300 Series Polished Square Welded Stainless Steel Tube 4m - 6m
300 Series Polished Square Welded Stainless Steel Tube 4m - 6m
300 Series Polished Square Welded Stainless Steel Tube 4m - 6m
300 Series Polished Square Welded Stainless Steel Tube 4m - 6m
300 Series Polished Square Welded Stainless Steel Tube 4m - 6m
300 Series Polished Square Welded Stainless Steel Tube 4m - 6m
300 Series Polished Square Welded Stainless Steel Tube 4m - 6m
300 Series Polished Square Welded Stainless Steel Tube 4m - 6m
Specifications
Brand Name :
NADONG
Model Number :
316
Certification :
ISG SGS
Place of Origin :
CHINA
MOQ :
1 Ton
Price :
$1000-$2200
Payment Terms :
L/C, T/T
Supply Ability :
1000 ton per month
Delivery Time :
15 working days
Packaging Details :
According to customer needs
Grade :
300 Series
Length :
4~6m (or customized)
Tolerance :
±1%
Steel Grade :
301L, 301, 316L, 316, 304, 304L
Processing Service :
Bending, Cutting
Manfacture technology :
cold drawn/cold rolled
OD of SS pipe :
6 to 720mm, 1/8 to 36 inches
Thickness :
0.8mm-20 mm
Description

Manufacturer 316 Welded Polished Square Stainless Steel Welded Tube

410 stainless steel is a stainless steel grade produced in accordance with the American ASTM standard, which is equivalent to China's 1Cr13 stainless steel, S41000 (American AISI, ASTM). It contains 0.15% carbon and 13% chromium.

Specfications

product name
Stainless steel pipe
Grade
201.202.301.302.304.304L.309S.310S.316.316L.321.410.430.430A.440A.440B.440C.904L.2205.2507.2520 ect. Or Customized
Standard
GB, AISI, ASTM, ASME, EN, BS, DIN, JIS
Surface
Satin Finish(180#.240#.320#).,Bright Finish(400#,600#,mirror),Mill Finish(2B),Hairline-Finish
(HL/Brushed),Ti-gold, Glossy matt,dull and so on.
specifications
Outer diameter
6mm-630mm or customized
Wall thickness
0.1-30mm or customized
Length
0.3-15.8m or customized
Technique
Cold rolled
welding or customized
Hot rolled
seamless
Test and Inspection
Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT
Thickness tolerance
±0.05mm

Chemical Composition

Specification Grade Chemical Composition(wt%)
C Mn Ni Cr Mo Ti
ASTMJIS 316L/022Cr17Ni12Mo2 ≤0.03 ≤2.0 10.0-14.0 16.0-18.0 2.0-3.0 -
JIS SUS316L ≤0.03 ≤2.0 12.0-15.0 16.0-18.0 2.0-3.0 -
ASTMJIS 316Ti/SUS 316Ti ≤0.08 ≤2.0 10.0-14.0 16.0-18.0 2.0-3.0 5*(C+N)-0.7

Properties

Spec Grade Mechanical Property Physical Property

Y.S

(N/MM2)

T.S

(N/MM2)

EL

(%)

 HRB

Specific Heat

(J/g℃)

 Modulus of Elasticity (KN/mm2)
ASTM/GB 316L/022Cr17Ni12Mo2 ≥170 ≥485 ≥40 ≤95 0.5 193
JIS SUS316L ≥175 ≥480 ≥40 ≤90 193
ASTM 316Ti ≥205 ≥515 ≥40 ≤95 0.5 200

300 Series Polished Square Welded Stainless Steel Tube 4m - 6m

300 Series Polished Square Welded Stainless Steel Tube 4m - 6m300 Series Polished Square Welded Stainless Steel Tube 4m - 6m

300 Series Polished Square Welded Stainless Steel Tube 4m - 6m

Applications:

316L: Widely used in corrosion-susceptible environment and some mechanical components those are difficult to make heat treatment after forming in more corrosive environment.

316Ti: Mainly used for industrial components.

300 Series Polished Square Welded Stainless Steel Tube 4m - 6m

300 Series Polished Square Welded Stainless Steel Tube 4m - 6m
