EN 1.4558 Seamless Stainless Steel Tube Pipe Sch80S Intended For Pipelines
EN 1.4558 Seamless Stainless Steel Tube Pipe Sch80S Intended For Pipelines
EN 1.4558 Seamless Stainless Steel Tube Pipe Sch80S Intended For Pipelines
EN 1.4558 Seamless Stainless Steel Tube Pipe Sch80S Intended For Pipelines
Specifications
Brand Name :
zheheng steel
Model Number :
88.9mm
Certification :
iso9001
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A, D/P
Supply Ability :
50TONS/30DAYS
Delivery Time :
30 DAYS
Packaging Details :
In bundles with waterproof material,or wooden crate packing
Material :
1.4558
Standard :
ASTM, GB, JIS, DIN, EN, AISI
shape :
sch80s
technique :
Cold-drawn
APPLICATION :
chemical
package :
woven packing
OD :
6-830mm
Description
EN 1.4558 Seamless Stainless Steel Tube Pipe Sch80S Intended For Pipelines
EN 1.4558 (X2NiCrAlTi32-20) Stainless Steel Tube Sch80S intended for pipelines
Product Introduction
EN 1.4558 stainless steel is a superaustenitic (highly alloyed) stainless steel formulated for primary forming into wrought products. Cited properties are appropriate for the solution annealed (AT) condition. 1.4558 is the EN numeric designation for this material. X2NiCrAlTi32-20 is the EN chemical designation.
It has a very low tensile strength among wrought superaustenitic stainless steels. In addition, it has a moderately low base cost and a moderately low embodied energy.
Applications
The 1.4558 grade is used in chemical industry equipment manufacturing nitric acid and derivatives, salts and fertilizers. Also used in cryotechnics, pharmaceutical industry, food industry (food processing plants, dairies, sugar factories, breweries), fuel industry (refineries and petrochemical plants).
Steel intended for pipelines, autoclaves, transport tanks, heat exchangers, absorption towers, pumps, coolers, and reactors.
Chemical Composition of 1.4558
Country (Region) Standard Steel Grade C, ≤ Si, ≤ Mn, ≤ P, ≤ S, ≤ Cr Ni Nb
European Union EN 10216 X2NiCrAlTi32-20 (1.4558) MIN
MAX 0.08		 MIN
MAX 1		 MIN
MAX 2		 MIN
MAX 0.04		 MIN
MAX 0.015		 MIN 17
MAX 19		 MIN 9
MAX 12		 MIN 10xC to 1.00
Production Range Specifications
  • Name: Stainless Steel Seamless Pipe
  • Standard: EN10216-5, EN10216-2, DIN 17456, DIN 17458, ASTM A312, A213, A269, A511, A789, A790, GOST 9941, GOST 5632, JIS G3459, JIS G3463, GB/T14975, GB13296, GB5310, GB9948
  • Material Grade: 1.4558
  • Diameter: OD: 6-830mm
  • Wall Thickness: 0.6mm - 60mm
  • Length: Up to 13 meters or as customers' request
  • Tolerance: According to the Standard
  • Surface: Natural Color of annealing & pickling, 180G, 320G, 400G Satin/Hairline, 400G, 500G, 600G or 800G Mirror finish
  • Test: UT, ET, HT, RT, and others according to standard or customer requests
Product Packaging
EN 1.4558 Seamless Stainless Steel Tube Pipe Sch80S Intended For Pipelines
Tensile Requirements
Tensile Strength: 75 KSI
Yield Strength: 30 KSI
Additional Information
  • Each pipe undergoes nondestructive electric test or hydrostatic test
  • Pipe lengths from NPS 1/8" to NPS 8 available up to 24ft (15-24ft range)
  • Finished pipes are reasonably straight with workmanlike finish
  • Butt weld ends according to ANSI B 16.25
  • Pipe marking includes: Logo, Standard, Size, Heat No., Lot No., H.T/E.T/U.T
  • Packing: Plastic end caps, anti-rust steel strip, plastic woven bag or film
  • Packing mark includes: Size, Steel Grade, Quantity, Weight, Meter
  • Official Original MTC paper supplied for each order
Unit Conversion Notes:
10-6*K-1 = 10-6/K
1 Ω*mm²/m = 1 μΩ*m
1 g/cm3 = 1 kg/dm3 = 1000 kg/m3
1 GPa = 1 kN/mm2
1 MPa = 1 N/mm2
