1200mm*L Forging,hot rolling and cold rolling,Cast Black,Rough Turning,Shot Blasting,
Coil/Strip Steel Coil/Steel Strip 0.03-16.0x1200mm Cold-Rolled&Hot-Rolled Annealed,Solution and Aging,Q+T,ACID-WASHED,Shot Blasting
Pipes/Tubes Seamless Pipes/Tubes,Welded Pipes/Tubes OD:6-219mm x WT:0.5-20.0mm Hot extrusion,Cold Drawn,Welded Annealed,Solution and Aging,Q+T,ACID-WASHED

Product shapes we supply:

  • Tool Die Steels in the 1.4432 Special Alloy grade
  • Stainless Steels - Special Steels in the 1.4432 Special Alloy grade
  • Square and Flat Steel in the 1.4432 Special Alloy grade
  • Coil Sheet in the 1.4432 Special Alloy grade
  • Bar and Hollow Bar in the 1.4432 Special Alloy grade
  • Forgings in the 1.4432 Special Alloy grade
  • Superalloy in the 1.4432 Special Alloy grade
  • Tube Pipe in the 1.4432 Special Alloy grade
  • Non-Magnetic Steel in the 1.4432 Special Alloy grade
  • Steels of Blade for Steam Turbine in the 1.4432 Special Alloy grade

EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 StainlessEN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 StainlessEN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 StainlessEN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless
