ASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface Finish
ASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface Finish
ASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface Finish
ASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface Finish
ASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface Finish
ASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface Finish
ASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface Finish
ASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface Finish
Specifications
Brand Name :
XQX
Model Number :
316L
Certification :
SC-RCS
Place of Origin :
China
MOQ :
5tons
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000Ton per month
Delivery Time :
15-30 workdays
Packaging Details :
Container
Product name :
316 Stainless Steel plate
finish :
2B
Thickness :
3.0mm
Technique :
Cold rolled
width :
1255
Standard :
AISI
Product Type :
Sheet
Main Size :
3.0*1255*680
length :
680
Description

2B BA No.1/2E HL Mirror No.4 Surface Finish Stainless Steel Sheet 316L Grade AISI/ASTM/SUS/JIS/DIN/TUV/BV/ETC Standard

316L Stainless Steel Sheet 3.0*1255*680 2B Finish Stainless Steel ASTM Standard

Fabrication
Fabrication of all stainless steels should be done only with tools dedicated to stainless steel materials. Tooling and work surfaces must be thoroughly cleaned before use. These precautions are necessary to avoid cross contamination of stainless steel by easily corroded metals that may discolour the surface of the fabricated product.

Cold Working
304 stainless steel readily work hardens. Fabrication methods involving cold working may require an intermediate annealing stage to alleviate work hardening and avoid tearing or cracking. At the completion of fabrication a full annealing operation should be employed to reduce internal stresses and optimise corrosion resistance.

Application

  • Insulated cups (we supply stainless steel materials to the largest manufacturer of insulated cups in China)

  • Springs, screws, nuts & bolts

  • Sinks & splash backs

  • Architectural panelling

  • Tubing

  • Brewery, food, dairy and pharmaceutical production equipment

  • Sanitary ware and troughs

  • Saucepans

Supplied Forms

  • Sheet

  • Plate

  • Coil

Specification

Chemical Compostion

Chemical Composition
Material C Si Mn P S Ni Cr Mo N
201 ≤0.15 ≤1.00 5.5~7.5 ≤0.060 ≤0.03 3.5~5.5 16.0~18.0 - -
304 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 8.0~11.0 18.0~20.0 - -
304L ≤0.03 ≤0.75 ≤2.00 ≤0.045 ≤0.03 8.0~12.0 18.0~20.0 - -
316 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 10.0~14.0 16.0~18.0 2.00~3.00 -
316L ≤0.03 ≤1.00 ≤2.00 ≤0.045 ≤0.03 10.0~14.0 16.0~18.0 2.00~3.00 ≤0.10

Machine Capability

Yield strength (N/mm2) Tensile strength (N/mm2Mpa): Elongation: Hardness
>=205

>=520

>=40

HB <=187 BRB <=90

Density(g/cm3) : 7.93

Machine Capability

Yield strength (N/mm2) Tensile strength (N/mm2Mpa): Elongation: Hardness
>=205

>=520

>=40

HB <=187 BRB <=90

Density(g/cm3) : 7.93

Packaging & Shipping

ASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface FinishASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface Finish

ASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface FinishASTM Standard 316 Stainless Steel Sheet 316L No.4 Surface Finish

Surface finish

Surface finish
Characteristics & Application
NO.1
Hot-rolled surface,annealed and pickled,can be used as cold-rolling material,industial tanks and chem i cal devices.
NO.2D
Cold-rolled, an nealed and pick led with out skinpassing the dull prod ucts can be used as auto mo bile parts, build ing materrials and pipings.
NO.2B
The surface brightness and flatness of NO.2B is better than NO.2D. Then through a special surfacetreament to improve its mechamical properties, N02B could nearly satisfy com pre hen sive uses.
NO.3
Polished with abra sive belt of grit #100#120,have bet ter bright ness with dis con tin u ous coarse stria, used as in ner and ex ter nal or na ments for building, elec tri cal ap pli anc es and kitchen uten sils etc.
NO.4
Polished with abrasive belt of grit #150#180, have better brightness with discontinuous coarse stria, but thinner than NO.3, are used as bathtud buildinginner and external ornaments electrical appliances, kitchen utensils and food processing equipment etc.
HL
Polished with abrasive belt of grit #150-320 on the No.4 finish and has continuous streaks, mainly used as building ornaments, elevators, door of building, frontal plate etc.
BA
Cold rolled, bright an nealed and skin passed, the prod uct has ex cel lent bright ness and good re flex iv i ty like mirror, used for lectrical appliances, mirror, kitch en apparatus, or na ment ma te ri als etc.

Thickness 0.2-3mm
Width 30-850mm/1000mm/1219mm/1240mm/1500mm
Standard AISI/ASTM/SUS/JIS/DIN/TUV/BV/ETC
Surface Finished 2B BA No.1/2E HL Mirror No.4
Application It is widely used in high-temperature and electric industry, medical devices, construction, chemistry, food industry, agriculture,
and ship components.
It also applies to food and beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts,
springs, and screen mesh etc. .
Certification CE, ISO, SGS, BV
Technique cold drawing
Edge Mill Edge / Slit Edge
Quality SGS Inspection
Grade(ASTM UNS) 201 304 316 410S 430
Price Terms FOB
Export Packing Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package
Supply Ability 10000Ton/Tons per Month


About us:


FAQ:​
Q1:What product information must I provide before making a purchase?
Please provide the grade, width, thickness, and surface treatment requirements, as well as the quantities you require.
Q2:What shipping ports are there?
We normally ship from FuZhou, Shanghai, Xiamen ports.
Q3:What are your payment terms?
20% T/T in advance and 80% balance before shipment.
Q4:What about product pricing information?
Prices vary due to changes in raw material prices on a regular basis.
Q5:Is it possible to send samples?
Of course, we offer free samples and express shipping to customers all over the world.
