SMD HD Fixed LED Display , Outdoor Video Wall LED Module Display 192*192mm Size
SMD HD Fixed LED Display , Outdoor Video Wall LED Module Display 192*192mm Size
SMD HD Fixed LED Display , Outdoor Video Wall LED Module Display 192*192mm Size
SMD HD Fixed LED Display , Outdoor Video Wall LED Module Display 192*192mm Size
Specifications
Brand Name :
HJY
Model Number :
P6
Certification :
CE FCC
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000 square meter per month
Delivery Time :
15-20 days after receiving deposit
Packaging Details :
wooden case
LED :
SMD3535
Color :
full color
Module resolution :
32*32dot
Resolution :
27777dot/sqm
Drive :
1/8 scan
Brightness :
5000nits
Keywords :
outdoor led display
Warranty :
2 years
Description

P6 outdoor fixed led display SMD 192*192mm full color led module display

Product Description
1 Pitch size 6mm
2 Module size 192mm*192mm
3 Module pixel(dots) 32*32 dot
4 Pixel configuration 1Red,1Green,1Blue SMD 3-in-1
5 Color scale 65536degree/1.07 billion colors
6 Pixel density 27777pixels/square meter
7 View angle(H/V) 60/120degree
8 Brightness ≥5000cd/sqm
9 Brightness adjustment 100level automatic or manual
10 View distance 6--80m
11 Power consumption 100-1200W/sqm
12 Net weight 45kg/square meter
13 Operating temperature —45°C~+60°C
14 perating humidity 10%—95%RH
15 Life time ≥100,000hours
16 Out of control dot ≤3/10,000
17 Whole Display Flatness ≤1mm Juncture
18 Exchange frame speed >150frames per second
19 Refresh frame frequency 600Hz
20 Control distance Cat. 5: 120m (without repeater), single mode fiber:20km,multi mode fiber: 500m
21 Power 110V/220V±15% 50Hz
22 Operating system Win7 Win8 Win10
23 Drive mode 1/8 scan
24 Display mode VGA640X480—VGA1600X1024
25 Protections for outdoor display IP65 for front, IP54 for rear
26 Maintenance way rear access, hanging installation
27 Accepting signal PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI

1. High quality:
Our most attention is the product quality.

Our most basic guarantee: the aging time exceeding 24 hours. Malfunction dot rate less than 0.0001. MTBF more than 10000 hours.we assure high brightness and long lifespan.

2. Attractive Factory Price:

We are professional manufacturer, has its own factories and production lines. Without middlemen and trading companies, our price is more competitive, quality is more reliable.

3. Perfect Display Effect:

High brightness and clearly led display effect with easy use control system which allow you easy become enviable led display experts.

4. Auto equipment:

Kailite has several auto production lines equipment with Taiwan auto-encapsulate machine, Taiwan ChangYu handler, and the production of LED meets the demand of high quality standard LED display.

5. After-sales service :

1. Lifetime free maintenance and upgrade.

2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
